RFID PROXIMITY READER - FOR MIFARE 13,56MHZ 125KHZ CARDS - ID EM CARD - WITH TOUCH KEYPAD AND PC CONNECTION - IP55 - DAHUA - ASI1201A-D
|
DESCRIPTION: Extremely reliable product. |
Product details
- Waterproof RFID Reader - Dahua Security
- Useful for access control with MIFARE 13.56Mhz/125khz card RFID reader, ID EM Card
- Numeric touch keyboard with blue backlighting
- Communication: TCP/IP (RJ45 10/100M), RS485, Wiegand
- Identification through RFID Cards, Code or combination
- Compatible Mifare 13.56Mhz / 125khz cards (Range 3-8cm (max.))
- 32Bit processor, 16M memory
- Door time out alarm, intrusion alarm, duress alarm and tamper alarm
- Fast card read/response times (<0.1s)
- Inputs: 1 door sensor, 1 exit button, 2 alarm inputs
- Output: 3 relays (doors, tone, alarm)
- Capacity up to 30,000 users, 150,000 events
- Watchdog Analysis Function
- User hierarchy: General, VIP, Guest, Patrol, Black list
- Power supply: 9-15DC/200mA
- Dimensions: 97mm*16mm*150mm
- Weight: 0.3Kg
- IP55 protection
- Operating temperature: -5°C~+55°C
Data sheet
| ASI1201A-D | |
|
Technical Specification |
|
|
System |
|
|
Main Processor |
32 Bits |
|
Memory |
16M |
|
Input/Output Ports |
|
|
Input |
Door sensor x 1, Exit button x 1, Alarm input x 1 |
|
Outputs |
Relay :Door lock×1 TTL: Bell×1, Alarm×2 |
|
Readers |
Reader x 1 |
|
Card Read |
|
|
Read Format |
13.56MHz(Mifare)/125KHz - EM ID |
|
Read Range |
3-8cm (max.) |
|
Response Time |
<0.1s |
|
Capacity |
|
|
cardholders |
30,000 |
|
Events |
150,000 |
|
Function |
|
|
User Management |
General, VIP, Guest, Patrol, Blacklist, Duress |
|
Alarm Function |
Door time out alarm, Intrusion alarm, Duress alarm, Tamper alarm |
|
Period Setting. |
Support 128 groups of schedules, 128 groups of periods and 128 groups of holiday periods |
|
interface |
|
|
To PC |
RJ45(10/100M) |
|
To Reader |
Wiegand/RS485 |
|
General |
|
|
RTC extension |
Yes |
|
Voice prompts |
No |
|
Beep Tone |
Buzzers |
|
Keyboard |
Sensitive touch keypad with blue backlight |
|
Power Supply |
9-15DC/200mA |
|
Working Environment |
-5°C~+55°C |
|
Working Humidity |
≤95% |
|
Dimension(W×D×H) |
97mm*16mm*150mm |
|
Weight |
0.3Kg |
Further details
 |
This terminal is STANDALONE . This means that it is autonomous, able to manage functions without having to integrate other devices. |
 |
32BIT processor |
|
|
Standalone RFID reader with touch keyboard and identification via:
- Combination - 13.56MHz format card (Mifare)
|
  |
Communication via TCP/IP (RJ45 100M), RS485 or Wiegand26/34 |
|
|
Up to 30,000 user files , 150,000 events!!! |
 |
Smart features: - Intrusion alarm, door time out alarm, tampering alarm |
 |
Watchdog function for analyzing device anomalies |
 |
This product is covered by a 24 month guarantee. |
