Synchronized double beam barrier with built-in alarm buzzer and optical-acoustic alignment, available in black. Offers a range of 30 meters outdoors and 60 meters indoors. Equipped with alarm relay (NO/NC) for security, local alarm, signaling and automation functions. Detection occurs through the simultaneous interruption of the two infrared beams. IP54 protection rating, ideal for both indoor and outdoor applications . - BX-100PLUS
FIND INSTALLER
https://www.setik.biz/en/sensors/10894-optex-ax-130tn-copy-of-outdoor-double-beam-barrier-wireless-ip54-optex.html
€99.55
€146.40 -32%
taxes included
OUTDOOR DOUBLE BEAM BARRIER WITH WIRE - RANGE OF 30 M
Product details
- Double beam barrier
- Built-in alarm buzzer
- Wireless
- Range 30 m outside, 60 m inside
- Alarm relay (NO/NC)
- Simultaneous interruption of the 2 infrared beams.
- Multi-level area: 2.5 m max
- Detectable speed 50 msec
- Power supply: 10.5 - 28 VDC
- Working temperature: -35°C ~ +55°C
- IP54 protection
- Dimensions: 231 x 52 x 61 mm
Technical data sheet
| Model | BX-100PLUS |
| Coverage | Outdoor: 30m (100 ft.) Indoor: 60m (200 ft.) |
| Maximum Arrival Distance | 300 m (1,000 ft.) |
| Detection Method | Simultaneous interruption of 2 infrared beams |
| Beam Characters | Plused Infrared |
| Interruption Period | 50 msec |
| Power Supply | 10.5 - 28V DC |
| Current Consumption | 55mA (Standby) / 75mA (max) |
| Alarm period | 2 ± 1 sec (Delay) |
| Relay Output | 2 relay outputs NO and NC 28VDC 0.2A (Max) each |
| Beeping Period | 15 ± 1 sec (Delay) |
| Volume of Audible alarm indicator | Approx 70 dB (at 1meter distance) |
| Tamper | NC opens when cover is removed |
| Operation Temperature | -35 °C ~ + 55 °C ( -30°F ~ -131°F) |
| Operating Humidity | 95% (Max) |
| Alignment Angle | ± 92% |
| Mounting | Wall (indoor/outdoor) |
| Operating temperature | -20°C to +50°C (-4°F to +122°F) |
| Weight | 400g (14.1oz.) |
| IP rating | IP54 |
