PoE IP Camera Hikvision DS-2TD1228-7 / QA Thermal DeepinView Bullet Thermal Camera NETD <40mk , Accuracy ± 8 ° C, for object temperature measurement and fire alarm .Dual-lens , dual thermal optics (6.9mm) / visible 6.4mm and Dual-Sensor (1x Thermal Vanadium Oxide Uncooled Focal Plane Array + 1x CMOS 1 / 2.7 "). Resolution 2688 × 1520 for visible optics, H.265, 15MT IR LED, WDR 120dB, Alarm, Audio , RS485, MicroSD slot. IP66 protection, TVS6000.
FIND INSTALLER
€1,146.68
€1,764.12 -35%CHRISTMAS WEEK 2024 ×
FREE SHIPPING
ON THE ENTIRE CATALOGUE!
1. Reach at least €249
2. Select FEDEX
3. Confirm code NATALE-FREE-E
4. Complete your order.
Shipping will be free of charge!
Until 10 a.m. on 27/12/2024
Code NOT combinable with other actives
https://www.setik.biz/storage/images/Articoli/hikvision_banner.jpg
DS-2TD1228-7 / QA | IP CAMERA HIKVISION TURRET THERMAL CHAMBER FIRE PREVENTION NETD <40MK
IP PoE Thermal Camera Hikvision Turret Thermal H.265 Camera
Thermal optics (6.9mm) - NETD <40mk (@ 25 ° C), Accuracy ± 8 ° C
Video Analysis and Fire Detection - Audio / Alarm
MicroSD slot (not included) - IP66 protection and TVS6000V - Ideal for fire prevention
| Thermal Sensing: What is it?
Any object with a temperature above absolute zero (-273.15 ° C) emits radiation. Infrared radiation lies between the visible spectrum (0.4-0.75um) and microwaves (> 15um). Even if we cannot see them, we perceive them every day: the sun and fire are sources of infrared radiation that we can perceive through heat. Image quality depends on the temperature difference and higher differentials produce better images. Here's how we distinguish the temperature difference in thermal imaging.  |
DS-2TD1228-7 / QA Hikvision GPU equipped thermal IP turret camera supporting intelligent behavioral analysis algorithm, capable of real-time high-precision VCA detection and alarm. Ideal for perimeter defense and fire prevention within critical infrastructures such as: communities, villas, construction sites, factories. The alarm prevention system will help you to immediately detect unexpected events and protect you from property loss.
Smart functions (thermal images):
- Leading image processing technology: Adaptive AGC, 3D DNR, NETD below 40mk (25 ° C), F # = 1.0
- Powerful behavioral analysis function, based on deep learning algorithm: Line crossing, Intrusion, Region of entry and exit
- Reliable alarm function for temperature exception
- Advanced algorithm for fire detection
- Bi-spectrum image fusion, picture-in-picture vision
Thermal imaging module:
- Sensor resolution 256 × 192 , high sensitivity sensor, supports contrast adjustment
- Adjustable shutter in various ways
- 3D DNR, 15 adjustable color schemes (palettes), image detail emphasis
- Mirror image, x2, x4 digital zoom and local output
|
Watch the video! |
|
PoE (Power Over Ethernet): |
|
Optics on board: - Thermal optics with 256 × 192 resolution of 6.9mm -Traditional lens with resolution up to 2688 × 1520 with fixed lens of 6.4mm |
| Bi-spectrum fusion: Possibility of vision in thermal, traditional, thermal / traditional Bi-Spectrum fusion or picture in picture mode (thermal vision in optical vision). In these last two modes, the details of the images will be clearer even if overlaid, useful as evidence when necessary. The preview in these cases also reduces the bandwidth and there is no need to switch from thermal to optical or vice versa.  |
|
IR Infrared Illuminator: |
|
Thermal Optics, NETD and Accuracy: Features NETD below 40mk with accuracy ± 8 ° C accuracy
|
| Clear and sharp images: With advanced features like Automatic Gain Control (AGC), Digital Detail Enhancement and 3DDNR, Hikvision thermal cameras deliver crystal clear thermal images unmatched in the industry.  |
| Video Analysis (VCA):
It has 4 types of VCA rules ( Line crossing, Intrusion, Incoming region, Outgoing region ), up to 8 VCA rules. |
| Fire Detection:
Ideal camera for fire detection.
|
| Alarm:
1 alarm inputs (0-5vDC) and 1 relay output , configurable alarm response action. |
| Audio:
1 audio interface 3.5 Microphone / Line in. Line input: 2-2.4V [pp], output impedance: 1K? ± 10% |
| Archiving:
Equipped with MicroSD slot. Support Micro SD / SDHC / SDXC card (up to 128GB), support manual / alarm recording |
| Installation environments:
Thermal cameras can be used in various scenarios.
|
| IP66 protection:
Protection level IP66 (Rain / Dust) and TVS 6000V (lightning) |
Data sheet
| DS-2TD1228-7 / QA | ||
| Room | ||
| Thermal Module |
Image sensor | Vanadium Oxide Uncooled Focal Plane Arrays |
| Resolution | 256 × 192 | |
| Pixel Interval | 12 μm | |
|
Response waveband |
8 μm to 14 μm | |
| NETD | <40 mK (25 ° C, F1.0) | |
| Lens (Focal Length) | 6.9 mm | |
| MRAD | 1.74 mrad | |
| Field Of View | 24.9 ° (H) x18.7 ° (V) | |
| Min. Focusing Distance | 1.3m | |
| Digital zoom | x2, x4 | |
| Openings | F1.0 | |
| Optical Module | Max. Image Resolution | 2688 × 1520 |
| Image Sensor | 1 / 2.7 "Progressive Scan CMOS | |
| Min illumination | Color: 0.0176 Lux @ (F2.25, AGC ON), B / W: 0.0035 Lux @ (F2.25, AGC ON) | |
|
Shutter speed |
1s to 1 / 100,000s |
|
| Lens (Focal Length) | 6.4 mm | |
| Field of View | 53.0 ° (H) x28.0 ° (V) | |
| Aperture (Range) | F1.6 | |
| WDR | 120 dB | |
| Image Effect | Target Coloration | Yes. Supported in white hot and black hot mode. |
| Illuminator | IR Distance | Up to 15 m |
| IR Intensity And Angle | Automatically adjusted | |
| Audible And Visual Alarm | White Light Range | Up to 30 m |
| Visual Alarm | Yes. White light alarm with adjustable flashing frequencies | |
| Audio Alarm | Yes, for two types of audible alarm (VCA and Temperature Exception) 2 preset voice alerts (one for each) 6 importable user-defined voice alerts (6 options shared in the two types) |
|
| Smart Function |
VCA (Video Content Analysis) |
4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total. |
|
Temperature Measurement |
3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line) | |
|
Temperature Range |
-20 ° C to 150 ° C (-4 ° F to 302 ° F) | |
|
Accuracy temperatures |
± 8 ° C (± 14.4 ° F) |
|
| Video and audio | Main Stream |
Thermal: |
| Sub-Stream | Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60Hz: 30fps (704 × 480, 352 × 240) |
|
| Video Compression |
Main Stream: H.265 / H.264 |
|
| Audio Compression | G.722.1 / G.711ulaw / G.711alaw / MP2L2 / G.726 / PCM | |
| Network |
Protocols | IPv4 / IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, SFTP, SRTP |
| Network Storage | MicroSD / SDHC / SDXC card (up to 256 G) local storage, NAS (NFS, SMB / CIFS), Auto Network Replenishment (ANR) | |
| API | ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G) | |
| Simultaneous Live View | Up to 20 channels | |
| User / Host Level | Up to 32 users, 3 levels: Administrator, Operator, User | |
| Security | User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x (EAP-MD5, EAP-TLS), access control, IP address filtering | |
| Client | iVMS-4200, Hik-Connect | |
| Web Browser |
Live view (plug-in allowed): Internet Explorer 11 |
|
| Interface | Alarm Input | 1, alarm input (0-5 VDC) |
| Alarm Output | 1, alarm output (alarm response actions configurable) | |
| Alarm Action | SD recording / Relay output / Smart capture / FTP upload / Email linkage | |
| Audio Input | 1, 3.5 mm Mic in / Line in interface
Line input: 2 to 2.4 V [pp], output impedance: 1 KΩ ± 10% |
|
| Audio Output | Linear level, impedance: 600 Ω | |
| Communication Interface |
1, RJ45 10M / 100M Self-adaptive Ethernet interface. |
|
| Analog Output | 1.0V [pp] / 75Ω, PAL / NTSC / BNC | |
| General |
Web Client Language | 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Power Supply | 12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3) |
|
| Power Consumption | 12 VDC ± 25%: 0.5 A, Max 6 W PoE (802.3af, class 3): 42.5 V to 57 V, 0.14 A to 0.22 A, Max 6.5 W |
|
| Working Temperature / Humidity |
Temperatures: -40 ° C to 65 ° C (-40 ° F to 149 ° F) |
|
| Protection level |
IP66 Standard |
|
| Dimensions | 138.3 mm × 138.3 mm × 123.1 mm (5.45 "× 5.45" × 4.85 ") | |
| Weight | 940 g (2.07 lb) | |
