HYU-610 Hyundai camera - IR 50 meters for outdoors
2MP 1 / 2.8 "CMOS Sensor - FULL HD - 2.8mm Fixed Lens - H.265 - OSD,
AWB, AGC, 3D-DNR, BLC, WDR 120 dB, IP67- 12V DC - Line crossing - Intrusion detection
HYUNDAI 2 MEGAPIXEL DOME CAMERA WITH 2.8 mm FIXED OPTICS - IR50 - IP67 - ONVIF® - PoE
![Hyundai Hyundai Security](https://www.setik.biz/storage/images/Articoli/Hyundai_logo_blu.jpg)
Product details
![Hyundai products Gamma di prodotti Hyundai](https://www.setik.biz/storage/images/Articoli/hyundai_banner_2.jpg)
HYUNDAI CATALOG: Are you looking for a HYUNDAI product but couldn't find it on our site? Don't worry, we can supply you with ALL Hyundai products: consult the CATALOG or contact us by email. |
![]() |
ONVIF® STANDARD All Onvif, the absolute standard for IP cameras, being Onvif guarantees compatibility with any modern recording system. NOT being Onvif means having a camera for its own sake that can never be used together with recording systems. |
![]() |
PoE - Power over Ethernet The advantage of a PoE camera is obvious. It allows it to be powered with the same cable with which it communicates without bringing additional power cables and without having to install a separate power supply system. A PoE camera guarantees constant voltages and simple installation. |
|
FIXED OPTICS This camera is equipped with 2.8mm fixed lens |
|
IR LIGHTING IR illuminator and maximum range 5 0 meters ! |
|
OSD MENU The camera has an OSD menu , through which it is possible to manage and adjust some functions such as: AWB, AGC, ATW, 3D-DNR, etc. |
![]() |
INTELLIGENT FUNCTIONS This camera has intelligent functions:
|
![]() |
DAY / NIGHT Day / Night: allows you to adapt the lens to night / day vision, and the relative automatic management of the IR illuminator, when present. |
![]() |
BLC (Back Light Compensation) It is one of the 3 possible steps in the management of images with contrast, typical situations are (entrances or exits from car parks, plates, special lights, entrances with shots from inside to outside, etc.) light compensation is one of the most complex possible, the BLC function allows a fair adaptation to these situations |
![]() |
AGC - Signal amplifier AGC is an integrated signal amplifier that allows vision even in critical conditions. It is automatic and does not require specific settings. |
![]() |
ULTRA WDR up to 120dB WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light / shadow contrast. Fundamental in the case of shots from the inside out, license plates, shaded spots or all situations where there is no homogeneity of light. |
![]() |
IP67: Guarantees protection from dust and immersion |
![]() |
A 12VDC power supply is required for the operation of this camera (not included) ![]() |
![]() |
This product is covered by a 3 Year Warranty! |
Data sheet
Model | HYU-610 | |
Room | ||
Image Sensor | CMOS 1 / 2.8 "of 2 megapixels | |
Digital resolution | 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), etc. | |
Frames per second | 25 fps @ 1080P | |
Stream | Main Stream: 1080P / 1.3MP / 720P (25 fps) Secondary Stream: D1 / VGA / CIF (25 fps) |
|
Compression | H.265 / H.264 / MJPEG | |
OSD | Yes | |
White balanc | Yes | |
Automatic Gain Control | Yes | |
Min. Illumination | 0.009 lux F1.6 color (AGC On) | |
IR Illumination | IR 50 meter | |
Fixed Lens | 2.8 mm | |
Viewing angle | 108 ° (H), 58 ° (V) | |
Day / Night | Yes | |
Backlight Compensation | WDR 120dB | |
Noise reduction | 3D noise reduction | |
Other | Adjustment of brightness, saturation, contrast, sharpness, gain control and white balance through client software and web browser | |
Smart functions | Detection of line crossing, intrusion detection, detection of entry or exit to region, false alarm filter by objective classification | |
AIsense | False alarm filter by objective classification | |
Micro SD | MicroSD / SDHC / SDXC card slot up to 128GB (card not included) | |
Network protocol | TCP / IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1x, QoS, IPv6, UDP, Bonjour | |
Network interface | RJ45 (10/100 Base-T) | |
Onvif | Compatible with ONVIF® (Profile S, G), ISAPI | |
Plug & Play | Plug & Play connection with NVR NEXTGEN | |
DDNS | Compatible with DDNS DEMES | |
PoE | Supports PoE 802.3af | |
Power Supply | 12V DC | |
Power Consumption | 0.6A, max. 7W | |
Working Temperature | -30 ° C ~ + 60 ° C | |
Humidity | 95% (without condensation) | |
Protection Level | IP67 | |
Case material | Metal | |
Dimensions | Ø130 x 105 mm | |
3AXIS | 0 ° ~ 360 ° (PAN), 0 ° ~ 70 ° (TILT), 0 ° ~ 360 ° (Rotation) |
