Ceiling wired PIR detector - Dual technology - Quad element sensor and 24Ghz microwave

Ceiling wired PIR detector - Dual technology - Quad element sensor and 24Ghz microwave
-35%

AXPRO HIKVISION

DS-PDCL12DT-EG2 Hikvision Indoor PIR ceiling detector with dual technology - 24Ghz microwave and quad element sensor - 12m detection range - 12 detection zones - Status and operation LED indicators - High quality product.


 ALREADY SEEN IT? IT'S ON PROMO! --> DS-PD2-P12QE-C


Reference: DS-PDCL12DT-EG2

Brand: Hikvision

EAN: 6931847157593

Manufacturer Object ( [id] => 42 [name] => Hikvision [description] =>

Since the year of its birth, its prestige has grown so much that in 2015 it will become the first global reality in security.

From 2016 Hikvision expands its market becoming Total Solution Provider for the entire security market. Thus it enters the world of intrusion detection and then approaches new technologies and intelligence at the service of mankind by dealing with IoT, Machine Vision, Robotics and Automotive systems. From security leader, Hikvision becomes with commitment, passion and competence a Hi-Tech company with a vision 4.0, always aiming high.

Setik is therefore honored to be a Hikvision distributor. We will, as always, offer the latest generation products and the appropriate technical and commercial support.

[short_description] =>

Videosorveglianza Hikvision

Hikvision was founded in 2001 with the aim of creating and developing complete professional video surveillance solutions, quickly becoming a leader in the security world.

[id_address] => [date_add] => 2020-03-26 09:28:09 [date_upd] => 2024-06-06 12:13:26 [link_rewrite] => hikvision [meta_title] => Security Hikvision [meta_keywords] => Hikvision, Security Hikvision [meta_description] => Hikvision was founded in 2001 and soon became a leader in the world of video surveillance. Discover now the products in the catalogue! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


HIKVISION: NET PRICES×


THIS PRODUCT IS ONLINE AT A SPECIAL PRICE!
Check out the other products that are part of the promotion! Prices valid until 30.04.2025
Netti Hikvision

ALARM HIKVISION×


  SPECIAL DISCOUNTS AND FREE SHIPPING!
DS-PWA64-Kit-WE |  DS-PWA96-M2H-WE  |  DS-PWA96-Kit-WE
 Take advantage now >>

CLEARANCE SALE ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

AXPro Alarms Hikvision

Hikvision AXPro Alarms

DS-PDCL12DT-EG2 | AX PRO HIKVISION CEILING PIR SENSOR - MICROWAVE 24GHZ - QUAD ELEMENT SENSOR

AX Pro Hikvision Indoor PIR ceiling detector, with dual technology: Microwave with 24ghz frequency and quad element sensor - LED operating indicator (Green for PIR, Red for Microwave, Blue for alarm) - Detection range 12m - 172 zones detection - For indoor ceiling application

DS-PDCL12-EG2-WE

DS-PDCL12DT-EG2 - HIKVISION


Main features

- Ceiling sensor with dual technology
- Microwave 24Gh
- Quad element sensor
- Detection range 12m
- 172 detection zones
- Status LED indicator:
- Operating temperature: -10 °C to 55 °C (14 °F to 131 °F)
- Product net weight: 138g
- For ceiling application
- Ideal for indoor use
- Dimensions: φ120mm×33.2mm
- Mounting height: 2.4 to 4 m

Documentation: Leaflet

Data sheet

DS-PDCL12DT-EG2

Detection Performance

Detection Method

Passive Infrared, Microwave

Detection Range

12m

Detection Angle

360°

Detection Zones

172

Detectable Speed

0.3 to 2m/s

Sensitivity

Auto, Low

White Light Filter

6500lux

Microwave Frequency

24GHz(24.15?24.25GHz)

Digital Temperature Compensation

Support

Creep Zone Protection

Support

Features

digital processing

Support

Sealed Optics

Support

TamperProtection

Front

interface

LED indicator

Green(PIR), Red(Microwave), Blue(Alarm)

electrical characteristics

power consumption

100mA Max

Electrical Characteristics

Power Supply

9 to 16VDC

Typical Voltage

12VDC

General

Operation Temperature

-10°C to 55°C (14°F to 131°F)

Storage Temperatures

-20°C to 60°C (-4°F to 140°F)

Operation Humidity

10% to 90%

Dimension(W×H×D)

φ120mm×33.2mm

Weight

138 g

Mounting Height

2.4 to 4m

Mounting method

Ceiling

Application Scenario

indoors

AXPRO HIKVISION ALARMS VS AJAX ALARMS. Read our blog post!

AXPRO SYSTEM - BEYOND SAFETY

AXPro is the new intelligent and professional wireless system with latest generation "Tri-X" radio technology. It is a complete solution, supports Video Intruder Verification technology and is versatile as it can be integrated with other security systems such as Video Surveillance, Video Intercom and Access Control. It also supports metadata from AcuSense devices and Heat Pro Thermal Cameras. AXPro boasts a simple, intuitive programming interface suitable for both professional audiences and end users.

axpro hikvision alarm system


Intruder Verification

Intruder Verification is the HD video alarm service that manages video verification from any Hikvision IP camera. Provides recording of a 7-second video clip containing pre and post event which is sent from the control panel buffer or via the NVR/IP camera archive. The end user will be able to access the video and live feed of the camera directly from the HikConnect APP.



Simple and intuitive programming

Thanks to the Hik-ProConnect software dedicated to the installer and available both on the portal and in the APP version, system configuration will be extremely simple. The control unit immediately recognizes the radio devices via the Hik-ProConnect APP thanks to the QR Code scan. Manual activities and installation times decidedly optimized. After configuring the detectors and accessories, it will be possible to proceed with programming their parameters and delivering the system to the user.



Management via APP: Hik-ProConnect and Hik-Connect

Hikvision AXPro alarms are compatible with the Hikvision Official APPs Hik-ProConnect , dedicated to installers and Hik-Connect , for end users.

Hik-ProConnect: cloud platform specially designed for installers.
- Time optimization
- Adding devices remotely or on site
- Simplified programming
- Creation of specific rules for the plant
- Remote monitoring of the system
- Identification of any malfunctions and immediate resolution
- Sending automatic reports
- Reduction of plant visits and increased efficiency

Hik-ProConnect: cloud platform specially designed for end users.
- Full management of all Hikvision devices/products
- View system status
- Activation/deactivation of the alarm
- Receive alarm notifications wherever you are
- Monitoring of the status of each individual device [signal level, battery status, ambient temperature]
