Dahua Thermal Bullet IP Camera FOCAL 25mm-400x300 IA

Dahua Thermal Bullet IP Camera FOCAL 25mm-400x300 IA
-57%

Dahua TPC-BF5401-B25-BM-S2 PoE ONVIF IP camera for outdoor/indoor use with 400(H)x300(V) resolution, Uncooled VOx Microbolometer sensor and 25mm fixed lens. H.265, ROI, Video Analysis and Fire Alarm , MicroSD Slot, People and Mobile Vehicle Detection , BNC/CVBS Video Output, RS-485, Audio, Alarm, IP67 Protection



Reference: TPC-BF5401-B25-BM-S2

Brand: Dahua

FIND INSTALLER

€2,748.38

€6,391.58 -57%
taxes included
Tax included
 Available in 5 days
 starting

LO HAI TROVATO A MENO?

Scrivici dove e ti sconteremo la differenza fino a fine mese!

meno


DAHUA IP CAMERA ONVIF® POE EPOE 25MM THERMAL CAMERA - VIDEO ANALYSIS AND FIRE ALARM

Made by Setik
Thermal IP Bullet Camera - Lite Dahua
Resolution 400(H)x300(V) - Uncooled VOx Microbolometer sensor - 25mm fixed lens - H.265 compression
ROI - Video Analysis - Fire alarm - MicroSD slot - Video output - RS-485 - Audio/Alarm
Detection of people and mobile vehicles - IP67 protection - 24 month warranty
THERMAL DETECTION


Product details

Telecamera Videosorveglianza IP Bullet Termica 25mm
  • ONVIF® PoE Bullet Thermal IP Camera - Dahua Pro Series
  • Resolution 400(H)x300(V)
  • Uncooled VOx Microbolometer sensor
  • 25mm fixed lens
  • Visual spectrum from 8 to 14?m
  • Thermal Sensitivity: 40mK
  • Compression up to H.265
  • Detection of People (up to 735m) and Mobile Vehicles (up to 1634m)
  • Recognition of People (up to 189m) and Mobile Vehicles (up to 420m)
  • Identification of People (up to 95m) and Mobile Vehicles (up to 210m)
  • Integrated Video Analysis ( Crossing, Intrusion)
  • Advanced detection functions: Fire detection and alarm, Hot and cold spot tracking, People and vehicle classification
  • ROI,
  • 1 CVBS/BNC Video Output
  • Audio: 1 input and 1 output
  • Alarm: 2 inputs and 2 outputs
  • RS-485 port
  • MicroSD slot (Max 256GB - not included)
  • 12V DC/PoE/ePoE power supply
  • Power supply NOT included
  • Dimensions 291mm× 103mm× 97mm (11.46" x 4.06" x 3.82")
  • Material: Metal
  • 24 month warranty

Data sheet

Uncooled VOx microbolometer sensor

  • Effective pixels: 400 x 300
  • Pixel size: 17 µm
  • Thermal sensitivity (NETD): 40mK
  • Spectrum range: 8 ~14 µm
  • Focal length (thermal): 25mm
  • Angle of view (thermal): 15.5°(H), 11.6°(V)

Effective distance on people (1.8 mx 0.5 m):

  • Detection: 735 meters
  • Recognition: 189 meters
  • Identification: 95 meters

Effective distance in vehicles (4m x 1.4m):

  • Detection: 1634 meters

  • Recognition: 420 meters

  • Identification: 210 meters

  • 4X digital zoom

  • Brightness and sharpness adjustment

  • Automatic gain control

  • 3D noise reduction

  • ROI

  • 18 color palettes

  • H.265/H.264/MJPEG Compression

Stream 1:

  • 1280x1024, 1280x720, 400x300 (25/30fps)

Stream 2:

  • 640x512, 400x300 (25/30fps)

  • Digital Image Stabilizer (EIS), mirror mode

  • Supports 4-zone video sensor, 4 regions of interest (ROI), and 4-zone privacy mask

  • IVS Detection: Line Crossing Detection, Intrusion Detection

  • Advanced detection functions: Fire detection and alarm, Hot and cold spot trace, Person and vehicle classification

  • Audio compression: G.711A, G.711Mu, AAC, and PCM

  • 1 input / 1 audio output

  • 2 alarm inputs / 2 outputs

  • 1 BNC/CVBS port

  • Support RS485

  • Ethernet RJ-45 (10/100M)

  • Network protocols: IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x

  • Compatible with Onvif (S/G) and API

  • Up to 10/20 users

  • Compatible with IE8, Chrome42, Firefox42 browsers

  • MicroSD card slot up to 256GB (card not included)

  • Power: 12V DC (±20%) / PoE / ePoE

  • Consumption: 13W

  • Storage temperature: -40°C ~ +70°C

  • Operating temperature: -40°C ~+50°C

  • Relative humidity: <95%

  • Lightning-proof 6KV

  • Degree of protection: IP67 metal casing

  • Dimensions: 103 (W) x 97 (H) x 291 mm

  • Weight: 1.5kg

Note: Effective distance values shown are nominal values and should be used as an estimate. Consult with your commercial to know the recommended detection distances with our Vaelsys perimeter system.

Further details

Thermal Camera... what is it? and how to choose it?

Read our article!

Standard ONVIF® Onvif, the absolute standard for IP cameras. Being Onvif guarantees compatibility with any modern recording system. NOT being Onvif means having a camera as an end in itself that can never be used together with recording systems
PoE power supply

The advantage of a PoE camera is evident, it allows it to be powered with the same cable with which it communicates without carrying additional power cables and without having to install a separate power system, a PoE camera guarantees constant voltages and simple installation

This camera is a THERMAL CAMERA .


Sensitivity 40mK

Visual spectrum from 8 to 14µm

Thermal Sensor:
Uncooled VOx Microbolometer

Ottica fissa 3.6mm

This camera has a 25mm fixed lens

  • Detection of People (up to 735m) and Mobile Vehicles (up to 1634m)
  • Recognition of People (up to 189m) and Mobile Vehicles (up to 420m)
  • Identification of People (up to 95m) and Mobile Vehicles (up to 210m)

This camera provides VIDEO ANALYSIS:
- Line crossing
- Intrusion


This camera provides advanced intelligent functions:
- Fire detection and alarm

Funzione ROI This camera is equipped with ROI function.

The images deriving from IP cameras are "compressed", therefore the quality is set during the recording phase. Especially on cameras with very high resolution, it is often necessary to reduce the quality in order to guarantee reduced bandwidth occupation and record a greater number of days or cameras.
The ROI allows you to define areas where you can set higher quality (for example a door, the area where the license plate usually passes, an exit, etc.). In that area I can set a higher quality , thus guaranteeing greater image definition.
Ultra Smart Funzione ROI

This camera has 1 Video Output (CVBS/BNC)

Full HDIt is extremely useful to also have Inputs/Outputs in a CCTV system to be able to control relays or activate a recording following an event
This camera has 2 inputs and 2 outputs
Ingresso Audio This camera has 1 input + 1 audio output
Dual Encoding RS 485 for PTZ Commands (Remotely Controlled Cameras)
Protezione IP67 contro polveri e immersioni Protection level IP67 (Dust / Immersion)

MicroSD Recording

Possibility to insert Micro SD up to a maximum of 256GB - not included

This camera was made of metal

Dual Encoding This product is covered by a 24 month warranty.

Downloads

Not available
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
