UR FOG FAST 01 2C Fog-free Antitheft Device, ideal for protecting large spaces. With a single shot it emits up to 1200m3 of thick fog in less than 70 sec. Equipped with 2 cylinders . UR FOG F1M06ITAD
https://www.setik.biz/en/fog-cannons/2595-ur-fog-f1m06itad-Fogging-ur-fog-fast-01-2c-antifurto-.html
€2,748.05
€3,233.00 -15%
taxes included
PRODUCT NOT AVAILABLE, DISCOUNT NOW 3%
HELVETIA-UR FOG PARTNERSHIP: Do you have a business? Discover the benefits you can get from this collaboration! |
ANTI-THEFT NEBBIOGEN FAST 01 2C UR FOG
URFog FAST 01 2C |
Ideal spray system to protect large areas.
Shoot up to 1200 m3 of dense fog in about 70 seconds, it is equipped with two removable bottles of low pressure foggy liquid.
Product details
- Nebbiogeno - UR FOG
- Emission up to 1800m3 of fog (with full cylinders)
- Smoke-like liquid certified as not harmful to health
- 2 F1M06BOM tanks of 600ml each (included)
- Power supply: 220 or 110V
- It meets the standards: CE and EMC
- It meets European standards
- Can also be installed at an angle
- White color
- Dimensions: 30.5x35.0xh43
- Weight: 22kg
Data sheet
| Model | F1M06ITAD |
| WEIGHT OF THE FOG MACHINE | About 22Kg |
| WEIGHT WITH PACKAGING | About 25kg |
| UNITS ON ONE PALLET 100X120 | 12 |
| DIMENSION OF THE MACHINE | 30x35xh43 |
| DIMENSION OF THE PACKAGING | 51x39xh52.5 |
| Colors | white |
| WORKING TIME WITHOUT MAINS POWER | About 2.5 hours |
| HEAT UP TIME FROM COLD | about 2 hours |
| VERTICAL OR CORNER MOUNTING | yes |
| HORIZONTAL MOUNTING | yes |
| SERIAL / USB PORT FOR MONITORING | yes |
| NOZZLE TAMPER | yes |
| SERIAL BUS FOR STANDARD PROTOCOL | yes |
| Fog Generator | |
| NEW HEATING SYSTEM PLUS | yes |
| MAX FOG SINGLE SHOT 1.5 M VISIBILITY | up to 1800 m3 |
| MAX FOG SINGLE SHOT ZERO VISIBILITY | up to 1200 m3 |
| MAX SECONDS OF FOG | 70 sec |
| MAX FOG EMISSION WITH FULL FOG TANK | 1800 m3 |
| NUMBER OF FLUID TANK | 2 |
| FLUID TANK CAPACITY | 2x 600 ml |
| SHOOTING SPECIFICATION | programmable in seconds |
| CYLINDER MODEL | A01 / |
| CYLINDER INCLUDED | 2 |
| DOUBLE FOG TANK ADVANTAGE | YES |
| Electrical Specifications | |
| POWER SUPPLY | 220 OR 110V |
| AVERAGE POWER CONSUMPTION | 60W |
| BACK UP BATTERY | YES |
| OPTIONAL DEMO / ANTIROBBERY KIT | YES |
| WIRED INPUTS ARMING AND SHOOTING | YES |
| WIRED OUTPUTS | YES |
| STANDARD COMMUNICATION PROTOCOL | YES |
| Standards | |
| COMPLIES WITH EUROPEAN CE | YES |
| FOG FLUID IS CERTIFIED | YES |
| MEETS EUROPEAN STANDARD | YES |
More details
 | For operation: |
To operate the fog generator, it is necessary:
- 230V power supply (for the heat exchanger heating system)
- 6 stylus batteries (for cylinder engines)
- 12V power supply for electronic card power supply
It is recommended to supply the 12V via the alarm control panel.
For the connections between the alarm control panel - switches, etc., refer to the installation and use manual.
 | The fastest fog generators in the world |
Up to 1200 m3 in less than 70 seconds. It is impossible to steal what is impossible to see this sentence has a great sense when we mean UR Fog since in a few seconds you can not see anything.
The densest fog
Thanks to the innovative fluid formulation with a high percentage of glycol, it ensures a dense fog that is totally impenetrable to visibility.
Removable tanks
Removable and without need for recharging.
Low energy consumption
The perfect insulation system offers very low energy consumption which saves on costs compared to other spray systems.
Nozzle tamper
Another exclusive, patented and very useful advantage that automatically detects if the nozzle is tampered with and sends an alert signal
Smart bus standart protocol
A unique serial bus to connect to the electronic card an additional card that allows the machine to be easily interfaced with alarms and control the nebulization system even remotely. A standard protocol for all machines.
Innovative technology and performance
UR FOG misting systems are innovative in their technology and performance, in order to guarantee maximum protection against theft.
Safe and certified
UR FOG spray systems are certified according to European legislation. The fog fluid is tested and is absolutely safe. They are not dangerous for objects, animals, people and leave no residue.
Accessories
UR-FOG ACCESSORIES:
 | F01STH - Wall bracket for FAST 01 |
| F03STH - Wall bracket for FAST 03 - EASY 03 |
| F02STH - Wall bracket for FAST 02 |
| F23STHPRO - Wall bracket for FAST PRO 02/03 |
 | FELSTH - Ellipse line bracket |
 | FPU4000ST - FAST 4000 PUMP PRO PLUS bracket |
 | FPUM - PUMP 4000 handle |
 | F23PRUG7 - 7CM Nozzle Extension |
 | F1MO3UG3 - 3-hole nozzle |
 | F23KITD - Demo Kit for FAST 01/02 and FAST / FAST PRO |
 | URTR - Remote control with receiver |
 | URT - Additional remote control |
 | F! 23KEY - Armament key |
 | F23KITA - Anti- theft cable |
 | F23PA - Anti- theft button |
 | URRS232 - rs232 5 / 12V transceiver |
 | URRE - Relay Card |
 | URCL - Cloud Lan card |
 | F1SO4PS - Power supply |
 | F1M04BATT - Battery 2Ah |
Download
No brochures available
WHO IS UR FOG?
UR Fog is one of the most solid Italian companies in the fog systems market.
The UR FOG team is made up of professionals and engineers with over 20 years of experience in both new product development and distribution management worldwide. From 2012 to date they have obtained several patents, created new technologies such as single and double cylinder technology, born at the very beginning of the activity and introduced important innovations such as the adjustable nozzle.
One of the strengths of this company and thanks to which they are often chosen, is the speed of ejection fog, a critical aspect for the products of many other competing brands.
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification
fill out this form
