The TP-Link Omada SX6632YF is a high-performance Layer 3 managed switch , ideal for enterprises and data centers that require ultra-fast connections and advanced management . Equipped with 32 10G SFP+ ports and 2 100G QSFP28 ports , it offers high bandwidth, intelligent switching and advanced security . Integrated with Omada SDN , it supports web-based cloud management and Omada app for optimal remote control.
FIND INSTALLER
SWITCH 26 PORTS 10G & 6 SLOT 25G MANAGED L3 - TPLINK OMADA
The TP-Link Omada SX6632YF is a Layer 3 managed switch designed for enterprises, data centers and corporate networks that require high performance, reliability and advanced management. With 26 10G SFP+ slots and 6 25G SFP28 slots, it offers ultra-fast bandwidth, perfect for data-intensive environments.
With a switching capacity of 820 Gbps, it ensures smooth and bottleneck-free transmissions, while physical stacking allows for redundancy and scalability, improving network performance and business continuity.
Advanced Layer 3 features, including RIP, OSPF, ECMP, VRRP, PIM-DM, and DHCP Server/Relay, provide intelligent traffic management and a more flexible and efficient network infrastructure. For security, it supports ACL, Port Security, DoS Defend, and 802.1X authentication, protecting your network from threats and unauthorized access.
Designed for maximum reliability, the switch integrates two field-replaceable power supplies, VRRP and ERPS, ensuring a stable and redundant network even in the event of hardware failures.
Management is simplified through integration with Omada SDN, which enables centralized cloud control via web and Omada app. For those who prefer local management, the switch offers advanced options via web interface, CLI, SNMP and RMON.
Main features:
- Ultra-fast connectivity: 26x 10G SFP+ slots and 6x 25G SFP28 slots for high performance and 820Gbps switching capacity for smooth, bottleneck-free traffic
- Scalability and redundancy : Physical stacking for improved performance and network redundancy, maximum reliability with 2 field-replaceable power supplies, and VRRP and ERPS support for business continuity and automatic failover.
- Layer 3 Advanced Features : Support for RIP, OSPF, ECMP, VRRP, PIM-DM for dynamic traffic management and DHCP Server/Relay for efficient IP assignment in large networks
- Maximum security and network protection : ACL (Access Control List) for advanced traffic control and Port Security, DoS Defend and 802.1X authentication to prevent unauthorized access
- Smart and Centralized Management: Integration with Omada SDN for cloud management and advanced monitoring and standalone management via Web, CLI, SNMP and RMON for maximum flexibility
- Ideal for Enterprises and Data Centers: Perfect for high-density networks, enterprises and high-traffic environments with high scalability and reliability for a secure and high-performance network infrastructure
Technical data sheet
| Model | SX6632YF |
| HARDWARE FEATURES | |
| Interface | 6× 10/25G SFP28 Slots 26× 10G SFP+ Slots 2× USB 3.0 Ports 1× RJ45 Console Port 1× USB Type C Console Port 1× RJ45 Management Port |
| Number of fans | Four field-replaceable and hot-swappable fans |
| Physical security lock | √ |
| Diet | Two field-replaceable and hot-swappable redundant power supplies (100–240 VAC, 50/60 Hz) *Ships with one PSM550-AC module by default, and another field-replaceable redundant power supply requires a separate purchase. |
| Energy consumption | 86.7W (110V/60Hz) |
| Dimensions (L x W x H) | 17.3 × 15.0 × 1.7 in (440 × 380 × 44 mm) |
| Mounting type | Rack Mountable |
| Max Power Consumption | 295.85 BTU/hr (110V/60Hz) |
| PERFORMANCES | |
| Switching capacity | 820 Gbps |
| Stacking | Stacking Number: 8 Stacking Port: 25G SFP28 Stack Bandwidth: Up to 300 Gbps (6 stack ports) |
| Packet Forwarding Rate | 610.1 Mpps |
| ARP Table | 128K |
| Buffers (packets) | 8 MB |
| Jumbo frame | 9 KB |
| SOFTWARE FEATURES | |
| QoS (Quality of Service) | Class of Service 8 Priority Queues Port Priority IEEE 802.1p Priority DSCP Priority Queue Min-Bandwidth Schedule Mode (SP, WRR, SP+WRR) Bandwidth Control Rate Limit Strom Control User Defined OUI Smoother Performance Action for Flows QoS remark (802.1P Remark, DSCP Remark) |
| L2 and L2+ functionality |
Link Aggregation |
| Advanced Features | Automatic Device Discovery Batch Configuration Batch Firmware Upgrading Intelligent Network Monitoring Abnormal Event Warnings Unified Configuration Reboot Schedule ISP Features 802.3ah Ethernet Link OAM L2PT (Layer 2 Protocol Tunneling) Device Link Detect Protocol (DLDP) DDM sFlow PPPoE ID Insertion |
| VLAN | VLAN Group (802.1q VLAN) Max 4K VLAN Groups 802.1Q Tagged VLAN MAC VLAN entries: 200 Multicast VLAN VLAN Management VLAN VPN (QinQ): Max 256 entries GVRP Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries VLAN-VPN VLAN Mapping VLANReplace VoiceVLAN Private VLAN |
| Safety | Port Isolation CPU Defend ARP Inspection (Dynamic ARP Inspection) DoS Defense IP-MAC-Port Binding 1,024 Entries DHCP Snooping ARP Inspection IPv4 Source Guard IPv6 MAC Port Binding 1,024 Entries DHCPv6 Snooping ND Detection ND Snooping IPv6 Source Guard DHCP Filter Static/Dynamic Port Security Up to 64 MAC addresses per port Broadcast/Multicast/Unknown-unicast Storm Control kbps/ratio control mode 802.1X Port base authentication Mac basic authentication VLAN Assignment MAB GuestVLAN Support RADIUS authentication and accountability AAA (including TACACS+) Secure web management through HTTPS with SSLv3/TLS 1.2 Secure Command Line Interface (CLI) management with SSHv2 IP/Port/MAC based access control |
| MANAGEMENT | |
| Omada App |
Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | Omada Cloud-Based Controller Omada Hardware Controller Omada Software Controller |
| Cloud Access | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.n |
| Zero Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller. |
| Management Features | Web-based GUI Command Line Interface (CLI) through console port, telnet SNMPv1/v2c/v3 Trap/Inform RMON (1, 2, 3, 9 groups) SDM-Template DHCP/BOOTP Client 802.1ab LLDP/LLDP-MED DHCP Auto Install Dual Image, Dual Configuration CPU Monitoring Cable Diagnostics Password Recovery SNTP System Log |
| OTHER | |
| Package Contents |
SX6632YF Switch |
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
| Environment | Operating Temperature: 5 °C to 50 °C (23 °F to 122 °F) @ 300 meters 5 °C to 45 °C (23 °F to 113 °F) @ 2,000 meters 5 °C to 40 °C (23 °F to 104 °F) @ 3,000 meters Storage Temperature: -40 °C to 70 ℃ (-40 ℉ to 158 ℉) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing |
|
Functionality |
|
|
High-speed Connections and Powerful Stacking |
|
|
Advanced Layer 3 Features |
|
| Maximum Reliability
Internal redundant power supplies and VRRP make it the ideal choice for a reliable network architecture. ERPS supports rapid protection and recovery in a ring topology. |
|
|
Advanced Security |
|
|
Omada SDN
|
|
|
3 year warranty The following product is covered by a 3 year warranty |
|
