iiyama VA 4k UHD 50 inch 40-point touch screen monitor

iiyama VA 4k UHD 50 inch 40-point touch screen monitor
New

The ProLite TF5039AS-B1AG is a 50" Touchscreen monitor with 4K UHD resolution and 40-point capacitive touchscreen technology (PCAP) . Continuous 24/7 operation . VA screen, Anti-glare (AG Coating) and IP54 protection, Edge-to-edge glass design, Open Frame. Typical contrast 5000:1, 16.7 million 8-bit colors, 9.5ms response time. 1 Display Port, 2 HDMI. 2 10W stereo speakers, USB Touch Interface. VESA 400x400. Matte black color.



Reference: TF5039AS-B1AG

Brand: IIYAMA

EAN: 4948570123889

FIND INSTALLER

€2,293.60

taxes included
Tax included
 Available in 5 days

PRODUCT NOT AVAILABLE, DISCOUNT NOW 3%



Description Details Data sheet Information Download

50" IIYAMA PROLITE MONITOR WITH 40-POINT CAPACITIVE TOUCHSCREEN DISPLAY - IP65 PROTECTION - 4K UHD RESOLUTION - BLACK

Made by IIYAMA


Monitor 50" VA - IIYAMA TOUCHSCREEN
Size: 50" - VA display, AG Coated Glass - Capacitive touchscreen - Scratch resistant - Touch Through glass technology - 1x DiplayPort - 2x HDMI - USB Touch Interface - HDCP - MiniJack (x1) - 2x10W stereo speakers - Compatible with 24/7 continuous operation - 9.5ms response time - 1x RS232c - 1x RJ45 LAN - 3mm glass thickness, 3H hardness - Multilingual OSD - Metal frame - Face-up operation - Matt black color - Weight: 28.6Kg - 3 Years Direct Manufacturer's Warranty

Product details

50 inch touchscreen monitor

  • 50" VA Monitor - IIYAMA
  • Type: VA, AG Coated Glass
  • Aspect ratio: 16:9
  • 50 inch capacitive touchscreen display - 40-point PCAP
  • Scratch resistant
  • Resolution 3840 x 2160 @60Hz (8.3 megapixel 4K UHD)
  • 1x DISPLAY PORT - 2x HDMI
  • Response time 9.5 ms
  • USB Touch Interface
  • Static Contrast Ratio: 5000:1
  • VESA 400x400 mount support
  • 1x RS232c
  • 1x RJ45 LAN
  • 8-bit color, 16.7 million colors
  • 1x Mini Jack
  • 2x 10W Stereo Speakers
  • HDCP
  • Metal frame
  • Designed for 24/7 continuous operation
  • Dimensions: 1149.4 x 670 x 64mm
  • Weight: 28.6Kg
  • Color: Black, Matte

Technical data sheet

Model TF5039AS-B1AG
DISPLAY CHARACTERISTICS
Design Edge to edge glass, Open Frame
Diagonal 49.5", 125.7cm
Panel VA, AG coated glass, matte finish
Native resolution 3840 x 2160 @60Hz (8.3 megapixels 4K UHD)
Aspect ratio 16:9
Brightness Panel 500 cd/m²
Brightness 435 cd/m² with touch
Light transmittance 87%
Static contrast 5000:1
Response time (GTG) 9.5ms
Viewing areas horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
Colour support 1.07G (8 Bits+FRC) (72% NTSC)
Horizontal Sync 28 - 160kHz
Viewable area W x H 1095.8 x 616.4mm, 43.2 x 24.3"
Bezel width (sides, top, bottom) 24mm, 24mm, 24mm
Pixel pitch 0.285mm
Colour black, matte
TOUCH
Touch technology PCAP bonded
Touchpoints 40
Touch Accuracy +- 2.5mm
Touch method stylus, finger, glove (latex)
Touch interface USB
Supported operating systems All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Through Glass 6mm
Palm rejection yes
INTERFACES / CONNECTORS / CONTROLS
Digital signal input

HDMI x2 (2.0, max. 3840x2160 @60Hz)
DisplayPort x1 (v.1.2 max. 3840x2160 @60Hz)

Audio input Mini jack x1
Monitor control input

RS-232c x1 (Get/Set Command)
RJ45 (LAN) x1 (Control and Internet)

Audio Output Mini jack x1
Speakers 2 x 10W
HDCP Yes
USB ports x2 (2.0 x2 (Type A))
FEATURES
Integrated software Android 11 OS, iiSignage², EShare, FailOver
Hardware CPU: A73*4+A53*4, GPU: G52 MP8, RAM: 4GB, ROM: 32GB
Extra handles, Touch Through-Glass
Kiosk mode yes
Max. non-stop operating time 24/7
Anti-image retention Yes
Glass thickness 3mm
Glass Hardness 3H
60950 Ball drop test yes
Water and dust protection IP65 (front)
Housing (bezel) metal
OSD key lock yes
Remote control lock yes
GENERAL
OSD languages EN, DE, FR, ES, IT, RU, CZ, NL, PL, SV, FI, DA, NB
Control buttons power
User controls picture (brightness, contrast, sharpness, back level, tint, colour, noise reduction, gamma selection, low blue light, color temp., color control, overscan, picture reset), screen (zoom mode, custom zoom, screen reset), audio (balance, treble, bass, volume, audio out (line out), max. volume, min. volume, mute, audio reset, audio out sync, speaker setting), configuration 1 (Android launcher, switch on state, Touch lock, Touch mode, mouse mode, panel saving, RS232 routing, boot on source, WOL, conf.1 reset, factory reset), configuration 2 (OSD timeout, OSD H position, OSD V position, system rotation, OSD info, logo and animation, logo setting, animation setting, monitor ID, monitor info, HDMI version, conf. 2 reset), advanced options (kiosk mode, side bar, no signal image, motorized stand, IR control, power LED light, fan, off timer, schedule, HDMI with one wire, HDMI with one wire off, failover, language, OSD transparency, power saving, advanced options reset)
Plug&Play DDC2B
MECHANICAL
Orientation landscape, portrait, face up
VESA mounting 400 x 400 mm
Mini PC Mount VESA 100 x 100, INTEL NUC
Operating temperature range 0°C - 40°C
Storage temperature range - 20°C - 60°C
MTBF 50000 hours (excluding backlight)
ACCESSORIES INCLUDED
Cables power (1.8m), USB (1.8m), HDMI (1.8m), DP (1.8m)
Guides quick start guide, safety guide
Cable cover yes
Remote control yes (batteries included)
POWER MANAGEMENT
Power Supply Unit internal
Power Supply AC 100 - 240V, 50/60Hz
Power Usage 137W typical, 0.5W stand by, 0.3W off mode
SUSTAINABILITY
Regulations CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA, cTUVus
Energy efficiency class (Regulation (EU) 2017/1369) F
Other above 0.1%: Lead
DIMENSIONS & WEIGHT
Product dimensions W x H x D 1149.4 x 670 x 64mm
Box dimensions W x H x D 1297 x 798 x 174mm
Weight (without box) 28.6kg
Weight (with box) 35.9kg

Further details

Display VA

VA monitor.

VA display, TOUCHSCREEN, 50 ".
High quality images.

Risoluzione 2.0 Megapixel Full-HD 1920x1080

New ULTRA HD 4K Technology (3840 x 2160)
Even higher resolution than FULL-HD!
More detail available, greater sense of depth and realism.

Risoluzione FULL HD 1920x1080 Monitor E2280HS-B1


Android OS

Thanks to the Android operating system, you can easily customize the display to suit your needs by installing applications directly on it.

Projective capacitive touchscreen


iiSignage²

iiSignage² is our content management platform for digital signage, which can be used to easily view and control content and securely manage iiyama displays. The content management system (CMS) gives you complete control of your messages and advertising, which you can manage remotely, easily and securely.

Projective capacitive touchscreen


Signal Failover

FailOver is a feature that automatically detects input sources. If there is no signal at the default input, the device automatically switches to the closest available input. FailOver allows the customer to prioritize a number of inputs (including browser, media player and Custom) and ensures that their content is always actively displayed.

failover signal bunner.jpg

Touch through glass

The back-window or through-glass function makes glass surfaces an interactive display. For back-window use, real estate agencies, POS, and restaurants.

touch through glass bunner.jpg

Touch through glass

Transform small meeting rooms into clean collaboration spaces using built-in applications such as Android OS, EShare and Whiteboard, a selection of intuitive and practical tools installed on our PCAP interactive touchscreens. With the Android operating system, you can easily customize the display by installing applications directly on it. With the EShare app, you can share, broadcast and edit content from any device directly on the screen and transform your team meetings into an easy, fast and seamless interactive session.

Huddle Spaces.jpg

Commercial Installations

Interactive 4K touchscreens are the key to immersive interactive experiences for retail design. Allow customers to explore your website right there and then or interact with a range of creative or experiential applications you wish to host. The flexibility to use in landscape or portrait modes with 24/7 operation. Android and MediaPlayer make the series displays one of the most adaptable touchscreen solutions available.

Commercial Installations.jpg

2 Speakers stereo 1W

Stereo Speakers

The monitor is equipped with 2 x 10W Speakers (Stereo). High quality sound in stereo format!

2 Speakers di qualità E2280HS-B1

Questo DVR presenta 1 porta HDMI
DisplayPort port

This product features HDMI ports (2x), DisplayPort 1x

Display resistente ai graffi

Scratch Resistant - IP65 Level Protection (Front)

Scratch resistance is essential for touch solutions used in public places and schools. This is achieved by a glass plate that covers the screen. It ensures a long life of the touch function and, more importantly, the touch function remains unchanged even if the glass is scratched.


USB Touch Interface
This model is equipped with an RJ45 LAN PORT and an RS232C port, for multilingual OSD menu control.
Attacco vesa

VESA mount

VESA mount compatibility means you can easily mount the LFD to any VESA-compatible mount.

For this product, the VESA dimensions are 600x400mm.

This product features a fast response time for refreshing images displayed on the screen, equal to 9.5ms .
Garanzia diretta fornitore 3 anni

This product is covered by a 3 YEAR DIRECT manufacturer's warranty .

Download

Download the English Brochure

All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
