HAC-HDW2501TLMQ-A-S2 - Dahua - Starlight HDCVI Eyeball Camera - 4in1 - 3.6mm Lens - 5MP - Smart IR 30m

HAC-HDW2501TLMQ-A-S2 - Dahua - Starlight HDCVI Eyeball Camera - 4in1 - 3.6mm Lens - 5MP - Smart IR 30m
-57%

Dahua HAC-HDW2501TLMQ-A-S2 outdoor camera with 4 technologies in 1: HDCVI / HDTVI / AHD / ANALOG Switchable via BNC Port (DIP Switch), 5Megapixel 5MP resolution, 3.6mm lens and 1 / 2.7 "CMOS sensor with Starlight technology . Illuminator Smart IR LED 30m 1, 120dB WDR, AGC, AWB, BLC, HLC, Day / Night (ICR), Mirror Mode, Privacy Masking, Microphone - IP67 protection for outdoor use.

Reference: HAC-HDW2501TLMQ-A-S2

Brand: Dahua

EAN: 6939554944871

Manufacturer Object ( [id] => 13 [name] => Dahua [description] =>

The Asian Company, born in 2001, is famous because of the excellent quality of its product in terms of performances and potential.

The range of products made by Dahua includes not only classic CCTV systems but also more complex and articulate systems: not only video surveillance, indeed, but also access control, video intercoms, thermal cameras and much more.

The reliability, the cutting-edge technologies and the competitive prices offered by Dahua are only some of the reasons why Setik has always chosen to distribute this brand. Dahua has been for years a reference point in the international CCTV market, due to the huge investments dedicated every year to Research and Development. Numbers are clear: since 2016, Dahua has registered more than 800 patents with its own brand.

The Dahua-branded products sold by Setik Srl could eventually be delivered as OEM: this means that the items are absolutely original and made by Dahua, but characterized by a different aesthetic look reserved for the online market (generally as far as the logo and the package are regarded).

This has no effects on the warranty and on the technical specifications nor even on the possible updates and functionalities, because the products are authentic Dahua’s ones.

[short_description] =>

Videosorveglianza Dahua

Zhejiang Dahua Technology Co., Ltd. is one of the leading solution providers in video surveillance industry, with more than 13,000 employees and 35 active branches all over the world.

[id_address] => [date_add] => 2012-07-14 17:53:54 [date_upd] => 2025-03-19 12:15:55 [link_rewrite] => dahua [meta_title] => Best Dahua Products: DVR, HCVR,NVR, IPC,SD,PTZ,HDCVI, [meta_keywords] => dahua, dahuatech, dahua distribution, dahua national supplier [meta_description] => Dahua, TVCC manufacturer, IP, Analogue and SDI,HD-CVI [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


DAHUA: LOSS LEADER×


 INCREDIBLE DISCOUNTS
on a selection of DAHUA products
 Check out the promo now >>

DAHUA 8X8×


  DAHUA 8MEGAPIXEL
8MEGAPIXEL CAMERAS WITH

 QUANTITY DISCOUNT   AND  FREE SHIPPING!
 DISCOVER THEM NOW >>

CLEARANCE SALE ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

OUTDOOR CAMERA 5MEGAPIXEL 3.6MM - STARLIGHT - SMART IR 30M - WDR 120dB - MICROPHONE - IP67 - DAHUA - HAC-HDW2501TLMQ-A-S2

Made by Dahua

5MP Eyeball Starlight 4in1 outdoor Dahua camera - HAC-HDW2501TLMQ-A-S2
4in1: HDCVI / HDTVI / AHD / ANALOG switchable via DIP Switch via BNC port - 5Megapixel 5MP - 3.6mm fixed lens - 1 / 2.7 "5MP 2880 (H) × 1620 (V) CMOS sensor with Starlight Technology - Smart IR 1 LED 30m - WDR 120dB / AGC / BLC / HLC / Mirror Mode / Privacy Masking on 8 rectangular areas - Microphone - Power supply NOT included - 24 months warranty

Product details

- Dahua outdoor surveillance camera - HAC-HDW2501TLMQ-A-S2
- 4 Technologies in 1: HDCVI / HDTVI / AHD / ANALOG
- Switchable technologies through dip switches on BNC port
- Resolution: 5Megapixel 5MP 2880 (H) × 1620 (V)
- 1 / 2.7 "CMOS image sensor with Starlight technology
- Starlight technology: Color night vision
- 3.6mm fixed lens
- Functions: Day / Night (ICR), BLC, HLC, AGC, Mirror Mode, Privacy Masks on 8 rectangular areas
- WDR 120dB
- OSD Multilingual menu
- Built-in microphone
- IP67 protection (Rain / Diving) ideal for outdoor use
- Smart IR 1 LED 30m illuminator
- 1 high definition BNC video output
- 12V DC power supply (not included)
- Material: Dome and cover in metal and decorative ring in plastic
- Supported operating temperature: –40 ° C to + 60 ° C (–40 ° F to + 140 ° F); <95% (non-condensing)
- Dimensions: φ109.9mm × 88.1mm (φ4.33 "× 3.47")
- Weight: 0.34 kg (0.75 lb)
- 24 months warranty

Data sheet

HAC-HDW2501TLMQ-A-S2

Room

Image Sensor

1 / 2.7 inch CMOS

Max. Resolution

2880 (H) × 1620 (V)

Pixel

5 MP

Scanning System

φ109.9mm × 88.1mm (φ4.33 "× 3.47")

Net Weight

0.34 kg (0.75 lb)

Gross Weight

0.45 kg (0.99 lb)

Further details

Quadruple hybrid technology

This camera is a QUADRIBRID (4 Integrated Technologies)
These cameras are at the same time, Analog , Ahd , HDCVI and HDVI .

Tecnologia AHDTecnologia HDCVITecnologia HDTVI

Switch Technologies:

The camera can switch from HDCVI to HDTVI, AHD or Analog via dip switch on coaxial cable

Risoluzione 5.0 Megapixel (2560x1920)

5MP resolution, means 12 times the resolution of a common D1 camera :
It guarantees adequate resolutions for any need.

Resolution: 2880 (H) × 1620 (V)

Ottica fissa This camera features a fixed 3.6mm lens


1 / 2.7 "CMOS sensor with STARLIGHT technology.

Low brightness, visibility at 0.0001Lux, color vision even in night mode

With this CMOS sensor it is possible to have color shots even in night mode.

Normally, when entering night mode, the color vision becomes black / white

With the Starlight SENSOR in this camera, night shots will be sharp and in color!

Esempio di visione notturna in presenza di sensore con tecnologia starlight

Illuminatore IR fino a 80mt

1 LED infrared illuminator with a maximum range of approximately 30m

SMART IR technology.
The light emitted by the LEDs is adapted according to the framed object.

ULTRA WDR up to 120dB
WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light / shadow contrast. Fundamental in the case of shots from the inside out, license plates, shaded spots or all situations where there is no homogeneity of light.

Microfono integrato

This camera has a built-in microphone
Allows you to adapt the lens to Night / Day vision

ICR The IR CUT FILTER is a mechanical filter that allows a correct display of images in daylight viewing conditions. It filters the typical infrared frequencies thus improving the image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies.
Immagine esempio IR CUT FILTER
BLC (Back Light Compensation) is one of the 3 possible steps in the management of images with contrast, typical situations are (entrances or exits from car parks, plates, special lights, entrances with shots from inside to outside, etc.) the compensation of light is one of the most complex operations possible, the BLC function allows a discreet adaptation to these situations


Click to enlarge

AGC_Camera AGC is an integrated signal amplifier that allows viewing even in critical conditions. It is automatic and does not require specific settings.
Protezione IP67 contro polveri e immersioni Protection level IP67 (Dust / Diving)

12VDC_Aliment 12VDC power supply not included
Questo prodotto è coperto da garanzia 24 mesi italiana

This product is covered by a 24 month warranty.

Download

Download the English brochure
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
