Dahua IP Video Door Phone Kit Villa Flush Mounting Internal Station and Video Door Phone and PoE Switch

BEST PRICE -58%

KTP01L(F) Dahua Video Door Phone Surface Mounting Kit: Consisting of VTH2421FW-P (Dahua IP Indoor Station 7 Inch Monitor), VTO2201F-P (IP External Video Door Phone), PFS3006-4ET-36 ( Dahua Fast Ethernet Switch 6 Ports with 4 ports PoE and 2 Uplinks ) , VTM114 (Flush Mounting Box Front and Back) . Dahua Security KTP01L(F)

Reference: KTP01L(F)

Brand: Dahua

EAN: 6923172525734

FIND INSTALLER

https://www.setik.biz/en/video-door-phones-kits/8446-dahua-ktp01lf-dahua-villa-ip-video-intercom-kit-flush-mounting-internal-station-and-video-intercom-and-poe-switch.html

€479.61

€1,141.92 -58%

taxes included

ARE YOU A PROFESSIONAL OF THE SECTOR?
REGISTER TO ACCESS YOUR LIST

Quantity

Hurry up! Only a few pieces left in our warehouse!

discover the available quantity

LO HAI TROVATO A MENO?

Scrivici dove e ti sconteremo la differenza fino a fine mese!

CHRISTMAS WEEK 2024 ×

FREE SHIPPING
ON THE ENTIRE CATALOGUE!

1. Reach at least €249
2. Select FEDEX
3. Confirm code NATALE-FREE-E
4. Complete your order.
Shipping will be free of charge!

Until 10 a.m. on 27/12/2024
Code NOT combinable with other actives

Description Product Details Data Sheet Further Details Download

DAHUA VILLA IP VIDEO DOOR ENTRY SURVEILLANCE KIT - COMPLETE - DHI-KTP01L(F) - FLUSH MOUNT

WHAT DOES THIS KIT INCLUDE?
- 1x Dahua IP Indoor Station Monitor 7 Inch (VTH2421FW-P)
- 1x IP Video Intercom (VTO2201F-P)
- 1x Dahua 6-Port Fast Ethernet Switch with 4 PoE ports and 2 Uplinks (PFS3006-4ET-36 )
- Box for Front and Rear Flush Mounting (VTM114)

Product details

	1x Outdoor station - VTO2201F-P > Dahua SIP IP video intercom suitable for outdoor use > H.265 > 2.0mm Fixed Optics > WDR 120dB > 3D NO > PoE > Embed IC reader > 1 Alarm output > 1x RJ45 10M/100M > IP65 > 12V DC > Recessed/surface installation
	1x Dahua indoor station - VTH2421FW-P > Indoor color 7" SIP monitor > Capacitive touchscreen (1024x600) > Microphone > Alarm integration 6 inputs / 1 alarm output > Supports SD cards up to 8GB > 1 RJ45 Wall mount > PoE
	1x Dahua PoE Switch - PFS3006-4ET-36 > Commercial range L2 unmanageable PoE switch > 6 total 10/100Mbps Base-TX ports > 4 PoE ports + 2 Uplinks > Fast transmissions at rates of 10 / 100 Mbps (for all ports) > Supported standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3X > Maximum power: 36W > MAC table size 2K > Support long distance transmission up to 250m via PoE (Subject to speed limit) > Extended working temperature: -10°C to +55°C > Ideal in networks set up in hospitals, schools, supermarkets, stations... > Thunderproof 6kV (4kV in differential mode) > PoE Watchdog function > Dimensions: 194.0mm × 108.1mm × 35.0mm
	1x Front and Rear Flush Mount Box - VTM114 >Interlocking box - Dahua > Compatible with outdoor station VTO2202F-P > Category: Video entryphone > Material: Metal > Wall mounting > Dimensions: 128.9mm × 162.9mm × 34.5mm > Quality product > 24 months warranty

Data sheet

model		VTH2421FW-P
System	main processor	Embedded Microprocessor
System	Operation System	Embedded LINUX OS
Video	Compression	H.264
Audio	Audio compression	G.711
	Audio inputs	All-direction Microphone
	Audio Outputs	Built-in Loudspeaker
	Bidirectional Talk	Support Dual-way Bidirectional talk
Display	LCD screen	7“ 1024x600, capacitive
Operation Mode	Input	Touch screen
interface	Alarm input	6
interface	Alarm output	1
Network	Ethernet	10M/100Mbps Self-adaptive
Network	network protocol	TCP/IP
General	Installation	Surface & Desktops
	Power	DC 12V
	power consumption	Standby ≤1W, Work ≤7W
	Working Temperature	﹣10°C~+55°C
	Relative humidity	10%~90%RH
	Dimensions	119.6mm×221.5mm×21.5mm
	Weight	0.35Kg

model	PFS3006-4ET-36
Hardware
Data transmission port	4 PoE ports with 10/100 Mbps Base-TX 2 Uplink ports with 10/100Mbps Base-TX
Power Supply	AC100–AC240V
Operating Temperature	-10°C to +55°C (-14°F–131°F)
Operating Humidity	10%–90%
power consumption	Idling: 0.5W Full load: 36W
PoE
PoE Budget	Port1-4 ≤30W, whole PoE budget ≤36W
PoE standard	IEEE802.3af, IEEE802.3at
PoE Pin Assignment	PoE: 1, 2, 4, 5(V+), 3, 6, 7, 8(V-)
Performance
Switching Capacity	1.2Gbps
Packet Forwarding Rate	0.89Mpps
MAC TableSize	2K
Jumbo Frames	2048 bytes
Communication Standard	IEEE 802.3, IEEE 802.3u, IEEE 802.3X
Performance
ESD	Air discharge: 8kV Contact discharge: 6kV
Thunderproof	Common mode: 6kV Differential mode: 4kV
Net Weight	0.56kg (1.23lb)
Gross Weight	1.11kg (2.15lbs)
Product Dimensions (W×L×H)	194.0mm × 108.1mm × 35.0mm (7.64" × 4.26" × 1.38")
Packaging Dimensions (W×L×H)	Packing box: 303mm × 262mm × 72mm (11.92" ×10.31" × 2.83") Protective box: 549mm × 325mm × 397mm (21.61" ×12.80" × 15.63")
package	10 devices in one package
Certifications	CE: EN60950; FCC
