copy of NVR IP 16 Channels H.265 4K 8MP 200Mbps 8HDD Dahua

-57% New

Dahua Professional IP NVR NVR4816-4KS2 IP recorder for 4K Ultra HD 16 Channel IP ONVIF surveillance , resolution up to 8MP. Video Compression H.265, Up to 200Mbps input bandwidth, 3 USB, VGA / HDMI (4K) , up to 8 HDD SATA Audio / Video 3.5 ", Video Analysis , ANR, Cloud P2P. Alarm / Audio.

Reference: NVR4816-EI

Brand: Dahua

FIND INSTALLER

https://www.setik.biz/en/recording-devices/10311-dahua-nvr4816-ei-copy-of-nvr-ip-16-channels-h265-4k-8mp-200mbps-8hdd-dahua.html

€823.62

€1,915.40 -57%

taxes included

ARE YOU A PROFESSIONAL OF THE SECTOR?
REGISTER TO ACCESS YOUR LIST

LO HAI TROVATO A MENO?

Scrivici dove e ti sconteremo la differenza fino a fine mese!

OFFICIAL AJAX DISTRIBUTORS! ×

BUY AJAX!
Free shipping >€49
SPED-AJAX-E

Description Product Details Data Sheet Further Details Download

NVR 16 IP CHANNELS - 4K ULTRA HD - 8HDD - 200MBPS - UP TO 8 MP - ALARM - AUDIO - DAHUA

Nvr IP 16 Channels - Dahua
Up to 8MP - Up to 200Mbps broadband input - Compression up to H.265 +
Up to 8 HDDs (not included) - Video Analysis - Audio / Alarm - ANR - 3 USB - VGA / HDMI (4K)

Dahua Lite Series: The advantage of 4K and H.265 at a really affordable price!

4K TECHNOLOGY - ULTRA HD - WHAT DOES IT MEAN?
4K technology (also called ULTRA HD ) is one of the latest innovations in the field of high definition vision. 4K correspond to the resolution of 4 Full-HD, so 3840 X 2160! Already used in the consumer electronics sector, it is finally arriving in the world of security. The new generation of DAHUA equipment, in fact, allows the support of cameras up to 12MPX on H265 standard, the new video compression that allows you to save up to 50% compared to the previous H264. Thanks to the 4K output it is also possible to view (on a 4K monitor) the image in its maximum detail.

4K TECHNOLOGY - ULTRA HD - WHAT DOES IT MEAN?

4K Ultra HD technology 4K technology (also called ULTRA HD ) is one of the latest innovations in the field of high definition vision. 4K correspond to the resolution of 4 Full-HD, so 3840 X 2160!
Already used in the consumer electronics sector, it is finally arriving in the world of security. The new generation of DAHUA equipment, in fact, allows the support of cameras up to 12MPX on H265 standard, the new video compression that allows you to save up to 50% compared to the previous H264. Thanks to the 4K output it is also possible to view (on a 4K monitor) the image in its maximum detail.

Product details

NVR 16 Canali fino a 8MP - Serie 4K Ultra HD - Dahua

	All Onvif , the absolute standard for IP cameras, being Onvif guarantees compatibility with any modern recording system. NOT being Onvif, it means having a camera for its own sake that can never be used together with recording systems This NVR supports ONVIF® 2.4 standard
	Smart H.265 + Smart H.265 + is the optimized implementation of the H.265 codec which uses a scene adaptive coding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction useful for delivering high quality video without straining the network. Smart H.265 + greatly reduces bit rate and storage requirements compared to standard H.265 compression
	New ULTRA HD 4K Technology ! Even higher resolution than FULL-HD! More detail available, greater sense of depth and realism.
	This IP NVR recorder has 16 Channels for connecting IP cameras Recording resolution up to 8Mp / 6Mp / 5MP / 4MP / 3MP / 1080P / 1.3MP / 720P Up to 200Mbps broadband inbound
	This video recorder supports some functions of Video Analysis: - Heat map - Line crossing - Intrusion - People counting
	Multiple network monitoring: Web viewer, CMS (DSS / PSS) & DMSS (best CCTV software for Mobile)
	ANR (Automatic Network Replenishment). This feature allows you to archive locally when the network is temporarily unavailable or congested. Normally in case of events of this type, the NVR stops recording, this type of NVR instead compensates for this problem. The NRA also manages the information flow to the NVR thus avoiding network congestion
	Supports IP cameras: Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and many more ... (operation with the models proposed here is to be verified from case to case)
	Supports 8x 3.5 " AV-GP SATA Audio / Video Hard Disk ( Max 6TB each) It also works without a hard disk even remotely! ATTENTION: use specific audio / video discs on NVR systems. For more information, read our dedicated article . HARD DISK NOT INCLUDED!
	This product features 1x HDMI port The HDMI1 port achieves a resolution of 4K ULTRA-HD
	With alarm relay 16 INPUTS and 4 ALARM OUTPUTS Useful for connecting burglar alarms or other instruments and for activating external peripherals (gates, sirens, etc.)
	This DVR has 1 Audio IN and 1 Audio OUT RCA
	Dynamic DNS: allows to reach the NVR even in case of Dynamic IP
	Ability to have the disk overwrite when full or have the disk overwrite after X days. NVR restart programming to ensure greater stability over time
	This NVR has email sending. In case of events (camera obfuscation, signal cut, motion, broken disk, network problems etc ...), it is able to send an email report, a sound notification or upload videos & screenshots via FTP
	Motion function. The recording starts when the camera detects motion.
	2x RJ-45
	This product is covered by a 24 month warranty.

Data sheet

Model: DVR	NVR4816-4KS2
SYSTEM
Main Processor	Quad-core embedded processor
Operating System	Embedded LINUX
VIDEO & AUDIO
IP Camera Input	16 channel
Two-way talk	1 Channel Input, 1 Channel Output, RCA
DISPLAY
Interface	1 HDMI, 1 VGA
Resolution	HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Decoding Capacity	2ch @ 4K 30fps, 8ch @ 1080P 30fps
Multi-screen Display	1/4/8/9/16
OSD	Camera title, Time, Camera lock, Motion detection, Recording
RECORDING
Compression	Smart H.265 + / H.265 / Smart H.264 + / H.264
Resolution	8Mp / 6Mp / 5MP / 4MP / 3MP / 1080P / 1.3MP / 720P etc.
Recording Rate	200Mbps
Bit Rate	16Kbps ~ 20Mbps Per Channel
Recording Mode	Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop
Recording Interval	1 ~ 120 min (default: 60 min) Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
VIDEO DETECTION & ALARM
Trigger Events	Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips
Video Detection	Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering
Alarm Input	16 Channel
Relay Output	4 Channel
PLAYBACK & BACKUP
Playback Channel	1/4/9/16
Search Mode	Time / Date, MD and Exact Search (accurate to second), Smart search
Playback Function	Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom
Backup Mode	USB Device / Network
Third-party Support
Third-party Support	Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more
NETWORK
Ethernet	2 RJ-45 Ports
PoE	N / A
Network Functions	HTTP, HTTPS, TCP / IP, IPv4 / IPv6, UPnP, RTSP, UDP, SMTP, NTP, DNS, IP Filter, DDNS, FTP, SNMP, IP Search (Support Dahua IP camera, DVR, NVS, etc.)
Max User Access	128 users
Smart Phone	iPhone, iPad, Android
Interoperability	ONVIF® 2.4, SDK, CGI
STORAGE
Internal HDD	8 SATA III Ports, Up to 6 TB capacity for each HDD
HDD Mode	Single
AUXILIARY INTERFACE
Usb Interface	3 ports (2 USB2.0, 1 USB3.0)
RS232	1 Port, for PC Communication and Keyboard
RS485	1 Port, for PTZ Control
ELECTRICAL
Power Supply	AC100V ~ 240V, 50 ~ 60Hz
Power Consumption
ENVIRONMENTAL
Working Environment	-10 ° C ~ + 55 ° C (+ 14 ° F ~ + 131 ° F), 86 ~ 106kpa
Storage Conditions	-20 ° C ~ + 70 ° C (-4 ° F ~ + 158 ° F), 0 ~ 90% RH
CONSTRUCTION
Dimensions	2U, 440mm × 450.1mm × 95mm (17.3 "x 17.7" x3.7 ")
Net Weight	5.2kg (11.5 lb) (without HDD)
Gross Weight	9.5kg (20.9 lb) (without HDD)
CERTIFICATIONS
THERE IS	EN55032, EN55024, EN50130-4, EN60950-1
FCC	Part 15 Subpart B, ANSI C63.4-2014
UL	UL60950-1
