ITC237-PW6M-IRLZF1050-C2 Standalone ANPR Camera, 1080P Resolution, 2 Megapixel, 10-50mm Varifocal Lens, 2 Megapixel 1/1.8" CMOS Sensor, IR Illuminator up to 30 Meters, WDR 96dB, SD Card up to 64Gb, audio , 2x RS485, 1x RS232, Alarm, Support license plate cropping, snapshot capture and video recording, Metadata, PoE
https://www.setik.biz/en/cameras/7934-dahua-itc237-pw6m-irlzf1050-c2-dahua-ip-2mp-optical-varifocal-camera-ir-anpr.html
€857.72
€1,994.70 -57%
taxes included
LO HAI TROVATO A MENO?
Scrivici dove e ti sconteremo la differenza fino a fine mese!
CHRISTMAS WEEK 2024 ×
FREE SHIPPING
ON THE ENTIRE CATALOGUE!
1. Reach at least €249
2. Select FEDEX
3. Confirm code NATALE-FREE-E
4. Complete your order.
Shipping will be free of charge!
Until 10 a.m. on 27/12/2024
Code NOT combinable with other actives
STANDALONE ANPR CAMERA 2 MEGAPIXEL FULL HD - SD CARD - POE - IK10 - AUDIO - ALARM - C2 VERSION - DAHUA TECHNOLOGY
Standalone ANPR Camera - Dahua1080P 2Megapixel resolution - Varifocal lens 10~50mm - 1/1.8" 2 megapixel CMOS sensor
IR illuminator up to 30 meters - WDR 96dB - SD slot - Audio, RS485, RS232, Alarm
Support license plate cropping, snapshot capture and video recording - PoE powered
ANPR CAMERAS: WHAT IS IT ABOUT? The presence of this technology allows adequate vision even in the presence of illuminators on license plates . |
Product details
- Standalone ANPR Camera - Dahua
- Resolution: 2Megapixel 1080P FULL HD
- 1/1.8” progressive CMOS image sensor
- 1/1.8” progressive CMOS image sensor
- Varifocal lens 10~50mm
- Video Compression H.265
- Video Compression H.265
- WDR( 96dB )
- 3 alarm inputs and 3 alarm outputs
- 1 audio input and 1 audio output
- RS485 - RS232
- IR illuminator with 6 LEDs and license plate reading
- IR illuminator with 6 LEDs and license plate reading
- Smart functions: Support license plate cropping, snapshot capture and video recording
- Remote viewing with Dahua DMSS
- SD slot slot
- PoE power supply
- Suitable for outdoor and indoor environments
- PoE power supply
- Suitable for outdoor and indoor environments
- Dimensions 370.4mm×124.7mm×105.7mm
- 24 month warranty
- 24 month warranty
Data sheet
| IP camera for license plate recognition |
| 1/1.8” 2 megapixel CMOS sensor |
| Compression formats: H.265/H.264M/H.264H/H.264B/MJPEG |
| Digital resolution: 1080P (1920x1080), 720P (1280x720), D1 (704x576), CIF (352x288) |
| Stream 1: 1080P, 720P (25fps) |
| Stream 2: 720P, D1, CIF (25fps) |
| 0.002lux |
| IR illumination: 6 leds, 30 meters, adjustable brightness |
| 10~50mm motorized optics |
| 1 RCA input / 1 RCA audio output |
| Picture modes: WDR 96dB, 3D-NR, edge enhancement |
| White balance with 3 modes |
| Auto, customizable auto, and customizable exposure modes |
| Support NRA |
| Capture range of 8 ~30 meters |
| Detected lane width of 6~7 meters |
| Maximum detection speed: 60km/h |
| Vehicle capture rate of ≥99% |
| Supports recognition of vehicle type, logo, color, license plate, vehicle without license plate |
| Vehicle recognition rate of ≥95% |
| video metadata |
| Shows the vehicle's license plate and its route |
| Support MicroSD card up to 64GB (card not included) |
| analog video output |
| 3 optocoupled alarm inputs |
| 3 alarm outputs |
| 2 RS485 ports |
| 1 RS232 port |
| Network interface: RJ45 (100/1000M) |
| Power: 12V DC / 24V AC / PoE+ (802.3at) |
| Consumption: <20W |
| Operating temperature -30°C ~ +65°C |
| Humidity 10%~90% |
| metal and plastic casing |
| Degree of protection IP67 |
| Dimensions: 124.7 (W) x 105.7 (H) x 370.4 mm |
| Weight: 1.7kg |
Further details
 | Dahua ANPR cameras offer a full range of functions for license plate recognition. They integrate an algorithm that detects and captures license plate numbers and stores their details in a database The camera can capture and store screenshots of license plates directly to an SD Card without the need for an NVR Why choose a Dahua ANPR camera? The Dahua ANPR camera range incorporates high quality 2 megapixel images, varifocal lenses, anti-roll headlights and long-range IR LEDs for license plate recognition up to 40 meters away. The cameras offer a white list / black list function capable of triggering set events based on stored license plates. Furthermore...
How and where can it be used? A Dahua ANPR camera is suitable for various types of areas, including parking entrances, barrier-controlled areas or lane monitoring.
 |
 | This camera has a resolution of 2Megapixel 1080P FULL HD 1080P/720P |
 |
The advantage of a PoE camera is evident, it allows it to be powered with the same cable with which it communicates without carrying additional power cables and without having to install a separate power system, a PoE camera guarantees constant voltages and simple installation |
 | This camera features 10-50mm varifocal optics |
| 1/1.8" sensor with STARLIGHT technology. Low brightness, color vision even in night mode
With this sensor it is possible to have color shots even in night mode. Normally, when you enter night mode, color vision becomes black/white. With the SENSOR present, night shots will be in color |
 | This camera has useful features such as: - License plate cutout - Overview screenshots and video recordings - White list / black list for activation of events set based on the memorized license plates. - Multiple Detection: The camera supports automatic and video detection, it is more stable when the system is used to control barriers or count the number of vehicles for access control. Even if automatic detection is triggered accidentally, video detection will still be automatic. |
 | Infrared illuminator with 6 Dot LEDs (larger) and license plate reading/range |
 | ULTRA WDR up to 96dB WDR (Wide Dynamic Range): It is the professional solution in cases where you need to operate in conditions of high light/shadow contrast. Fundamental when shooting from inside to outside, license plates, shadowed points or all situations where there is no homogeneity of light.  |
 | This camera features: 1 Inputs + 2 Alarm Outputs |
 | This camera features 1 audio input + 1 audio output |
 | Allows you to adapt the lens to Night/Day vision
|
 | The IR CUT FILTER is a mechanical filter that allows correct viewing of images in daytime viewing conditions. It filters the typical infrared frequencies thus improving image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies.  |
 | BLC (Back Light Compensation) is one of the 3 possible steps in the management of images with Contrast, typical situations are (Entries or exits from car parks, license plates, particular lights, entrances with shots from the inside towards the outside, etc.) the compensation of the light is one of the most complex operations possible, the BLC function allows discreet adaptation to these situations |
 | Level of protection from heavy rain and dust in IP parameters. |
 | IK 10 is the highest level of protection against direct damage. This allows the use of the camera even if there are risks of vandalism
|
 | Dahua DSS management software
New design, easy to use
High Compatibility |
 | Possibility to insert Micro SD Snapshot recording of vehicle license plates and saving directly to SD |
 | This product is covered by a 24 month warranty. |
