HYU-657 Hyundai PRO HDTVI dome outdoor video surveillance camera. CMOS sensor, 2 MP 2Megapixel resolution and 2.8 ~ 12mm Varifocal lens Motorized . The Smart IR 40M illuminator with EXIR 2.0 Technology , OSD, ATW, MWB, AGC, BLC, WDR digital, 2D-DNR, image adjustment, Supports PoC
![](https://cdn.setik.biz/img/click.png)
OUTDOOR CAMERA HYUNDAI HDTVI DOME 2 MEGAPIXEL 2.8 ~ 12MM MOTORIZED
![Hyundai Hyundai Security](https://www.setik.biz/storage/images/Articoli/Hyundai_logo_blu.jpg)
Resolution 2 MP 2Megapixel - 2.8 ~ 12mm Varifocal lens Motorized - CMOS sensor
40M Smart IR LED Illuminator with EXIR 2.0 Technology - OSD, ATW, MWB, AGC, BLC, WDR digital, 2D-DNR
Extended Warranty 3 Years Hyundai! - Supports PoC
Product details
![Hyundai products Gamma di prodotti Hyundai](https://www.setik.biz/storage/images/Articoli/hyundai_banner_2.jpg)
HYUNDAI CATALOG: Are you looking for a HYUNDAI product but couldn't find it on our site? Don't worry, we can supply ALL Hyundai products: consult the CATALOG or contact us by email. |
![]() |
HD-TVI is one of the technologies present in the world of video surveillance. |
![]() |
POC - POWER OVER COAX: This new technology allows to power common coaxial cameras directly via the video cable, on which the signal is sent using the same transmission medium. This technical concept is very similar to PoE, already widely used on IP devices and even earlier on old analog phones. The coverage in terms of distance of this technology depends on the quality of the cable and the power required by the camera, in any case the guaranteed distances are greater than those of the typical 12V power supplies, which have a much greater loss. Below you will find a table purely indicative of Dahua: |
![]() |
5MP resolution, means 12 times the resolution of a common D1 camera :
|
![]() |
This camera features a 2.8mm-12mm motorized Varifocal lens |
|
Smart IR Illuminator and Smart IR 2.0 Technology Maximum range 40 meters
EXIR 2.0 TECHNOLOGY
This technology remedies the classic ailments of the traditional IR illuminator . In detail:
1) NO IR REFLECTION OR BLEEDING:
Having the IR LEDs positioned separately from the camera lens, the possible internal reflections of IR and IR Bleeding, a serious problem on dome cameras due to the presence of the glass dome, are completely eliminated.
2) BEST IR COVERAGE: Usually, the IR is integrated into a circular apparatus with various LEDs around the lens.
This often resulted in a circular area overexposed to the center of the image and underexposed corners due to uneven IR coverage. The rectangular EXIR LEDs provide a much more even coverage across the entire image, eliminating this issue.
3) LESS PROBLEMS WITH SPIDERS / INSECTS: Spiders and other insects tend to be attracted to the heat of the warmer IR LEDS in non-EXIR cameras. This problem decreases with EXIR cameras, even more so with flat-faced EXIR cameras, on which the contact surfaces are clearly smaller.
|
|
The camera has an OSD menu , through which it is possible to manage and adjust some functions such as: AWB, AGC, ATW, 2D-DNR etc.
|
![]() |
This camera has autofocus |
![]() |
Day / Night: allows you to adapt the lens to night / day vision, and the relative automatic management of the IR illuminator, when present. ![]() |
![]() |
The IR CUT FILTER is a mechanical filter that allows correct display of images in daytime viewing conditions, filtering the typical infrared frequencies, thus improving the image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies. |
![]() |
BLC (Back Light Compensation): it is one of the 3 possible steps in the management of images with contrast, typical situations are: entrances or exits from parking lots, plates, special lights, entrances with shots from inside to outside, etc. Light compensation is one of the most complex operations possible, the BLC function allows a discreet adaptation to these situations ![]() |
![]() |
AGC is an integrated signal amplifier that allows viewing even in critical conditions. It is automatic and does not require specific settings. |
![]() |
ATW (Auto Tracing White Balance), refers to a modern technology that automatically and continuously adjusts the color balance of the camera according to the color temperature . The ATW is a more advanced function than the AWB (Auto White Balance), and it is very important since in the absence of it, the images could be completely unusable. Possibility to adjust the color balance also manually (MWB) |
![]() |
IP67 protection level (Dust / Immersion) |
![]() |
A 12VDC power supply is required to operate this camera (not included) ![]() |
![]() |
This product is covered by a 3 year warranty! |
Data sheet
Model | HYU-657 |
Room | |
Image Sensor | 2MP CMOS image sensor |
Digital Resolution | 2MP 1080P (1920x1080) at 25 fps |
Min. Illumination | 0.01 lux F1.2 (color, AGC On) / 0 lux IR On |
RIP | Built-in PIR Alarm Detector (11m, 110 °) with White Alarm LED |
Lens | 2.8 ~ 12 mm |
Day / Night | ICR |
OSD | yes (coaxial - up to 300m) |
IR Illuminator | Smart IR: 40 meters - EXIR 2.0 Technology |
Ingress Protection | IP67 |
Power Supply | 12V DC (± 25%) |
Power Consumption | 8W |
Working Temperature | -40 ° C ~ + 60 ° C |
Humidity | ≤90% |
Dimensions | Ø134.3 x 123.9 x 111.4 mm |
Weight | 750 g |
