Dahua TPC-BF5601-B35-DC-S2 ONVIF PoE IP Camera - S2 Version - Outdoor/Indoor Thermal Camera with 640(H)x512(V) resolution, Uncooled VOx sensor with 35mm fixed lens - H.265, Artificial intelligence with fire alarm and perimeter protection - 512GB MicroSD slot (not included), Heat detection, People and Moving Vehicles , Audio, Alarm, RS485, CVBS analogue BNC video output - IP67 protection for outdoor environments - For video surveillance systems.
FIND INSTALLER
DAHUA IP CAMERA THERMAL CAMERA ONVIF® POE - 35MM LENS - ARTIFICIAL INTELLIGENCE AND FIRE ALARM - AUDIO - ALARM - TPC-BF5601-B35-DC-S2 - S2 VERSION
Thermal IP Bullet Camera - S2 Version - Dahua - TPC-BF5601-B35-DC-S2
Resolution 640x512 - Uncooled VOx Microbolometer sensor - 35mm fixed lens - NETD 35mk - H.265 compression -
Artificial Intelligence with Fire Detection and Perimeter Protection - 512GB MicroSD Slot (not included) - CVBS Video Output on BNC Port - RS-485 - RJ45 Ethernet 10/100Base T - Audio 1in/1out / Alarm 2in/2out - Heat Detection, People and Moving Vehicles, Hot/Cold Spot Tracking - IP67 Protection Rating - 24 Month Manufacturer's Warranty - Ideal for Video Surveillance Systems.
| THERMAL DETECTION |
|---|
|
Product details
- ONVIF® PoE Bullet Thermal IP Camera - TPC-BF5601-B35-DC-S2
- S2 Version
- Resolution 640x512
- Uncooled VOx Sensor
- 35mm fixed lens
- Visual spectrum from 8 to 14?m
- Thermal Sensitivity: 35mK
- Compression up to H.265 and Dual Stream video
- Detection of People (1458 meters) and Mobile Vehicles (4487 meters)
- Advanced intelligent functions (Fire detection and alarm, Cold/hot spot tracking, Human/vehicle classification)
- ROI, Motion Detection
- 1 CVBS/BNC Video Output
- Audio: 1 input and 1 output
- Alarm: 2 inputs and 2 outputs
- RS-485 port
- RJ45 10/100 Base-T Ethernet LAN network port
- MicroSD slot (Max 512GB - not included, sold separately)
- Power supply 12V DC/PoE/ePoE
- Power supply NOT included
- Dimensions: 291mm × 103mm × 97mm
- Net weight of the item: 1.4Kg
- Bracket included
- Operating temperature: -30°C ~ +70°C
- IP67 outdoor protection
- Lightning protection 6kV
- 24 month manufacturer's warranty
Technical data sheet
| TPC-BF5601-B35-DC-S2 |
Uncooled vanadium oxide focal plane sensor |
Effective pixels: 640 x 512 |
Pixel size: 12 µm |
Thermal sensitivity (NETD): ≤35 mK (@f/1.0) |
Spectral range: 8 ~14 µm |
Focal length: 35 mm |
Angle of view: 12.5°(H), 10°(V) |
Effective distance in people: |
Detection: 1458 meters |
Recognition: 375 meters |
Identification: 187 meters |
Effective distance on vehicles: |
Detection: 4487 meters |
Reconnaissance: 1100 meters |
Identification: 555 meters |
Digital Detail Enhancement (DDE) |
Automatic and manual gain control |
2D/3D-NR noise reduction |
18 color palettes |
H.265, H.264, MJPEG video compression |
Stream 1: 1280x1024 (default), 720P, VGA (1~50/60 fps) |
Stream 2: VGA default, 320x256 (1~50/60 ips) |
Perimeter protection: Cross line detection, intrusion detection |
Person and vehicle classification |
Heat detection |
Hot/cold spot tracking |
G.711A, G.711Mu, AAC and PCM audio compression |
CVBS/BNC video output |
1 audio input / 1 audio output |
2 alarm inputs / 2 alarm outputs |
RS485 support |
Ethernet: RJ-45 (10/100 Base-T) |
Network protocols: HTTP, HTTPS, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, SNMP, QoS, UPnP, NTP |
Onvif, CGI and Dahua SDK support |
MicroSD card slot up to 512GB (card not included) |
Power supply: 12V DC (±20%) / PoE (802.3af) / ePoE |
Maximum power consumption: 13W (12V) / 14W (PoE) |
Storage temperature from -30°C ~+70°C |
Operating temperature from -30°C ~+70°C |
Relative humidity: ≤95%. |
Lightning proof 6KV |
IP67 protection level |
Dimensions: 103 (W) x 97 (H) x 291 mm |
Net weight: 1.4 kg |
Gross weight: 1.9 kg |
Further details
 | Thermal Camera... what is it? and how to choose it? |
 | Onvif, the absolute standard for IP cameras. Being Onvif guarantees compatibility with any modern recording system. NOT being Onvif, means having a camera that is an end in itself that can never be used together with recording systems |
 | The advantage of a PoE camera is clear, it can be powered with the same cable with which it communicates without carrying additional power cables and without having to install a separate power system, a PoE camera guarantees constant voltages and simple installation. |
 | This camera is a THERMAL CAMERA .
Visual spectrum from 8 to 14µm
|
| Thermal Sensor:
|
 | This camera has a 35mm fixed lens People Detection:
|
  | This camera features advanced intelligent functions:
|
 | This camera has 1 Video Output (CVBS/BNC) |
 | It is extremely useful to have Inputs/Outputs in a CCTV system to be able to control relays or activate recording following an event. This 2 Input 2 Output Camera |
 | This camera has 1 Audio Input + 1 Audio Output |
 | RS 485 for PTZ Controls (Remotely controllable cameras) |
 | Protection level IP67 (Dust / Immersion) |
 | Possibility to insert Micro SD up to a maximum of 512GB - not included, sold separately |
 | This product is covered by a 24 month warranty. |
