4MP IP ONVIF Bullet Camera - 2.8mm Lens - Wizsense - Video Analysis

Product details

Data sheet

IPC-HFW3441DG-AS-4G-UAE-B

Room

Image Sensor

1/3" CMOS

Max.Resolution

2688(H)×1520(V)

ROM

128MB

RAM

256MB

- Secondary Human/Vehicle Recognition

SMART SEARCH

This function allows you to obtain various motion videos in a short time by simply drawing an area during playback. Very useful in case he should understand an emergency

This camera provides video compression in H.264 and H.265 format, the new standard for video compression!

This camera has a resolution of 4Megapixel :
4MP (1~25/30fps)

Image sensor 1/3” 4Megapixel progressive scan CMOS 2688x1520 progressive scan

1/3" sensor with STARLIGHT technology.

Low brightness, color vision even in night mode



With this sensor it is possible to have color shots even in night mode.

Normally, when entering night mode, the color vision becomes black/white.

With SENSOR present, night shots will be in color

This camera features a 2.8mm fixed lens. Main stream: 2688 × 1520 @(1–25/30 fps )
sub stream: 704 × 576 @ (1–25fps)/704 × 480 @ (1–30fps)
Sub stream 1: 1920 × 1080 @ (1–25/30 fp

Infrared illuminator with 1 LED and maximum range 50 meters!

1 Warm Light Led up to 30 Meters

This camera is also equipped with SMART IR technology.
Through this technology, the light emitted by the LEDs is adapted according to the object framed.

ULTRA WDR up to 120dB
WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light/shadow contrast. Fundamental in case of shooting from inside to outside, plates, shadowed points or all situations where there is no homogeneity of light.
Day/Night: allows you to adapt the lens to night/day vision, and the relative automatic management of the IR Illuminator, when present.

The IR CUT FILTER is a mechanical filter that allows correct viewing of images in daytime viewing conditions, filtering the typical infrared frequencies, thus improving image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies.

This camera is equipped with ROI function.

The images deriving from IP cameras are "compressed", consequently the quality is set during the recording phase. Especially with cameras with a very high resolution, it is often necessary to reduce the quality in order to guarantee a low bandwidth occupation and to record a larger number of days or cameras.
The ROI allows you to define areas where you can set higher quality (for example a door, the area where the license plate usually passes, an exit, etc.). In that area I can set a higher quality thus guaranteeing a greater definition of the image.
Protection level IP67 ( Dust / Immersion )

This camera has 1 alarm inputs and 1 alarm outputs. 1 RCA audio input channel and 1 RCA audio output channel.

Possibility to insert Micro SD up to a maximum of 256Gb - not included

Power supply NOT included
This product is covered by a 24 month guarantee.
