4in1 IP Camera Eyeball HDCVI 2MP Starlight - 3.6mm - Microphone - Smart IR 60m - WDR 130dB - Microphone

-57%

Dahua - Outdoor Dome video surveillance camera - HAC-HDW2241TLMQ-A-S2 S2 version with 4 technologies in 1: CVI / AHD / TVI / CVBS switchable via DIP Switch - 2 MP - 3.6mm fixed lens - 2MP CMOS sensor - Smart Illuminator IR 60M - Day / Night (ICR) - BLC, HLC, WDR 130dB, AWB, AGC, OSD, 3DNR - Microphone - IP67 protection - Full metal case - Easy to install.

Reference: HAC-HDW2241TLMQ-A-S2

Brand: Dahua

FIND INSTALLER

https://www.setik.biz/en/cameras/8116-dahua-hac-hdw2241tlmq-a-s2-4in1-ip-camera-eyeball-hdcvi-2mp-starlight-36mm-microphone-smart-ir-60m-wdr-130db-microphone.html

€74.49

€173.24 -57%

taxes included

ARE YOU A PROFESSIONAL OF THE SECTOR?
REGISTER TO ACCESS YOUR LIST

Quantity

Available in 5 days

LO HAI TROVATO A MENO?

Scrivici dove e ti sconteremo la differenza fino a fine mese!

OFFICIAL AJAX DISTRIBUTORS! ×

BUY AJAX!
Free shipping >€49
SPED-AJAX-E

Description Product Details Data Sheet Further Details Download

VIDEO SURVEILLANCE CAMERA EYEBALL - 2MP - 4IN1 CVI / AHD / TVI / CVBS - 3.6MM - 4 IN 1 - SMART IR 60M - CMOS SENSOR - IP67 - MICROPHONE - DAHUA - HAC-HDW2241TLMQ-A-S2

Outdoor Dome Camera - Dahua - HAC-HDW2241TLMQ-A-S2
4in1: CVI / AHD / TVI / CVBS - 2 Megapixel 2 MP FullHD 1080p - 3.6mm fixed lens - 2MP CMOS Sensor - Smart IR 60M - Day / Night (ICR) - OSD menu - AWB, AGC, BLC, HLC, WDR digital, 2D-NR - 8 zone privacy masks - Dimensions: Φ121.9 mm × 99.1 mm - Weight: 0.43Kg - IP67 protection ideal for outdoor environments - Easy to install - Integrated microphone - Power supply NOT included - 24 month warranty

Product details

DAHUA-2851 | Dahua 4 in 1 PRO series fixed dome with Smart IR of 60 m for outdoor use. CMOS 1 / 2.7

- Dahua dome video surveillance camera - HAC-HDW2241TLMQ-A-S2

- 4 Technologies in 1: CVI-AHD-TVI-CVBS switchable via DIP Switch

- S2 version

- 2MP FullHD 1080p resolution
- 3.6mm fixed lens
- 2MP CMOS image sensor

- Smart IR 60 M illuminator

- Day / Night (ICR), BLC / HLC / DWDR / AGC

- Supports 8-zone rectangular privacy mask

- Operating temperature: -40 ° C ~ + 60 ° C

- Relative humidity: <95% (non-condensing)

- IP67 protection ideal for outdoor environments

- Material: Case entirely in metal

- Dimensions: Φ121.9mm × 99.1mm
- Power supply: 12V DC
- Suitable for indoor and outdoor environments
- 24 months warranty

Data sheet

HAC-HDW2241TLMQ-A-S2

Room

Image Sensor

2MP CMOS

Max. Resolution

1920 (H) × 1080 (V)

Pixel

2MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25 s – 1 / 100,000 s
NTSC: 1/30 s – 1 / 100,000 s

S / N Ratio

> 65 dB

Min. Illumination

0.001 Lux / F1.6, 30 IRE, 0 Lux IR on

Illumination Distance

30 m (98.4 ft)

Illuminator On / Off Control

Car; manual

Illuminator Number

2 (IR light)

Pan / Tilt / Rotation Range

Pan: 0 ° -360 °
Tilt: 0 ° -78 °
Rotation: 0 ° –360 °

Lens

Lens Type

Fixed lens

Mount Type

M12

Focal Length

3.6 mm

Max. Aperture

F1.6

Field of View

H: 86 °; V: 46 °; D: 101 °

Iris Type

Fixed iris

Close Focus Distance

1.1 m (3.6 ft)

Video

Frame Rate

CVI:
PAL: 1080p @ 25fps;
NTSC: 1080p @ 30fps;
AHD:
PAL: 1080p @ 25fps;
NTSC: 1080p @ 30fps;
TVI:
PAL: 1080p @ 25fps;
NTSC: 1080p @ 30fps;
CVBS:
PAL: 960 × 576H;
NTSC: 960 × 480H

Resolution

1080p (1920 × 1080); 960H (960 × 576/960 × 480)

Day / Night

Auto switch by ICR

BLC

BLC / WDR / HLC

WDR

130 dB

White Balance

Car; manual

Gain Control

Car; manual

Noise Reduction

3D NR

Smart IR

Yes

Mirror

Off / On

Privacy Masking

Off / On (8 area, rectangle)

Certifications

Certifications

CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1 + CAN / CSA C22.2 No.60950-1)

Port

Video Output

Video output choices of CVI / TVI / AHD / CVBS by one BNC port (DIP Switch)

Audio Input

One channel built-in mic

Power

Power Supply

12 V ± 30% DC

Power Consumption

Max 3.1 W (12 V DC, IR on)

Environment

Operating Temperature

–40 ° C to +60 ° C (–40 ° F to 140 ° F); <95% (non-condensation)

Storage Temperature

–40 ° C to +60 ° C (–40 ° F to 140 ° F); <95% (non-condensation)

Protection Grade

IP67

Structure

Casing

Metal throughout the whole casing

Camera Dimensions

Φ109.9 mm × 88.1 mm (Φ4.3 "× 3.5")

Net Weight

0.34 kg (0.75 lb)

Gross Weight

0.45 kg (0.99 lb)

Further details

	This camera is a QUADRIBRID (4 Integrated Technologies) These cameras are at the same time Analogue , Ahd , Hdcvi and Hdtvi . Switchable via DIP Switch!
	2MP fullHD 1080p 1920x1080p progressive scan resolution. 2MP CMOS image sensor.
	3.6mm fixed lens.
	CMOS sensor with 2MP 1080p FullHD STARLIGHT technology. Low brightness, visibility at 0.0001Lux, color vision even in night mode With this CMOS sensor it is possible to have color shots even in night mode. Normally, when entering night mode, the color vision becomes black / white. With the SENSOR present, night shots will be sharp and in color
	Infrared illuminator with an approximate maximum range of 30m with 2 LEDs. This camera is also equipped with SMART IR technology. Through this technology , the light emitted by the LEDs is adapted according to the framed object.
	3D-NR is the most advanced version of Noise Reduction management, it allows still images in the presence of low light and in movement, The currently most powerful solution to obtain the maximum results in the presence of low light.
	Allows you to adapt the lens to Night / Day vision.
	The IR CUT FILTER is a mechanical filter that allows a correct display of images in daylight viewing conditions. It filters the typical infrared frequencies thus improving the image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies.
	BLC (Back Light Compensation) is one of the 3 possible steps in the management of images with contrast, typical situations are (entrances or exits from car parks, plates, special lights, entrances with shots from inside to outside, etc.) light is one of the most complex operations possible, the BLC function allows a discreet adaptation to these situations Click to enlarge
	AGC is an integrated signal amplifier that allows vision even in critical conditions. It is automatic and does not require specific settings.
	ULTRA WDR up to 130dB WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light / shadow contrast. Fundamental in the case of shots from the inside out, license plates, shaded spots or all situations where there is no homogeneity of light.
	This camera has a built-in microphone!
	Protection level IP67 (Dust / Immersion) ideal for use in video surveillance systems set up in external cabinets.
	DC12V power supply ( NOT included in the package).
	This camera was made with full metal cases along the entire body.
	This product is covered by a 24 month warranty.
