PTZ85260-HNF-PA-FL - Dahua - IP ONVIF PTZ Laser Positioner - 60x 5.6-336 Optical Zoom - 2MP 1080p Resolution - CMOS 1/1.8" Starlight - Artificial Intelligence : Video Metadata / Perimeter Protection / Face Recognition - Laser with range 1000m - Smart Codec H.265+ - Triple Stream - Day/Night(ICR) - BLC - WDR - BLC - HLC - AWB - AGC - 2D/3DNR - ROI - Defog - Privacy Mask - RS485 RJ45 100M - Bidirectional Audio - Alarm - Event alarm - MicroSD slot up to 512GB (not included) - IP67 protection from outdoors and TVS 6KV against lightning - Body material: ADC12.
FIND INSTALLER
€7,341.78
€17,073.90 -57%LO HAI TROVATO A MENO?
Scrivici dove e ti sconteremo la differenza fino a fine mese!
IP ONVIF® PTZ LASER POSITIONER - OPTICAL ZOOM 60X 5.6-336MM - ARTIFICIAL INTELLIGENCE - AUDIO - ALARM - IP67 - TVS6KV - DAHUA - PTZ85260-HNF-PA-FL
IP ONVIF® PTZ Laser Positioner with Artificial Intelligence - Dahua - PTZ85260-HNF-PA-FL
8 Megapixel - 5.6-336mm lens with 60x optical zoom - STARVIS™ CMOS sensor 1/1.8” with Starlight for 24/7 color viewing - Codec H.265+ Smart - Triple Stream -
Laser distance up to 1000m - HLC - BLC - 2D/3DNR - WDR - AWB - AGC - ROI - Optical Defog - Motion Detection - 16x Digital Zoom - Day/Night(ICR) - Artificial Intelligence : Video Metadata - Facial Recognition - Auto- tracking and perimeter protection - Two-way audio 1in/1out / Alarm 7in/2out - RS485 port - RJ45 LAN 100M - Micro SD slot (Max. 512GB - Not Included) - IP67 protection and TVS 6000V Lightning protection - 24 Months Warranty
Product details
- WizMind Onvif PTZ IP laser positioner - Dahua - PTZ85260-HNF-PA-FL
- 1/1.8" 8 Megapixel STARVIS™ CMOS
- Starlight technology
- 2MP 1920x1080p resolution, progressive scan images!
- Varifocal optics: 5.6-336mm
- Powerful optical zoom: 60x
- Laser illumination with a range of up to 1,000m!
- Artificial Intelligence: Video Metadata - Perimeter Protection - Face Detection
- Triple Stream Video
- H.265+ codecs
- Day/Night (ICR), WDR, BLC, HLC, ROI. 3DNR, AWB, AGC, Privacy Masks, 16x digital zoom
- PFA technology: Greater image clarity
- microSD slot up to 512GB
- Audio: 1 in + 1 out (bidirectional)
- Alarm: 7 inputs + 2 outputs
- Alarm linked to events
- iOS and Android compatible
- Case material: ADC12
- Protection IP67 (Dust / Immersion, for outdoor) and TVS 60000 (Anti Lightning)
- Dimension: 344.6mm × 252.2mm × 499.8mm
- Optimum function operating temperature: –40 °C to +70 °C
- Item net weight: 15.4Kg
- Power Supply: 36VDC, 5A (±25%)
- 24 months warranty
Data sheet
| PTZ85260-HNF-PA-FL | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Room | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor | 1/1.8" CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pixels | 2MP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max.Resolution | 1920(H)×1080(V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ROM | 8GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM | 2GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed | 1/1s–1/30,000s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System | Progressives | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Min Illumination |
All Onvif , the absolute standard for IP cameras, being Onvif guarantees compatibility with any modern recording system. NOT being Onvif means having a camera for its own sake that can never be used together with recording systems This laser positioner complies with the ONVIF® standard! | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| AI | Artificial intelligence
- Perimeter protection : Intrusion, line crossing, lost and abandoned objects etc. - Video Metadata - Facial Recognition | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | This camera has a resolution of 2MP, equal to 1920x1080p progressive scan, Max. 25/30 fps@2M. 1/1.8" 2MP progressive scan CMOS sensor! | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Smart H.265+ Smart H.265+ is the optimized implementation of H.265 codec that uses scene-adaptive coding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ greatly reduces bit rate and storage requirements compared to standard H.265 compression
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 1/1.8" STARVIS™ CMOS sensor with STARLIGHT technology. Low brightness, color vision even in night mode With the Sony CMOS sensor it is possible to have color shots even in night mode. Normally, when entering night mode, the color vision becomes black/white. With the SENSOR present, night shots will be sharp and in color! | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | 60x Optical Zoom, 5.6-336mm varifocal lens + 16x Digital Zoom | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Illuminator with long range, the laser reaches up to 1,000m! | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | This camera features the AUTO TRACKING function.
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | This camera provides VIDEO ANALYSIS:
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | This camera has PTZ (PAN / TILT / ZOOM) positioning functions: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | ULTRA 2D / 3D-DNR 3D-NR is the most advanced version of NOISE REDUCTION management. Allows still images in low light and moving images. It is currently the most powerful solution for obtaining maximum results in the presence of little light. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | This Camera features 7 Inputs (on-off value input: 0–5 VDC) and 2 Alarm Outputs! | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | This camera has 1 input (LINE IN) + 1 Audio Output (LINE OUT): Two-way audio. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Day/Night: allows you to adapt the lens to night/day vision, and the relative automatic management of the IR Illuminator, when present.  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | The IR CUT FILTER is a mechanical filter that allows correct viewing of images in daytime viewing conditions, filtering the typical infrared frequencies, thus improving image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | ULTRA WDR up to 120dB WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light/shadow contrast. Fundamental in case of shooting from inside to outside, plates, shadowed points or all situations where there is no homogeneity of light. The greater the value in dB, the greater the camera's ability to manage the strong difference in the backlight present. Common WDRs usually reach 80db, the human eye is able to recognize a difference of up to 100db. This model reaches up to 120db managing very high levels of contrast.  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | OPTICAL DEFOG: This function allows you to clearly see images taken in particular climatic conditions: rain, smoke and fog | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 |
This camera is equipped with ROI function. The images deriving from IP cameras are "compressed", consequently the quality is set during the recording phase. Especially with cameras with a very high resolution, it is often necessary to reduce the quality in order to guarantee a low bandwidth occupation and to record a larger number of days or cameras. The ROI allows you to define areas where you can set higher quality (for example a door, the area where the license plate usually passes, an exit, etc.). In that area I can set a higher quality thus guaranteeing a greater definition of the image.  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | This camera features the Motion function by connecting it to a recording device having alarm inputs. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Possibility to insert Micro SD up to a maximum of 512GB (not included) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Protection level IP67 ( Dust / Immersion ) Also includes TVS 6000 lightning protection! | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | This product is covered by a 24 month guarantee. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
