4K Ultra HD Eyeball Camera - 2.8mm Lens - Microphone - 4in1 - Smart IR 30m

4K Ultra HD Eyeball Camera - 2.8mm Lens - Microphone - 4in1 - Smart IR 30m
-57%

Lite Series | Dahua HAC-HDW1800TLM-A - Outdoor Eyeball Camera. - 4 technologies in 1: CVI / TVI / AHD / Analog switchable on a single BNC port - 4K Ultra HD 3840x2160p resolution - 2.8mm fixed lens - 4K CMOS sensor - Smart IR illuminator up to 30m, also suitable for outdoor environments (IP67 protection) - DWDR - 3DNR - HLC - BLC - Day/Night(ICR) - Built-in microphone - Made of metal.

Reference: HAC-HDW1800TLM-A

Brand: Dahua

EAN: 6923172529435

Manufacturer Object ( [id] => 13 [name] => Dahua [description] =>

The Asian Company, born in 2001, is famous because of the excellent quality of its product in terms of performances and potential.

The range of products made by Dahua includes not only classic CCTV systems but also more complex and articulate systems: not only video surveillance, indeed, but also access control, video intercoms, thermal cameras and much more.

The reliability, the cutting-edge technologies and the competitive prices offered by Dahua are only some of the reasons why Setik has always chosen to distribute this brand. Dahua has been for years a reference point in the international CCTV market, due to the huge investments dedicated every year to Research and Development. Numbers are clear: since 2016, Dahua has registered more than 800 patents with its own brand.

The Dahua-branded products sold by Setik Srl could eventually be delivered as OEM: this means that the items are absolutely original and made by Dahua, but characterized by a different aesthetic look reserved for the online market (generally as far as the logo and the package are regarded).

This has no effects on the warranty and on the technical specifications nor even on the possible updates and functionalities, because the products are authentic Dahua’s ones.

[short_description] =>

Videosorveglianza Dahua

Zhejiang Dahua Technology Co., Ltd. is one of the leading solution providers in video surveillance industry, with more than 13,000 employees and 35 active branches all over the world.

[id_address] => [date_add] => 2012-07-14 17:53:54 [date_upd] => 2025-03-19 12:15:55 [link_rewrite] => dahua [meta_title] => Best Dahua Products: DVR, HCVR,NVR, IPC,SD,PTZ,HDCVI, [meta_keywords] => dahua, dahuatech, dahua distribution, dahua national supplier [meta_description] => Dahua, TVCC manufacturer, IP, Analogue and SDI,HD-CVI [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


DAHUA: LOSS LEADER×


 INCREDIBLE DISCOUNTS
on a selection of DAHUA products
 Check out the promo now >>

DAHUA 8X8×


  DAHUA 8MEGAPIXEL
8MEGAPIXEL CAMERAS WITH

 QUANTITY DISCOUNT   AND  FREE SHIPPING!
 DISCOVER THEM NOW >>

CLEARANCE SALE ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

HAC-HDW1800TLM-A | EYEBALL 4K ULTRA HD 2.8MM SUPER ADAPT CAMERA - DWDR - FOR OUTDOORS - S6 VERSION

Made by Dahua
Dahua Bullet Camera - Lite Series | HAC-HDW1800TLM-A
S6 Version - 2MP Full HD 1080p 1920x1080p resolution - 2.8mm fixed lens - 4 technologies in 1 (HDCVI / HDTVI / AHD / ANALOG switchable - 30m IR illuminator with 1LED IR Light - Day/Night (ICR) - BLC - HLC - DWDR - 2DNR - Mirror Mode - Privacy Masking - IP67 protection grade (ideal for use even in outdoor environments) - Dimensions: φ94.0 mm × 85.7 mm - Material: Metal body.

Product details


  • Dahua 4in1 bullet camera - Lite Series - HAC-HDW1800TLM-A
  • 4 Technologies in 1: HDCVI / HDTVI / AHD / ANALOG switchable on single BNC port
  • Ultra HD 4K 3840x2160p progressive scan resolution
  • 4K CMOS Sensor
  • Fixed optics 2.8mm
  • Functions: Day/Night(ICR), BLC, DWDR, 2DNR, Mirror Mode, Privacy Masking
  • Built-in microphone
  • Smart IR Illuminator up to equipped with 1 IR LIGHT Illuminators
  • IP67 Protection (Rain / Immersion) - Also suitable for outdoor environments!!
  • Dimensions: ?94.0 mm × 85.7 mm (?3.70" × 3.37")
  • Metal body
  • Operating temperature: –40 °C to +60 °C
  • Product net weight: 0.33 kg
  • Power supply: 12 VDC ± 30% (power supply not included)
  • 24 month manufacturer's warranty

Technical data sheet

HAC-HDW1800TLM-A

Room

Image Sensor

4K CMOS

Max. Resolution

3840 (H)× 2160 (V)

Pixel

8 MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25 s–1/100,000s
NTSC: 1/30 s–1/100,000 s

Y/N Ratio

> 65 dB

Min. Illumination

0.03Lux/F2.0, 30IRE, 0Lux IR on

Illumination Distance

30 m (98.4 ft)

Illuminator On/Off Control

Car; manual

Illuminator Number

1 (IR light)

Pan/Tilt/Rotation Range

Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°

Lens

Lens Type

Fixed lens

Mount Type

M12

Focal Length

2.8mm

Max. Openings

F2.0

Field of View

H:105° V:56° D:125°

Iris Type

Fixed

Fixed opticsThis camera features a 3.6mm fixed lens
Illuminatore IR fino a 80mt

Infrared illuminator with approximate maximum range of 30m

This camera also features SMART IR technology.
Through this technology , the light emitted by the LEDs is adapted depending on the object being framed.

Smart IR Technology

Allows you to adapt the lens to Night/Day vision

ICR The IR CUT FILTER is a mechanical filter that allows correct viewing of images in daytime viewing conditions. It filters the typical infrared frequencies, thus improving image quality. In nighttime conditions, the filter is removed as it is necessary to capture the typical IR frequencies.
Immagine esempio IR CUT FILTER
BLC (Back Light Compensation) is one of the 3 possible steps in the management of images with Contrast, typical situations are (Entrances or exits from parking lots, License plates, Special lights, Entrances with shots from the inside towards the outside, etc.) the light compensation is one of the most complex operations possible, the BLC function allows a fair adaptation to these situations


Click to Enlarge

Protezione IP67 contro polveri e immersioni Protection level IP67 (Dust / Immersion)

12VDC_Power 12VDC power supply not included
Questo prodotto è coperto da garanzia 24 mesi italiana

This product is covered by a 24 month warranty.

Download

Download the English Brochure
Schema dettagliato con le dimensioni della telecamera HAC-HFW1500TLM-IL-A-S2
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
