Passive PIR + MW Detector Wired for outdoor use - Low Absorption - Anti-masking

Passive PIR + MW Detector Wired for outdoor use - Low Absorption - Anti-masking
-52%

Wired detector for outdoor use with Double Technology PIR + MW, double beam and very low absorption. Anti-masking and anti-opening function . 16 zones, fixing height from 0.8 to 1.2m, selectable alarm outputs NC / NO 0.1A @ 28Vd.c (Max), 12Vdc power supply, Wall or pole mounting. Degree of protection IP55, black body with white cover. GRD VXS-DAM



Reference: GRD VXS-DAM

Brand: Guardian

EAN: 8058258765013

FIND INSTALLER

€251.22

€523.38 -52%
taxes included
Tax included
 Available in 5 days
 starting

PRODUCT NOT AVAILABLE, DISCOUNT NOW 3%



PIR + MW DUAL TECHNOLOGY DETECTOR - OUTDOOR - WIRED - ANTIMASKING

RIVELATORE PASSIVO DA ESTERNO DOPPIO FASCIO DOPPIA TECNOLOGIA ANTIMASCHERAMENTO DA ESTERNO BASSO ASSORBIMENTO

DESCRIPTION:
The VXS-DAM GRD sensor is one of the best wired detectors on the market.

This device is equipped with double PIR + MW technology and double beam with 12m range, 90 ° angle, 16 zones

Product details

  • Passive outdoor detector
  • Double PIW + MW technology
  • Range 12 m 90 ° angle with detection beams adjustable in range.
  • SMDA logic for advanced temperature compensation and immunity to environmental disturbances.
  • Rectangular configuration of the detection area with pre-cut masking stickers.
  • Double conductive shielding of the pyroelement against disturbances caused by bright lights.
  • Active infrared anti-masking function to detect masking with covering objects.
  • Low Absorption
  • Quality product

Data sheet

Model GRD VXS-DAM
Detection method Passive infrared and microwave
PIR detector cover Width m 12 - 90 ° / 16 zones
PIR distance limit From m 2.5 to 12 (5 levels)
Speed detectable 0.3 to 2.0 m / s
Sensitivity 2.0 ° C @ 0.6 m / s
Supply voltage From 9.5 to 18Vdc
Current absorption
(except walk test)
35mA @ 12Vc.c.
Alarm time 2.0 ± 0.1 s.
Warm-up time About 60 s. (LED flashes)
Alarm output Selectable NC (normally closed) / NO (normally open) 0.1A @ 28Vd.c (max.)
Fault output NC (normally closed) 0.1A @ 28Vdc (max)
Tamper output It opens when the front cover or main unit or fixing base is removed
LED indicator Red LED; 1. Heating 2. Alarm 3. Masking detection + yellow LED; 1. Heating 2. Microwave detection DIP switch ON or walk test

DIP switch ON or walk test
Operating temperature -20 ° C to + 45 ° C
Ambient humidity 95% max.
Degree of protection IP55
Fixing positions Wall, pole (indoors)
Fixing height From 0.80 m to 1.20 m
Weight g 450
Accessories 2 x Screws (4x20mm), 3 x Masking Stickers
