Explosion-proof ONVIF® PoE IP Dome Camera - 2.7 mm–13.5 mm - IP68 - IK10 - IR 40m - S2

Explosion-proof ONVIF® PoE IP Dome Camera - 2.7 mm–13.5 mm - IP68 - IK10 - IR 40m - S2
-58%

IPC-HDEW8441R-Z-S2 Dahua AI Outdoor Onvif PoE IP Camera with Artificial Intelligence , explosion-proof - 4MP , 1/3" CMOS sensor, 2.7-13.5mm lens, H.265 - Triple Stream - IR 40m, WDR 120dB - AI: Perimeter Protection, SMD 3.0, Face, Smart Search, People Counting, Heat Map - 256GB microSD slot (not included) , IP68 and IK10 - RJ45 Ethernet - RS-485 - Audio - Alarm - Ideal for outdoor use.



Reference: IPC-HDEW8441R-Z-S2

Brand: Dahua

FIND INSTALLER

€1,389.12

€3,307.42 -58%
taxes included
Tax included
 Available in 5 days
 starting

LO HAI TROVATO A MENO?

Scrivici dove e ti sconteremo la differenza fino a fine mese!

meno


EXTERNAL EXPLOSION-PROOF ONVIF® POE IP CAMERA - 4MEGAPIXEL - 2.7-13.5MM - ARTIFICIAL INTELLIGENCE - AUDIO - ALARM - DAHUA - IPC-HDEW8441R-Z-S2

Dahua
Explosion-proof Outdoor ONVIF® PoE IP Camera - Dahua AI Series - IPC-HDEW8441R-Z-S2
Resolution 4Megapixel - Varifocal optics 2.7 mm–13.5 mm - CMOS 1/3" 4MP - IR 40M - WDR 120dB - ROI, Day/Night (ICR, BLC, HLC, 3DNR, EIS, Defog - RJ45 Ethernet - RS-485 - Slot MicroSD 256GB (not included) - AI: Perimeter Protection, SMD 3.0, Face, Smart Search, People Counting - Audio 1in/1out - Alarm 3in/2out - In 316L stainless steel - IP68 and Ik10 protection against vandalism - Ideal for outdoors.

Tecnologia Intelligenza Artificiale

AI TECHNOLOGY | ARTIFICIAL INTELLIGENCE:
Artificial intelligence (AI) refers to the branch of science and engineering that produces intelligent machines, especially intelligent computer programs. In the security sector, however, the artificial intelligence used is that which allows the creation of advanced devices for environmental analysis.

Product details

  • ONVIF® PoE External AI IP Camera - Dahua - IPC-HDEW8441R-Z-S2
  • 4Megapixel 4MP resolution
  • Varifocal lens 2.7-13.5mm
  • 1/3" 4MP CMOS sensor
  • Video compression up to H.265
  • Triple Stream
  • WDR 120dB - Defog - EIS - Mirror Mode - Privacy Mask - 3DNR - BLC - HLC
  • IR illuminator with approximately 40m range and 2 lighting LEDs
  • Artificial Intelligence Lite : Perimeter Protection, Intrusion, Line Crossing, People Counting, SMD 3.0, Face Detection, People Counting
  • Audio 1in/1out
  • 3in/2out alarm
  • Micro SD memory slot (Up to 256GB - not included)
  • IP68 protection (indoor / outdoor)
  • Material: 316L stainless steel casing
  • Dimensions: 219.5mm × Φ165mm × 118.2mm
  • Weight: 4.5Kg
  • Operating temperature: T5/T100 °C : –40 °C ≤ Tamb ≤ +60 °C (–40 °F to +140 °F) T6/T80 °C :–40 °C ≤ Tamb ≤ +55 °C (– 40 °F to +131 °F)
  • Power supply NOT included
  • 24 month warranty

Data sheet

IPC-HDEW8441R-Z-S2

Room

Image Sensor

1/3" CMOS

Max.Resolution

2688(H)×1520(V)

ROM

128MB

RAM

1 GB

Scanning System

Progressives

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

0.005 Lux@F1.5 (Color, 30 IRE)
0.0005 Lux@F1.5 (B/W, 30 IRE)
0 lux (Illuminator on)

S/N Ratio

> 56 dB

Illumination Distance

40 m (131.23 ft) (IR LED)

Illuminator On/Off Control

Auto/Manual

Illuminator Number

2 (IR LED)

Pan/Tilt/Rotation Range

Pan: 0°–355°
Tilt: 0°–75°
Rotation: 0°–355°

Lens

Lens Type

Motorized vari-focal

Mount Type

φ14

Focal Length

2.7mm–13.5mm

Max. Openings

F1.5

Field of View

Horizontal: 100.4°–30.2°
Vertical: 56°–16°
Diagonal: 125°–34°

Iris Type

Fixed

Close Focus Distance

0.8 m (2.6 ft)

Smart Events

IVS

Abandoned object; missing object

Intelligence

IVS (Perimeter Protection)

Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection

SMD 3.0

Less false alarm, longer detection distance

Face Detection

Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face extraction attributes including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting.

People Counting

Tripwire people counting, generating and exporting reports (day/month/year); people counting in area; queue management; 4 rules can be set for tripwire, people counting in area and queue management.

Heat Map

Yes

Smart Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)

Smart Codecs

Smart H.265+/Smart H.264+

AI Coding

AI H.265
AI H.264

Video Frame Rate

Main stream: 2688 × 1520 @(1 fps–25/30 fps)
sub stream: 704 × 576@ (1–25 fps)/704 × 480 @ (1–30 fps)
third stream: 1920 × 1080 @ (1–25/30 fps)
The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Stream Capability

3 streams

Resolution

4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280×960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 576/640 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 32kbps–16384kbps
H.265: 32kbps–16384kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

120dB

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Car

Noise Reduction

3D NO

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

Yes (4 areas)

Defog

Yes

Smart Illumination

Yes

Image Rotation

0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)

Mirror

Yes

Privacy Masking

8 areas

Scene Self-adaptation (SSA)

Yes

Image Stabilization

Electronic Image Stabilization (EIS)

Audio

Audio Compression

PCM; G.711a; G.711Mu; G.726; G.723

Alarm

Alarm Event

No SD card; SD card full; SD card error; SD card service life warning (supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missingobject; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; defocus detection; external alarm; face detection; people counting in area; stay alarm; people counting; people No. exception; safety exception

Network

Network

RJ-45 (10/100 Base-T)

SDK and API

Yes

Cyber Security

Video encryption; firmware encryption; configuration encryption; Digests; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade

Protocol

IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP

Interoperability

ONVIF® (Profile S/Profile G/Profile T); CGI; Milestones; Genetec; P2P

User/Host

20 (Total bandwidth: 80M)

Storage

FTP; SFTP; Micro SD card (support max. 256G); NAS

Browsers

IE
Chrome
Firefox

Management Software

Smart PSS, DSS, DMSS

Mobile Phone

iOS; Android

Cyber Security

Configuration encryption; trusted execution; Digests; Security logs; WSSE; account lockout; syslog; Video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certification

Certifications

Certification

CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
ATEX: EN 60079-0/EN 60079-1/EN 60079-31
IECEx : IEC 60079-0/IEC 60079-1/IEC 60079-31
Certificates:
ATEX: TÜV 20 ATEX 8579
IECEx: IECEx TUR 20.0059X

Port

RS-485

1 (baud rate range: 1200 bps–115200 bps)

Audio Input

1 channel (terminal)

Audio Output

1 channel (terminal)

Alarm Input

3 channel in: 5 mA 3 V–5 VDC

Alarm Output

2 channel out: 300 mA 12 VDC

Power

Power Supply

12 VDC/PoE (802.3af)

Power Consumption

Basic: 3.1W (12VDC); 3.6W (PoE)
Max. (H.265+intelligence on +WDR +IR on + auto focus): 6.2 W (12 VDC); 7.3W (PoE)

Environment

Operating Conditions

T5/T100 °C : –40 °C ≤ Tamb ≤ +60 °C (–40 °F to +140 °F)

T6/T80 °C :–40 °C ≤ Tamb ≤ +55 °C (–40 °F to +131 °F)

Operating Humidity

≤95%

Storage Temperatures

–40 °C to +60 °C (–40 °F to + 140 °F)

Protection Grade

IP68; IK10

Storage Humidity

≤95%

Structure

Casing Material

SUS316L (316 stainless steel)

Dimensions

219.5 mm × Φ165 mm × 118.2 mm (8.64" × Φ6.5" × 4.65") (L × W × H)

Net Weight

4.5 kg (9.9 lb)

Gross Weight

5.3 kg (11.7 lb)

Further details

Questo prodotto rispetta lo standard Onvif

All Onvif , the absolute standard for IP cameras, being Onvif guarantees compatibility with any modern recording system. NOT being Onvif means having a camera as an end in itself that can never be used together with recording systems

This camera is ONVIF® compatible

PoE power supply The advantage of a PoE camera is evident, it allows it to be powered with the same cable with which it communicates without carrying additional power cables and without having to install a separate power system, a PoE camera guarantees constant voltages and simple installation

AI | Artificial intelligence
This camera features Artificial Intelligence on board

- Face Capture : Face capture is a software application that automatically captures faces from within a digital image or video frame from a video source . Dahua cameras use advanced deep learning algorithms , trained by a large number of sources that encompass facial data, allowing the camera to quickly and accurately locate faces from the video source and capture facial images.

- Perimeter protection: Intrusion, line crossing (people&vehicle classification)
- SMD 3.0
- People counting
- Face detection
- Smart search

AI Camera - Cattura del volto

Risoluzione 4Mpx 2592x1520

4 Megapixel resolution (2688 × 1520)

Varifocal optics This camera features 2.7-13.5mm varifocal optics.

Main stream: 2688 × 1520 @(1 fps–25/30 fps) 1920 × 1080 @(1 fps–50/60 fps)
Sub stream: 704 × 576 @1 fps–50 fps/704 × 480 @1fps–60 fps
Third stream: 1920 × 1080 @(1 fps–25/30 fps)

Illuminatore IR 40 MT

Infrared illuminator with 2 IR and range up to 40MT for night vision.

ULTRA WDR up to 120dB
WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light/shadow contrast. Fundamental when shooting from inside to outside, license plates, shadowed points or all situations where there is no homogeneity of light.
Icon Day/Night function Day/Night: allows you to adapt the lens to night/day vision, and the related automatic management of the IR Illuminator, when present.
Example Day/Night function
Funzione ROI This camera is equipped with ROI function.

The images deriving from IP cameras are "compressed", therefore the quality is set during the recording phase. Especially on cameras with a very high resolution, it is often necessary to reduce the quality in order to guarantee reduced bandwidth occupation and record a greater number of days or cameras.
The ROI allows you to define areas where you can set higher quality (for example a door, the area where the license plate usually passes, an exit, etc.). In that area I can set a higher quality , thus guaranteeing greater image definition.
Ultra Smart Funzione ROI
Icon Function DEFOG It allows you to clearly see images taken in particular climatic conditions: rain, smoke and fog
DEFOG function example image
DEFOG function example image
This DVR features audio inputs/outputs 1 audio input and 1 audio output.
Alarm Inputs and Outputs 3 inputs and 2 alarm outputs.
IP68 protection against dust and continuous immersion Protection level IP68 (Dust / Continuous immersion)

IK 10 is the highest level of protection against direct damage. This allows the use of the camera even if there are risks of vandalism

MicroSD Recording

Possibility of inserting a Micro SD up to a maximum of 256Gb - not included

Material from which the device was created Explosion-proof product, made of solid 316L stainless steel casing
12V 3A power supply

Power supply NOT included.

Diet:
12 VDC.
12V DC power supply

Italian Guarantee icon This product is covered by a 24 month warranty.

Downloads

Download the English brochure
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
