ELED VA Professional Monitor 4K UHD 43" Inch WiFi iiSignage² Android

LH3260HS-B2AG

DISPLAY CHARACTERISTICS

Design

Thin bezel

Diagonal

42.5", 108cm

Panel

VA, AG coated glass, matte finish, hard coating (3H), haze 25%

Native resolution

3840 x 2160 @60Hz (8.3 MegaPixels 4K UHD)

Aspect ratio

16:9

Panel brightness

500 cd/m²

Static contrast

4000:1

Response time (GTG)

6.5ms

Viewing areas

horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°

Colour support

1.07G (8 Bits+FRC) (NTSC 87%)

Horizontal Sync

28 - 160kHz

Viewable area W x H

941.2 x 529.4mm, 37.1 x 20.8"

Bezel width (sides, top, bottom)

9mm, 9mm, 9mm

Pixel pitch

0.245mm

Bezel color and finish

black, matte

INTERFACES / CONNECTORS / CONTROLS

Digital signal input

HDMI x3 (v.2.0, max. 3840x2160 @60Hz)

Monitor control input

RS-232c x1
RJ45 (LAN) x1

Audio output

Mini-jack x1 (3.5mm)
Speakers 2 x 10W

HDCP

v.1.4 & 2.2

USB ports

x2 (v.2.0)

FEATURES

Integrated software

Android 11 OS, iiSignage2 (available soon), FailOver, EShare

WiFi

yes (Built-in, 802.11ac)

Hardware

CPU: A53*4, GPU: G52 MP2, RAM: 2GB, ROM: 16GB

Extra

Wall mounting kit included (VESA 400x300mm)

Max. non-stop operating time

24/7

Anti-image retention

yes

Media playback

yes

Housing (bezel)

plastic

GENERAL

OSD languages

EN, DE, FR, ES, IT, CN, RU, JP, CZ, NL, PL

Control buttons

Power button, Power Indicator, Remote Sensor

User controls

picture (brightness, contrast, sharpness, black level, tint, colour, noise reduction, gamma selection, color temperature, color control, over scan, picture reset), screen (H. position, V. position, clock, clock phase, zoom mode, custom zoom, auto adjust, screen reset), Audio (balance, treble, bass, volume, audio out, maximum volume, minimum volume, mute, audio source, audio reset, audio out sync, speaker setting), configuration 1 (switch on state, panel saving, RS232-routing, boot on source, WOL, configuration 1 reset, factory reset), Configuration 2 (OSD timeout, OSD H-Position, OSD V-position, rotation, information OSD, logo and animation logo setting, animation setting, monitor ID, group ID, monitor information, DP version, DP monitors, HDMI version, configuration 2 reset), advanced option (IR control, power LED light, keyboard control, tiling, off timer, schedule, HDMI with one wire, HDMI with one wire power off, FailOver, language, OSD transparency, power saving, advanced option reset), Android settings (network & internet, apps & notifications, display, signage display, security, language & input, date & time, about device)

Plug&Play

DDC2B

MECHANICAL

Orientation

landscape, portrait

Fanless design

yes

VESA mounting

400 x 300mm

Operating temperature range

0°C - 40°C

Storage temperature range

- 20°C - 60°C

MTBF

50,000 hours (excluding backlight)

ACCESSORIES INCLUDED

Cables

power, HDMI, RS-232c

Guides

quick start guide, safety guide

Other

Wall mount bracket, Wall mount guide, Screws, Screw anchors, Stickers for screw holes

Remote control

yes (batteries included)

POWER MANAGEMENT

Power supply unit

internal

Power supply

AC 100 - 240V, 50/60Hz

Power usage

45W typical, 0.5W stand by, 0.3W off mode

SUSTAINABILITY

Regulations

CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA

Energy efficiency class (Regulation (EU) 2017/1369)

AND

DIMENSIONS / WEIGHT

Product dimensions W x H x D

967.4 x 555.9 x 40mm

Box dimensions W x H x D

1075 x 652 x 144mm

Weight (without box)

9.1kg

Weight (with box)

12.7kg
