copy of Hyundai NVR 8 channels IP 4K 8MP - 8 POE ports - 80/80 Mbps

Product details

	This NVR provides compression standards up to H.265+ H.265+: What are the advantages? - Savings of up to 90% on bandwidth - Reduction of storage space - Longer recording times on analog surveillance systems with the same storage space.
	8 IP channels with resolution up to 4K/8 Megapixel!
	Possibility of management and viewing from Smartphone "P2P installation", via Hyundai HYU-connect application (iOs and Android). Network configuration via free cloud (www.hdcvi.hyundai-security.es - Manageable from the HYUVMS App).
	Supports 1x SATA Hard Disk up to 8TB ATTENTION: on NVR systems use specific audio/video discs. For more information, read our dedicated article . HARD DRIVE NOT INCLUDED
	This NVR features 1x HDMI port (up to 4K) and 1x VGA port (1080P)
	This NVR features 2x USB Ports (2x 2.0)
	This NVR features 1 self-adaptive RJ45 port (10/100M)
	1 input + 1 RCA output

Data sheet

• Inputs/Outputs:

  • 8 IP camera inputs
  • Two-way audio: 1 RCA input / 1 RCA output
  • Simultaneous HDMI (4K) and VGA (1080P) video outputs
  • Connections: 2 USB 2.0
  • 8 PoE ports (10/100Mbps, 802.3af/at)

• Compression & Resolution:

  • H.265+, H.265, H.264+, H.264 compression format
  • Recording resolution: 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
  • Decoding capacity: 6 channels 1080P (30 fps), 3 channels 4MP (30 fps), 1 channel 8MP (30 fps)

• Bandwidth:

  • Incoming bandwidth: 80 Mbps
  • Outgoing bandwidth: 80 Mbps

• Storage:

  • Supports 1 SATA HDD up to 8TB (HDD not included)

• Playback & Detection:

  • 8-channel synchronized playback
  • Motion detection 2.0 with 4-channel classification for people and vehicles
  • Smart search

• Network:

  • Ethernet RJ45 (10/100M) self-adaptive network interface
  • Network protocols: TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
  • Up to 32 remote connections

• Power & Consumption:

  • Power supply: 48 V DC, 1.88 A
  • Power consumption: ≤10 W (without HDD/PoE)
  • 75W PoE delivery

• Environmental:

  • Operating temperature: -10°C ~ +55°C
  • Relative humidity: 10~90%

• Physical:

  • Dimensions: 320 (L) x 48 (H) x 240 mm
  • Weight: ≤1kg
  • Desktop installation
