HYUNDAI 3.1MM THERMAL BULLET CAMERA - TWO-WAY AUDIO - PoE - HYUNDAI
Product details
|
HYUNDAI CATALOG: Are you looking for a HYUNDAI product but couldn't find it on our site? Don't worry, we can supply you with ALL Hyundai products: consult the CATALOG or contact us by email. |
| THERMAL DETECTION |
|---|
|
|
 |
This camera is equipped with 3.1mm fixed lens People detection : 91m; recognition: 23m; ID: 11m Vehicle detection : 280m; recognition: 70m; ID: 35m. |
 |
This camera is a THERMAL CAMERA, with sensitivity <40mK.
|
 |
The advantage of a PoE camera is obvious, it allows it to be powered with the same cable with which it communicates without carrying additional power cables and without having to install a separate power supply system, a PoE camera guarantees constant voltages and simple installation. |
 |
This camera features Two Way Audio |
  |
This camera has advanced smart features:
|
 |
This camera has 1 input + 1 audio output |
 |
This Camera with 2x Inputs and 2x Alarm Output |
 |
Metal casing. |
 |
Lightning protection. |
 |
IP66: Guarantees protection from dust and water jets (rain) |
 |
This product is covered by a 3 Year Warranty! |
Data sheet
| Model | HYU-660 |
| DESCRIPTION | |
| Camera equiped with high sensibility thermal sensors and a graphic processor wich executes Video Content Analisys algorythm. | |
| This camera is an excellent solution for indoor and outdoor short range perimeter detection, fire prevention, predictive mantainance and other applications. | |
|
THERMAL ROOM |
|
|
FPA Sensor |
Uncooled Oxide Vanadium |
| Thermal Resolution | 160x120 (improved to 320x240) |
| Pixel Size | 17μm |
| Thermal Sensibility (NETD) | <40 mk (@ 25 ° C, f / 1.0) |
| Spectral Range | 8 μm ~ 14 μm |
| Focal Distance | 3.1 mm |
| MRAD | 5.48 mRad |
| Viewing Angle | 50 ° x 37.2 ° |
| Minimum focus Distance | 0.2 meter |
| Openings | F / 1.1 |
| Effective distance on people | Detection (91 m), recognition (23 m), ID (11 m) |
| Effective distance on vehicles | Detection (280 m), recognition (70 m), ID (35 m) |
| INTELLIGENT FUNCTIONS | |
| VCA | up to 8 VCA rules up to 4 tipologies (tripwire, intrusion, entrance and exiting region) |
| Temperature Range | -20 ° C ~ 150 ° C |
| Accuracy temperatures |
± 8 ° C |
| Fire detection | Dynamic fire point detection, up to 10 fire points detectable |
| IP COMMUNICATION & INTEGRATION | |
| Video Compression |
H.265 / H.264 / MJPEG, H.265 + / H.264 + (baseline / main / high profile) |
| Stream |
|
| Audio Compression |
G.711u / G.711a / G.722.1 / MP2L2 / G.726 / PCM |
| LAN |
1x RJ45 10 / 100M auto-adaptive |
| Internet Protocols |
IPv4 / IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| Displays | Up to 20 simultaneously |
| Users | Up to 32 users ? 3 levels: administrator, operator, user |
| Compatibility |
API, ISAPI and third party management gateway |
| Alarm | 2 in / 2 out |
| Audio | 1 in / 1 out |
| Storage |
MicroSD / SDHC / SDXC card slot (up to 128 GB), with support with manual recording or alarm |
| BNC |
BNC output 1.0V [pp] / 75Ω (PAL / NTSC) |
| ELECTRICAL & ENVIRONMENTAL | |
| Power Supply | 12V DC (± 20%), PoE 802.3at, class 4 |
| Consumption | 1.7A, max. 8W (12V DC) |
| Working Temperature | -40 ° C ~ + 65 ° C |
| RH |
≤90% (without condensation) |
| Protection Grade |
IP66 |
| PHYSICAL FEATURES | |
| Material |
Metal case |
| Dimensions | 113.5 (W) x 113 (H) x 352.4 (L) mm |
| Weight | 1.45 g |
| Wall Mount and tube base | included |
| NOTE | The effective distance values shown are nominal values and should be used as an estimate. Consult your sales representative to find out the recommended detection distances with our Vaelsys perimeter system. |
