ONVIF IP NVR - 64 channels - Up to 32MP 8K - Video Analysis and artificial intelligence - Audio - Alarm
Dahua - NVR608RH-64-XI - 64-channel ONVIF IP NVR - Resolution up to 32MP 8K - Smart H.265+ Codec - Bandwidth: 1280Mbps in/1024Mbps out (with AI deactivated) - Artificial intelligence - Video Analysis - Audio - Alarm - SATA for 8HDD up to 16TB (not included) - RAID mode support - eSATA - 4xHDMI - 2xVGA interface - Synchronous playback up to 16 channels - Multi-Brand support - For desktop or rack mounting.
DAHUA: LOSS LEADER×
INCREDIBLE DISCOUNTS
on a selection of DAHUA products
Check out the promo now >>
DAHUA 8X8×
DAHUA 8MEGAPIXEL
8MEGAPIXEL CAMERAS WITH
QUANTITY DISCOUNT AND FREE SHIPPING!
DISCOVER THEM NOW >>
SSD1TB SHOCK PRICE!×
SSD1TB SHOCK PRICE!
Same price as the NON-SSD version!
Only 100 pieces!
Buy now >>
CLEARANCE SALE ×
CLEARANCE SALE!
Take advantage of our must-see outing offers.
Discover the promo >>
64 CHANNEL NVR - IP ONVIF DAHUA - 32MP RESOLUTION - H.265+ - VIDEO ANALYSIS - ARTIFICIAL INTELLIGENCE - 8HDD 16TB - DAHUA - NVR608RH-64-XI
VERSION WITHOUT POE PORTS!

ONVIF IP NVR 64 Channels - Dahua - NVR608RH-64-XI
Up to 32MP - Up to 1280Mbps input / 1280Mbps recording / 1024Mbps output - Video Compression up to H.265+
Audio 1in/2out and Alarm 16in/8out - Supports 8x SATA 16TB HDD (sold separately) - Supports RAID mode - 4x HDMI (Up to 32MP on HDMI3) - 2x VGA (1080p out) - 4xUSB ports (2x2.0 + 2x3 .0) - Hard disks NOT included - 24 months manufacturer's warranty - Power supply: 100–240 VAC, 50/60 Hz - For desktop or rack mounting.

4K TECHNOLOGY - ULTRA HD - WHAT DOES IT MEAN? |
---|
Product details

![]() |
Onvif is the most important standard in the IP world. Being Onvif guarantees a wide range of IP devices compatible with each other (DVRs/cameras). This NVR is ONVIF® compatible |
|
Smart H.265+ Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive coding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure, and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ greatly reduces bit rate and storage requirements compared to standard H.265 compression |
![]() |
64 Channels. Maximum resolution 32MP (2 active channels) Synchronized playback of up to 16 channels BAND: WITH AI ACTIVATED: |
![]() |
New ULTRA HD 4K Technology! The HDMI 3 port has a maximum resolution of 8K 32MP! |
![]() |
Support IP cameras: Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC,
LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet (operation with the models proposed here must be verified on a case-by-case basis) |
![]() |
This video recorder supports some ARTIFICIAL INTELLIGENCE functions
|
![]() |
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS(best CCTV software for Mobile) |
![]() |
Supports 8x 3.5" SATA Audio / Video AV-GP Hard Disks ( Max 16TB each) HARD DRIVE NOT INCLUDED! |
![]() |
This NVR features 4x USB Ports (2 Rear USB3.0, 2 Front USB2.0) |
![]() |
RAID Function: The RAID mode allows the contents of a disk to be replicated on a second disk, thus guaranteeing data reliability in the event of disk failure and continuity of service. |
![]() |
Equipped with 4 HDMI ports. The HDMI 3 port supports 32MP video output |
![]() |
This product features 2x VGA ports with 1080P resolution! |
![]() |
With alarm relay 16 inputs + 8 outputs for burglar alarms or other instruments and to activate external peripherals (gates, sirens, etc.) |
![]() |
This DVR features 1 bi-directional RCA audio input and 2 outputs |
![]() |
Dynamic DNS: allows you to reach the NVR even in the case of a Dynamic IP |
![]() |
Ability to overwrite the disk when it is full or have the disk overwrite after X days. NVR restart programming to ensure greater stability over time |
![]() |
This NVR has email sending. In case of events (camera blurring, signal cutting, motion, broken disk, network problems etc...), it is able to send a report via email, a sound notification or upload videos & screenshots via FTP |
![]() |
Motion function. Recording starts when the camera detects movement. |
![]() |
This product is covered by a 24 month manufacturer's warranty |
Data sheet
NVR608RH-64-XI | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
System |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Main Processor |
Industrial-grade processor |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System |
Embedded Linux |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Interface |
Web, Local GUI |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
TO THE |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI by Recorder |
Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI by Camera |
Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; object monitoring |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AcuPick AI by Camera + Recorder |
Max. 64-channel, 1 combined event per channel/s |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Protection |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Performance AI by Recorder (Number of Channels) |
Simultaneous mode: 32 channels, 10 IVS rules for each channel Heterogeneous mode: 24 channels, 10 IVS rules for each channel |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Performance of AI by Camera (Number of Channels) |
64 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Attributes |
Gender; age group; glasses; expressions; face mask; beard |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection Performance of AI by Recorder (Number of Channels) |
Simultaneous mode: 8 channels (up to 12 face images/s each channel) Heterogeneous mode: 5 channels (up to 12 face images/s each channel) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection Performance of AI by Camera (Number of Channels) |
64 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Database Capacity |
Up to 40 face databases with 300,000 images, with a total capacity of 48 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition Performance of AI by Recorder (Number of Channels) |
Simultaneous mode: 32-channel FD (by camera) + FR (by recorder), image stream: 32 face images/s; 8-channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s Heterogeneous mode: 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s; 5-channel FD (by recorder) + FR (by recorder), video stream: 10 face images/s |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition Performance of AI by Camera (Number of Channels) |
64 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SMD Plus |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SMD Plus by Recorder |
32-channel: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SMD Plus by Camera |
64 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Metadata |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Metadata Performance of AI by Recorder (Number of Channels) |
8 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Metadata Performance of AI by Camera (Number of Channels) |
64 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
People Attributes |
9 human body attributes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Human Attributes |
Top color, top type, hat, bag, age, gender and umbrella |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motor Vehicle Attributes |
License plate, plate color, vehicle model, vehicle logo, plate color, ornament, calling, |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Non-motor Vehicle Attributes |
Vehicle model, vehicle color, number of persons, helmet. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Vehicle License Plate Comparison |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ANPR by Camera (Number of Channels) |
64 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
License Plate Database Capacity |
Blocklist and allowlist: 20,000 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio and Video |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Access Channel |
64 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Bandwidth |
AI disabled: 1280 Mbps incoming, 1280 Mbps recording and 1024 Mbps outgoing AI enabled: 640 Mbps incoming, 640 Mbps recording and 512 Mbps outgoing |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
32MP; 24MP; 16MP; 12MP; 8MP; 5MP; 4MP; 1080p; 720p; Q1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Decoding Capability |
AI disabled: 2-channel 32 MP@30 fps; 2-channel 24MP@30fps; 4-channel 16MP@30fps; 5-channel 12MP@30fps; 8-channel 8MP@30fps; 12-channel 5MP@30fps; 16-channel 4MP@30fps; 32-channel 1080p@30 fps?64-channel D1@30 fps AI enabled: 1-channel 32 MP@30 fps; 1-channel 24MP@30fps; 2-channel 16MP@30fps; 2-channel 12MP@30fps; 4-channel 8MP@30fps; 6-channel 5MP@30fps; 8-channel 4MP@30fps; 16-channel 1080p@30fps? 64-channel D1@30fps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Output |
2 VGA, 4 HDMI; VGA: 1920×1080, 1280×1024, 1280×720; HDMI1&2: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI3: 7680×4320, 3840×2160, 1920×1080, 1280×1024, 1280×720; HDMI4: 1920 × 1080, 1280 × 1024, 1280 × 720 Simultaneous mode: max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1 and HDMI2 is 4K; max. resolution of HDMI3 is 8K; max. resolution of HDMI4 is 1080p Heterogeneous mode: Simultaneous video source output for VGA1 and HDMI1, simultaneous video source output for VGA2 and HDMI2. Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1, HDMI2 and HDMI3 is 4K; max. resolution of HDMI4 is 1080p |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multi-screen Display |
Main screen: 1/4/8/9/16/25/36/64 Sub screen: 1/4/8/9/16/25/36 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Third-party Camera Access |
ONVIF; RTSP; Sony; Axis; Arecont; Pelco; Canon; Samsung |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression Standard |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression |
Smart H.265+; H.265; Smart H.264+; H.264; MPEG4; MJPEG |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression |
G.711a; G.711u; PCM; G726 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol |
HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; ISCSI |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mobile Phone Access |
iOS; Android |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability |
ONVIF (Profile S/profile T/Profile G); CGI; SDK |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browsers |
Chrome IE 9 or later Firefox |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Mode |
Multi-address mode, load balance, fault tolerance and other network port binding modes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Recording Playback |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multi-channel Playback |
Up to 16 channels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Record Mode |
Manual; alarm; motion detection; scheduled |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Backup Method |
Portable hard drive, eSATA disk, burner, USB device and network |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Playback Mode |
Download the English brochure
|
