WIRED INPUT AND OUTPUT MODULE - 16 INPUTS & 4 OUTPUTS - RJ-45 10/100 Mbps - POE - ARM9A4-P-W2-868
Product details
- Wired Input and Output Module - Dahua - ARM9A4-P-W2-868
- 16 NC-NO inputs
- 4 relay outputs
- Wireless range 1600m
- Power supply 230 VAC/PoE
- Auxiliary power supply 12V 2A (at 230 VAC) / 12V 0.75A (in PoE)
- 7Ah buffer battery
- Dimensions: 304mm × 235mm × 90.8mm
- Product net weight: 1.22 kg
- For indoor use
- Operating temperature: –10 °C to +55 °C
- Average battery life: 5 years
Technical data sheet
| ARM9A4-P-W2-868 | |
|
Port |
|
|
Alarm Input |
Supports local 16-channel alarm input, 1 to 6 channels support pulse detection, and 1 to 16 channels support 0EOL/EOL/2EOL/3EOL |
|
AlarmOutput |
Supports 4 lcoal channels(Max 30 VDC, 3A) |
|
Network Mode |
Ethernet |
|
Network Port |
1 × RJ-45 10/100Mbps Ethernet port; PoE power supply |
|
StorageBattery |
Supports lead-acid battery with 12 V and 7 AH |
|
Auxiliary Power Output |
2 built-in auxiliary output, 14.5V, total 1 A (PoE), 2 A (Non PoE) |
|
Function |
|
|
Indicator Light |
One indicator (indicator status) |
|
Button |
1 × switch button, 1 × reset button |
|
Remote Update |
Supports cloud updates |
|
Low Battery Detection |
Yes |
|
Tamper |
Yes |
|
Measuring Range (Temperature) |
–10 °C to +55 °C (+14 °F to +131 °F) (indoor) |
|
Technical |
|
|
LED Indicator |
1 × indicator |
|
Scenario |
Indoors |
|
Wireless |
|
| Carrier Frequency | 868MHz |
| Transmitter Power (EIRP) | limit 25mW |
| Communication Mechanism | Two way |
| Communication Distance | RF: Up to 1,600 m (5249.34 ft) in an open space |
| Encryption Mode | AES128 |
| Frequency Hopping | Yes |
| General | |
| Power Supply | 100-240 VAC, PoE (802.3at), battery |
| Power Supply Type | Type A |
| Standby Time | Static standby: Up to 30 hrs (@7 AH storage battery） |
| Low Battery Threshold | 11,000 mV |
| Battery Restore Threshold | 12,000 mV |
| Power Consumption | 220 VAC quiescent current (40 mA Irms) 220 VAC max current@2Aload + charge (315 mA Irms) POE quiescent current (125mA) POE max current@1Aload + charge (612 mA) Battery quiescent current (70 mA@13.8 V) Battery max current@2Aload (2.08A@13.8V) |
| Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Operating Humidity | 10%–90% |
| Product Dimensions | 304 mm × 235 mm × 90.8 mm (11.97" × 9.25" × 3.57") |
| Net Weight | 1.22 kg (2.69 lb), without battery |
| Gross Weight | 1.78 kg (3.92 lb), without battery |
| Installation | Wall mount |
| Casing Material | PC + ABS |
| Appearance Color | White |
| Protection | IP30 |
| Certifications | THERE IS |
| Anti-corrosion Level | Basic Protection |
| Storage Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Storage Humidity | 10%–90% |
| Packaging Dimensions | Standalone packaging: 269 mm × 14 0 mm × 280 mm (10.59" × 0.55" × 11.02") (L × W × H) Protective case packaging: 585 mm × 443 mm × 399 mm (23.03" × 17.44" × 15.71") (L × W × H) |
