HAC-HDW2501TLMQ-A-S2 - Dahua - Starlight HDCVI Eyeball Camera - 4in1 - 3.6mm Lens - 5MP - Smart IR 30m
Dahua HAC-HDW2501TLMQ-A-S2 outdoor camera with 4 technologies in 1: HDCVI / HDTVI / AHD / ANALOG Switchable via BNC Port (DIP Switch), 5Megapixel 5MP resolution, 3.6mm lens and 1 / 2.7 "CMOS sensor with Starlight technology . Illuminator Smart IR LED 30m 1, 120dB WDR, AGC, AWB, BLC, HLC, Day / Night (ICR), Mirror Mode, Privacy Masking, Microphone - IP67 protection for outdoor use.
FIND INSTALLER
DAHUA: LOSS LEADER×
INCREDIBLE DISCOUNTS
on a selection of DAHUA products
Check out the promo now >>
OUTDOOR CAMERA 5MEGAPIXEL 3.6MM - STARLIGHT - SMART IR 30M - WDR 120dB - MICROPHONE - IP67 - DAHUA - HAC-HDW2501TLMQ-A-S2
5MP Eyeball Starlight 4in1 outdoor Dahua camera - HAC-HDW2501TLMQ-A-S2
4in1: HDCVI / HDTVI / AHD / ANALOG switchable via DIP Switch via BNC port - 5Megapixel 5MP - 3.6mm fixed lens - 1 / 2.7 "5MP 2880 (H) × 1620 (V) CMOS sensor with Starlight Technology - Smart IR 1 LED 30m - WDR 120dB / AGC / BLC / HLC / Mirror Mode / Privacy Masking on 8 rectangular areas - Microphone - Power supply NOT included - 24 months warranty
Product details
- IP67 protection (Rain / Diving) ideal for outdoor use
- Smart IR 1 LED 30m illuminator
Data sheet
| HAC-HDW2501TLMQ-A-S2 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Room |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Image Sensor |
1 / 2.7 inch CMOS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Max. Resolution |
2880 (H) × 1620 (V) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Pixel |
5 MP |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Scanning System |
φ109.9mm × 88.1mm (φ4.33 "× 3.47") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Net Weight |
0.34 kg (0.75 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Gross Weight |
0.45 kg (0.99 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Further details
 |
This camera is a QUADRIBRID (4 Integrated Technologies) Switch Technologies: The camera can switch from HDCVI to HDTVI, AHD or Analog via dip switch on coaxial cable |
 |
5MP resolution, means 12 times the resolution of a common D1 camera : Resolution: 2880 (H) × 1620 (V)
|
 |
This camera features a fixed 3.6mm lens |
|
|
1 / 2.7 "CMOS sensor with STARLIGHT technology. Low brightness, visibility at 0.0001Lux, color vision even in night mode With this CMOS sensor it is possible to have color shots even in night mode. Normally, when entering night mode, the color vision becomes black / white With the Starlight SENSOR in this camera, night shots will be sharp and in color!
|
 |
1 LED infrared illuminator with a maximum range of approximately 30m SMART IR technology. |
 |
ULTRA WDR up to 120dB WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light / shadow contrast. Fundamental in the case of shots from the inside out, license plates, shaded spots or all situations where there is no homogeneity of light.  |
|
|
This camera has a built-in microphone |
 |
Allows you to adapt the lens to Night / Day vision
|
 |
The IR CUT FILTER is a mechanical filter that allows a correct display of images in daylight viewing conditions. It filters the typical infrared frequencies thus improving the image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies.  |
 |
BLC (Back Light Compensation) is one of the 3 possible steps in the management of images with contrast, typical situations are (entrances or exits from car parks, plates, special lights, entrances with shots from inside to outside, etc.) the compensation of light is one of the most complex operations possible, the BLC function allows a discreet adaptation to these situations |
 |
AGC is an integrated signal amplifier that allows viewing even in critical conditions. It is automatic and does not require specific settings. |
 |
Protection level IP67 (Dust / Diving) |
 |
12VDC power supply not included  |
 |
This product is covered by a 24 month warranty. |
