Hikvision DS-2CE76D0T-ITMFS (2.8mm) 2MP CMOS 4in1 (TVI / AHD / CVI / CVBS) Turret outdoor camera 2Megapixel, 2.8mm fixed lens, 2.0MP CMOS sensor, EXIR 2.0 illuminator up to 30M with EXIR 2.0 technology, Support 3D Digital noise reduction, BLC, Smart IR, WDR 120dB. HD-TVI video output, IP67.
€79.30
€122.00 -35%PRODUCT NOT AVAILABLE, DISCOUNT NOW 3%
DS-2CE76D0T-ITMFS (2.8mm) | HIKVISION 2MP TURRET CAMERA 4IN1 2.8MM IP67 IR30
Hikvision 4IN1 (TVI / AHD / CVI / ANALOG) camera for outdoor IP67
Resolution: 2 MP 2Megapixel - 2.8mm fixed lens - CMOS sensor
30M Smart IR Illuminator with EXIR 2.0 Technology - Day / Night (ICR) - AGC - BLC - SMART IR - WDR 120dB - IP67 protection
Power supply NOT included - 24 months warranty
4IN1 TECHNOLOGY: This camera is a QUADRIBRID (4 Integrated Technologies) |
Resolution: This camera features a resolution of 1920x1080 FULL-HD 2 megapixels high performance CMOS sensor |
Optics: This camera features 2.8mm fixed lens |
IR Infrared Illuminator: This camera is also equipped with SMART IR technology. EXIR 2.0 TECHNOLOGY This technology remedies the classic disturbances of the traditional IR illuminator. 1) NO IR REFLEX OR BLEEDING: 2) BEST IR COVERAGE:
|
Day / Night: Allows you to adapt the lens to night / day vision, and the relative automatic management of the IR illuminator, when present. |
IR CUT FILTER (ICR): Mechanical filter that allows a correct display of images in daytime viewing conditions. It filters the typical infrared frequencies thus improving the image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies. |
BLC (Back Light Compensation): is one of the 3 possible steps in the management of images with contrast, typical situations are (entrances or exits from car parks, plates, special lights, entrances with shots from inside to outside, etc.) light compensation is one of the most complex possible, the BLC function allows a fair adaptation to these situations |
AGC (Automatic Gain Control): integrated signal amplifier that allows viewing even in critical conditions. It is automatic and does not require specific settings. |
WDR: |
IP67 protection - outdoor: |
Diet: |
Data sheet
DS-2CE76D0T-ITMFS (2.8mm) | |
Room | |
Image Sensor | 2.0 megapixel progressive scan CMOS |
Signal System | PAL / NTSC |
Video Frame Rate | TVI: 1080P @ 30fps, 1080P @ 25fps AHD: 1080P @ 30fps, 1080P @ 25fps CVI: 1080P @ 30fps, 1080P @ 25fps CVBS: PAL / NTSC |
Resolution | 1920 (H) × 1080 (V) |
Min. Illumination | 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
Shuder Time | PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s |
Lens | 2.8 mm |
Field of View | horizontal FOV: 106.4 °, vertical FOV: 57.9 °, diagonal FOV: 124.6 ° |
Lens Mount | M12 |
Day & Night | ICR |
Angle Adjustment | Pan: 0 to 360 °, Tilt: 0 to 75 °, Rotation: 0 to 360 ° |
Audio | Built-in mic |
WDR (Wide Dynamic Range) | Digital WDR |
Menu | |
AGC | Yes |
D / N Mode | Auto / Color / BW (Black and White) |
Image Mode | STD / HIGH-SAT |
HLC (Highlight Compensation) | Yes |
White Balance | Auto / Manual |
AE (Auto Exposure) Mode | DWDR / BLC / HLC / Global |
Noise Reduction | 2D DNR |
Language | English |
Functions | Brightness, Sharpness, Mirror, Smart IR |
Interface | |
Video Output | Switchable TVI / AHD / CVI / CVBS |
General | |
Operating Conditions | -40 ° C to 60 ° C (-40 ° F to 140 ° F), Humidity: 90% or less (non-condensing Aon) |
Power Supply | 12 VDC ± 25% |
Power Consumption | Max. 3.7 W |
Protection level | IP67 |
Material | Metal |
IR Range | Up to 30 m |
Communication | HIKVISION-C |
Dimension | 89.47 mm × 68.2 mm (3.52 "× 2.68") |
Weight | Approx. 240 g (0.53 lb.) |
