copy of IP NVR 16 Channels Onvif 32MP AI Network Recorder 512Mbps 2U 8HDDs WizSense - Dahua

-57%

Dahua Professional PoE ONVIF IP NVR NVR5816H-XI XI WizSense Series 16 Channel Recorder with resolution up to 32MP . Smart H.265+, Up to 512Mbps bandwidth in/record/out. Artificial Intelligence : Face detection and recognition, perimeter protection, SMD plus, Video metadata, ANPR, stereo analysis, heat map, people counting. 2U Up to 8HDDs (20TB - not included), 1 audio input/2 output, 16 alarm inputs/8 outputs, 2xHDMI, 2x VGA, 2x USB 2.0, 2x USB 3.0, 1x RS232, 1x RS485. Supports rack or desktop mounting.

Reference: NVR5864H-XI

Brand: Dahua

EAN: 6923172502032

FIND INSTALLER

https://www.setik.biz/en/recording-devices/10323-dahua-nvr5864h-xi-copy-of-ip-nvr-16-channels-onvif-32mp-ai-network-recorder-512mbps-2u-8hdds-wizsense-dahua.html

€1,638.33

€3,810.06 -57%

taxes included

ARE YOU A PROFESSIONAL OF THE SECTOR?
REGISTER TO ACCESS YOUR LIST

PRODUCT NOT AVAILABLE, DISCOUNT NOW 3%

LO HAI TROVATO A MENO?

Scrivici dove e ti sconteremo la differenza fino a fine mese!

Description Product Details Technical Data Sheet Further Details Download

16-CHANNEL NVR ONVIF® IP DAHUA - XI SERIES ARTIFICIAL INTELLIGENCE - UP TO 32 MEGAPIXELS

IP Nvr 16 Channels Onvif - New XI AI Series - Dahua
Up to 32MP resolution - 512Mbps maximum bandwidth - Video compression up to H.265+
Output 2x HDMI - 2x VGA - 4x USB - Audio and Alarm - 2U Up to 8HDDs SATA III 3.5"
Artificial Intelligence: Face detection and recognition, perimeter protection, SMD plus, metadata, ANPR, stereo analysis, heat map, people counting, Video metadata

Tecnologia WizSense

WIZSENSE TECHNOLOGY:
Launched by Dahua Technology, WizSense is a series of broad-based AI products and solutions that adopt independent AI chip and deep learning algorithm. It can recognize human and vehicle in an image with high accuracy, allowing users to focus on real targets. Powered by Dahua's advanced technology, WizSense makes your videos smart, simple and inclusive.

Intelligent refers to WizSense based on AI chip and deep learning algorithm. It provides various features that realize accurate alerts for people and vehicles, as well as rapid target search, maximizing resources to increase overall efficiency.
Simple means that WizSense offers simple setup, especially for SMD Plus which can be enabled with just one button. It makes customers' daily work easier and also empowers them to make better business decisions.
WizSense inclusiveness is the idea that everyone gains opportunities and benefits from artificial intelligence. With affordable pricing and easy setup of Dahua WizSense, AI is no longer limited to the ivory tower, but is instead applied to real-world scenarios.

Product details

NVR 16 Canali fino a 32MP - Serie XI AI - Dahua

Dahua XI series

Dahua's NVR5000-XI series offers advanced recording technology and features AI capabilities making it ideal for IP video surveillance. It features a powerful processor with powerful decoding capabilities that offers high bandwidth access, incoming and outgoing, forwarding and strong decoding capabilities that together produce unobstructed streams and access video up to 32MP . Thanks to Dahua's advanced deep learning algorithms and video metadata technology, the NVR offers:

- High precision facial recognition
- Video metadata
- Perimeter protection
- SMD Plus [8 channels]

These features reduce event response time

AcuPick is an industry-leading and highly precise search technology.

When the NVR with AcuPick compatible IP cameras, uses the lens characteristics to search for videos in which uses the lens characteristics to search for videos in which the lens appears.

The NVR is compatible with many third-party devices, making it a great surveillance solution

Data sheet

Model: DVR	NVR5816H-XI
SYSTEM
Main Processor	Industrial-grade processor
Operating System	Embedded Linux
Operating Interface	Web, Local GUI
TO THE
AI by Recorder	Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD
AI by Camera	Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD; stereo analysis, crowd distribution; people counting; ANPR; heat maps; PPE detection
AcuPick AI by Camera + Recorder	Max. 16-channel, 1 combined event per channels
PERIMETER PROTECTION
Perimeter Performance AI by Recorder (Number of Channels)	16 channels, 10 IVS rules for each channel
Perimeter Performance of AI by Camera (Number of Channels)	All channels (32 targets/s)
FACE DETECTION
Face Attributes	6 attributes
Face Detection Performance of AI by Recorder (Number of Channels)	Sub screen 4K enabled：4 channels (up to 12 face images/s each channel) Sub screen 4K disabled：8 channels (up to 12 face images/s each channel)
Face Detection Performance of AI by Camera (Number of Channels)	16 channels
FACE RECOGNITION
Face Database Capacity	Up to 20 face databases with 2,000,00 images, with a total capacity of 44 G.
Face Recognition Performance of AI by Recorder (Number of Channels)	Sub screen 4K enabled: 16-channel FD (by camera) + FR (by recorder), image stream: 32 face images/s 4-channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s Sub screen 4K disabled: 16-channel FD (by camera) + FR (by recorder), image stream: 32 face images/s 8-channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s
Face Recognition Performance of AI by Camera (Number of Channels)	16 channels
SMD PLUS
SMD Plus by Recorder	16 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
SMD Plus by Camera	All channels (64 targets/s)
VIDEO METADATA
Metadata Performance of AI by Camera (Number of Channels)	8 channels, 23 attributes extraction.
Metadata Performance of AI by Camera (Number of Channels)	16 channels
People Attributes	9 human body attributes
Motor Vehicle Attributes	9 attributes
Non-motor Vehicle Attributes	4 attributes
VEHICLE LICENSE PLATE COMPARISON
ANPR by Camera (Number of Channels)	All channels (32 targets/s)
License Plate Database Capacity	1. Create up to 20,000 plate numbers. 2. Blocklist and allowlist
AUDIO AND VIDEO
Access Channel	16 channels
Network Bandwidth	AI disabled: 512 Mbps incoming, 512 Mbps recording and 512 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
Resolution	32MP; 24MP; 16MP; 12MP; 8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 960p; 720p; D1; CIF; QCIF
Decoding Capability	AI disabled: 2-channel 32 MP@30fps; 2-channel 24MP@30fps; 4-channel 16MP@30fps; 5-channel 12MP@30fps;8- channel 8 MP@30 fps; 10-channel 6MP@30fps; 12-channel 5 MP@30 fps;16-channel 4 MP@30 fps AI enabled: 1-channel 32 MP@30 fps; 1-channel 24MP@30fps; 2-channel 16MP@30fps; 4-channel 12 MP@30 fps;6- channel 8 MP@30 fps; 8-channel 6MP@30fps; 8-channel 5MP@30fps; 12-channel 4MP@30fps; 16-channel 1080p@30fps
Video Output	2 VGA, 2 HDMI VGA:1920×1080, 1280×1024, 1280×720 HDMI:3840×2160, 1920×1080, 1280×1024, 1280×720 Heterogeneous video source output for HDMI1 and HDMI2 Simultaneous video source output for VGA1 and HDMI1 Simultaneous video source output for VGA2 and HDMI2
Multi-screen Display	Main screen: 1/4/8/9/16/25/36 Sub screens: 1/4/8/9/16
Third-party Camera Access	ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha
STANDARD COMPRESSION
Video Compression	Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
Audio Compression	G.711a; G.711u; PCM; G726
NETWORK
Network Protocol	HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.); ISCSI
Mobile Phone Access	iOS; Android
Interoperability	ONVIF 23.06(Profile T; Profile S; Profile G); CGI; SDK
Browsers	Chrome; Firefox; IE
RECORDING PLAYBACK
Multi-channel Playback	Up to 16 channels
Record Mode	General, motion detection; intelligent; alarm; POS
Backup Method	USB device and network
Playback Mode	Instant playback; general playback; event playback; tag playback; smart playback
STORAGE
Disk Group	Yes
RAID	RAID 0/1/5/6/10
Hot Swapping	Yes
ALARM
General Alarm	Motion detection; local alarm; alarm box; camera external alarm; network alarm; scene changing; PIR alarm; thermal alarm
Anomaly Alarm	Error (no disk, disk error, low space, RAID exception, low quota space; abnormal disk health; network disconnection; IP conflict; MAC conflict; abnormal fan speed); video loss; video tampering; offline camera; audio detection
Intelligent Alarm	Face detection; face recognition; video metadata (human, motor vehicle, and non-motor vehicle); perimeter protection; license plate comparison
Alarm Linkage	Record; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzers; log, preset; e-mail
PORT
Audio Input	1-channel RCA
Audio Output	2-channel RCA
Alarm Input	16 channels
Alarm Output	8 channels (1-channel 12V 1A output）
HDD Interface	8 SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature.
eSATA	1
RS-232	1
RS-485	2 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication)
USB	4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports)
HDMI	2
VGA	2
Network Port	2(10/100/1000 Mbps Ethernet port, RJ-45)
GENERAL
Power Supply	100–240 VAC, 50-60 Hz
Power Consumption	<13W (without HDD)
Net Weight	7.48 kg (19.38 lb)
Gross Weight	10.2 kg (26.06 lb)
Product Dimensions	440.0 mm × 459.6 mm x 95.0 mm (17.32" × 18.09" × 3.74") (W ×D × H)
Packaging Dimensions	570.0 mm × 570.0 mm x 226.0 mm (22.44" × 22.44" × 8.90") (W ×D × H)
Operating Temperature	–10 °C to +55 °C (14 °F to +131 °F)
Storage Temperatures	–20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity	10%–93% (RH)
Installation	Rack or desktop
CERTIFICATIONS
Certifications	Class A CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014

Further details

	This IP NVR recorder has 16 channels for connecting IP cameras Recording resolution up to 32Megapixel Up to 512Mbps bandwidth
	Smart H.265+ Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive coding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure, and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ greatly reduces bit rate and storage requirements compared to standard H.265 compression
	This NVR supports ONVIF® 23.06 standard
	ANPR \| Automatic car license plate recognition Ideal for income and expense management. Compatible with Dahua ANPR cameras , integrates black/white list functions, data import/export, addition/deletion of license plate numbers in the lists, search results from a recorded video.
	Possibility of connecting POS devices, obtaining all the information superimposed on the channel. Possibility of pos search by date or transaction
	Supports 8x 3.5" SATA III hard disks up to 20 TB each (hard disks not included) ATTENTION: on NVR systems use specific audio/video discs. For more information, read our dedicated article .
	This NVR has 4 USB ports (2x rear USB3.0, 2x front 2.0)
	2x HDMI and 2x VGA port
	With alarm relay 16 inputs and 8 outputs for inputs from burglar alarms or other instruments and to activate external peripherals (gates, sirens, etc.)
	This NVR features 1 RCA audio input and 2 outputs
	Dynamic DNS: allows you to reach the NVR even in the case of a Dynamic IP
	Ability to overwrite the disk when it is full or have the disk overwrite after X days. NVR restart programming to ensure greater stability over time
	This NVR has email sending. In case of events (camera blurring, signal cutting, motion, broken disk, network problems etc...), it is able to send a report via email, a sound notification or upload videos & screenshots via FTP
	Motion function. Recording starts when the camera detects movement.
	1x RJ-45 (10/100/1000 Mbps)
	RS 485 for PTZ Commands (Remotely Controlled Cameras)
	RS 232 to communicate with PC and keyboard
	This product is covered by a 24 month warranty.
