ONVIF® 12MP Fisheye PoE IP Camera - 1.29mm Fixed Lens - 10m IR - Artificial Intelligence and Video Analysis

ONVIF® 12MP Fisheye PoE IP Camera - 1.29mm Fixed Lens - 10m IR - Artificial Intelligence and Video Analysis
-58%

IPC-EBW81242-AS-IVC-S2 - S2 version - Dahua - Onvif PoE outdoor IP camera Fisheye for video surveillance - 12MP - 1 / 1.7 "CMOS sensor and 1.29mm fixed lens - Panomorph lens B9VVT - Triple Stream - Smart Video H.265 + - Video Analysis - Artificial intelligence ( People Counting), smart search and heat map, queue management - IR 10m - Day / Night (ICR) - BLC - HLC - DWDR - 3DNR - ROI - Defog, Motion Detection - IP67 protection (Dust / Immersion) and IK10 (Vandalism Acts) - MicroSD 256GB Slot - Audio - Microphone and Loudspeaker - Alarm - PoE +



Reference: IPC-EBW81242-AS-IVC-S2

Brand: Dahua

FIND INSTALLER

€907.97

€2,161.84 -58%
taxes included
Tax included
 Available in 5 days
 starting

LO HAI TROVATO A MENO?

Scrivici dove e ti sconteremo la differenza fino a fine mese!

meno


IP POE CAMERA ONVIF® 5MP FISHEYE - 12 MEGAPIXEL - 1.29MM OPTICS - ARTIFICIAL INTELLIGENCE - DAHUA - IPC-EBW81242-AS-IVC-S2

Prodotto Dahua
ONVIF® PoE outdoor IP camera Fisheye - Dahua - IPC-EBW81242-AS-IVC-S2
Resolution 12MP Megapixel - 1.29 Optical Fisheye Panoramic - Panomorph Lens B9VVT - Triple Stream - H.265 + - 1 / 1.7 "CMOS sensor - IR 10m - Day / Night (ICR) - BLC - HLC - DWDR - 3DNR - ROI - Defog - Video Analysis (tripwire, intrusion) - Artificial Intelligence (people counting, heat map, smart search, queue management - Audio 1in and 1 out / Alarm 2in and 2 out - Microphone and Speaker - Slot for MicroSD 256GB (not included) - Supports PoE + - 24 months warranty

Product details

  • Onvif PoE outdoor IP camera - Dahua - IPC-EBW81242-AS-IVC-S2
  • Resolution up to 12 MP
  • Fixed Lens 1.29 Fisheye (180 °) Panoramic Vision
  • Panomorph Lens RPL: B9VVT
  • 1 / 1.7 "CMOS sensor
  • Video compression H.265 + / H.264 + Smart Codec
  • Day / Night (ICR), 3DNR, AWB, AGC, BLC, HLC, ROI, defog, Motion detection and Privacy Masking
  • DWDR: Digital WDR
  • Video Analysis: Line crossing , Intrusion
  • Artificial Intelligence: People Counting, Heat Map, Smart Search, Queue Management
  • IR with maximum range up to 10 meters
  • ONVIF® standard
  • PoE + (802.3at) supported
  • MicroSD slot up to 256GB (not included)
  • 1 Input + 1 Audio Output
  • Integrated microphone
  • Integrated loudspeaker
  • 2 inputs + 2 alarm outputs
  • IP67 protection (Dust / Diving)
  • IK10 protection (Vandalism)
  • RJ45 10/100/1000 Base-T Ethernet port
  • 12V DC / PoE power supply (not included)
  • Operating temperature: –40 ° C to +60 ° C
  • Dimension: 59.8mm × Φ149.8mm
  • Item Weight: 0.79Kg
  • Metal shell
  • 24 months warranty

Data sheet

IPC-EBW81242-AS-IVC-S2

Room

Image Sensor

1 / 1.7 "CMOS

Max. Resolution

4000 (H) × 3000 (V)

ROM

2 GB

RAM

4 GB

Scanning System

Progressive

Electronic Shutter Speed

Auto / Manual 1/3 s – 1 / 100,000 s

Min. Illumination

0.01 Lux@F2.0 (Color, 30 IRE)

0.001 Lux@F2.0 (B / W, 30 IRE)

0 Lux (Illuminator on)

S / N Ratio

> 56 dB

Illumination Distance

10 m (32.81 ft) (IR)

Illuminator On / Off Control

Auto / Manual

Illuminator Number

3 (IR LED)

Lens

Lens Type

Fixed-focal

Lens Mount

M12

Focal Length

1.29mm

Max. Aperture

F2.0

Field of View

Horizontal: 185 °;

Vertical: 180 °

Iris Control

Fixed

Close Focus Distance

0.2m (0.66ft)

Smart Event

Heat Map

Yes

Professional, intelligent

IVS (Perimeter Protection)

Intrusion; tripwire

People Counting

Supports 4 rules to count the number of people entering, exiting, and staying separately. It will trigger alarm linkage when the number of people who entering, exiting or staying exceeds the threshold. It can display and export reports based on year, month, day, week, day or custom time.

Supports 4 rules to count the number of people in area and will trigger alarm linkage when the average strand time or people number in the area exceeds the threshold. It can display and export reports based on year, month, day, week, day or custom time.

Supports 4 queue management rules to count number of people queuing and queue time in real time, and it will trigger alarm linkage when the number of people queued or queue time exceeds the threshold. It can display and export reports based on year, month, day, week, day or custom time.

Smart Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video

Video Compression

H.265; H.264; H.264H; MJPEG (Only supported by the sub stream)

Smart Codec

Smart H.265 +; Smart H.264 +

Video Frame Rate

Main stream: 4000 × 3000 @ (1–25 / 25 fps)

sub stream: 704 × 576 @ (1–25 / 30 fps)

third stream: 1280 × 960 @ (1–17 / 17 fps)

Fisheye mode:

1O (4000 × 3000)

1P (4096 × 1024)

2P (2432 × 2432)

1R (1216 × 1216)

2R (2432 × 2432)

4R (2432 × 2432)

1O + 3R (2432 × 2432)

* The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Stream Capability

3 streams

Resolution

4000 × 3000; 3280 × 2480; 2880 × 2160; (3M) 2048 × 1536; 1.3M (1280 × 960); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control

CBR / VBR

Video Bit Rate

H264: 8 kbps – 16384 kbps

H265: 3 kbps – 16384 kbps

Day / Night

Auto (ICR) / Color / B / W

BLC

Yes

HLC

Yes

WDR

DWDR

White Balance

Car; natural; street lamp; outdoor; manual; regional custom

Gain Control

Car

Noise Reduction

3D NR

Motion Detection

OFF / ON (4 areas, rectangular)

Further details

ONVIF® Onvif, the absolute standard for IP cameras. Being Onvif guarantees compatibility with any modern recording system. NOT being Onvif means having a camera for its own sake that can never be used together with recording systems
PoE power supply

The advantage of a PoE camera is obvious, it allows it to be powered with the same cable with which it communicates without carrying additional power cables and without having to install a separate power supply system, a PoE camera guarantees constant voltages and simple installation.

This camera has 802.3at PoE + protocol

This camera has 8Mpx 3480x2160 resolution

This camera has a resolution of up to 12 megapixels.

4000x3000 pixels.

Fisheye obiettivo

1.29 mm lens with FishEye effect. Useful objective to have a complete overview of what we want to film. 180 ° panoramic vision

Smart H.265 + video encoding

Smart H.265 +

Smart H.265 + is the optimized implementation of the H.265 codec which uses a scene adaptive coding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference frame and intelligent noise reduction useful for delivering high quality video without straining the network.

Smart H.265 + greatly reduces bit rate and storage requirements compared to standard H.265 compression

Video compressione Smart H.265+

Main stream: 4000 × 3000 @ (1–25 / 25 fps)
sub stream: 704 × 576 @ (1–25 / 30 fps)
third stream: 1280 × 960 @ (1–17 / 17 fps)

Fisheye mode:

1O (4000 × 3000) 1P (4096 × 1024) 2P (2432 × 2432) 1R (1216 × 1216) 2R (2432 × 2432) 4R (2432 × 2432) 1O + 3R (2432 × 2432)

This camera features SMART DETECTION:
- Line crossing recognition
- Intrusion recognition



This camera features INTELLIGENT FUNCTION:

- Heat Map

- Perosne count

- queue management and control

Heat map


Illuminatore IR fino a 10mt

Infrared illuminator with REAL range up to 10M for night vision

Interfaccia audio

This camera has 1 Audio input + 1 Audio output.

Microfono integrato

This camera also has a built-in microphone and speaker.

This NVR has alarm inputs and outputs Equipped with 2 inputs and 2 alarm outputs.
Funzione ROI This camera is equipped with the ROI function.

The images deriving from IP cameras are “compressed”, consequently the quality is set during the recording phase. Especially on cameras with a very high resolution, it is often necessary to reduce the quality in order to guarantee a reduced bandwidth occupation and record a greater number of days or cameras.
The ROI allows you to define areas where you can set a higher quality (for example a door, the area where the plate usually passes, an exit, etc.). In that area I can set a higher quality thus guaranteeing a greater definition of the image.
Ultra Smart Funzione ROI
Day / Night Function Icon Day / Night: allows you to adapt the lens to night / day vision, and the relative automatic management of the IR illuminator, when present.
Example Day / Night function
ICR

The IR CUT FILTER is a mechanical filter that allows a correct visualization of the images in daytime viewing conditions, filtering the typical infrared frequencies, thus improving the image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies.

Esempio Funzione IR Cut Filter

Automatic Gain Control Function Icon Automatic Gain Control, with the possibility of independently adjusting the sensitivity in particular conditions of use
Example Automatic Gain Control Function

BLC (Back Light Compensation): it is one of the 3 possible steps in the management of images with contrast, typical situations are: entrances or exits from parking lots, license plates, special lights, entrances with shots from inside to outside, etc. Light compensation is one of the most complex operations possible, the BLC function allows a discreet adaptation to these situations

3D-DNR 3D-NR is the most advanced version of NOISE REDUCTION management. Allows still images in low light and in motion. It is currently the most powerful solution for obtaining maximum results in low light conditions.

D-WDR (Digital Wide Dynamic Range) is the Software solution of the most powerful WDR integrated in the DSP, exactly as it happens for the digital zoom compared to the Optical Zoom, it is a software simulation of emulation of the WDR technology, however extremely useful in circumstances of strong contrast.

DEFOG Function Icon This function allows you to clearly see images taken in particular climatic conditions: rain, smoke and fog
DEFOG function example image
DEFOG function example image
MicroSD Card slot Possibility to insert Micro SD up to a maximum of 256GB (not included)
Protezione IP67 contro polveri e immersioni Protection level IP67 (Dust / Diving)

IK 10 is the highest level of protection from direct damage. This allows the use of the camera even if there is a risk of vandalism

12VDC_Aliment12V DC power supply not included
Italian Guarantee Icon This product is covered by a 24 month warranty.

Download

Download the English brochure
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
