Dahua Dome IP Camera 5MP Varifocal 2.7mm-13.5 IP67 IK10 IR40m - Dahua

Dahua IPC-HDBW2541R-ZS-S2 5 Megapixel ONVIF PoE outdoor IP camera, 2.7-13.5mm motorized varifocal dome, 1/2.7" C MOS H.265+ . Smart IR illuminator 2 LED 40M, WDR 120dB , Video Analysis , Day/Night Auto(ICR)/Color/B/W , ROI, MicroSD slot (max.256 GB), IP67/IK10 protection.

Reference: IPC-HDBW2541R-ZS-S2

Brand: Dahua

FIND INSTALLER

Description Product Details Technical Sheet Further Details Download

DAHUA ONVIF® POE 5MEGAPIXEL VARIFOCAL MOTORIZED DOME IP OUTDOOR CAMERA

Dahua ONVIF® PoE Outdoor IP Camera
5Megapixel Resolution - 2.7-13.5mm Motorized Lens - 1/2.7" CMOS with Starlight Technology - H.265+
Smart IR illuminator 2 LEDs 40M - Day/Night Auto(ICR)/Color/B/W - WDR 120dB - ROI - Video Analysis
12V DC/PoE power supply (802.3af) (not included) - MicroSD slot max 256 GB (not included) - 24 months warranty

Product details

ONVIF® PoE Outdoor Dome IP Camera - Dahua
Resolution: 5Megapixel
1/2.7” progressive CMOS image sensor
Varifocal optics 2.7-13.5mm
Video compression up to H.265+
Functions: WDR(120dB) , Day/Night Auto(ICR)/Color/B/W , 3D NR,BLC, HLC
Video Analysis Functions: Perimeter Protection, Intelligent Search, Human and Vehicle Classification
Smart IR illuminator 2 LEDs 40M
Remote Visibility. DMSS Application
IP67 Protection (Dust/Immersion)
IK10 Protection (Vandalism)
Suitable for indoor/outdoor environments
MicroSD slot (Max 256GB - not included)
Dimensions: 93.4mm × Φ122mm
Power supply 12V DC ( not included )
24 Months Italian Warranty

Technical data sheet

Room

Image Sensor

1/2.7" CMOS

Max. Resolution

2960 (H) × 1668 (V)

ROM

128 MB

RAM

256 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

0.007 lux@F1.5 (Color, 30 IRE)
0.0007 lux@F1.5 (B/W, 30 IRE)
0 lux (Illuminator on)

Y/N Ratio

>56dB

Illumination Distance

40 m (131.23 ft) (IR)

Illuminator On/Off Control

Auto; Manual

Illuminator Number

2 (IR LEDs)

Pan/Tilt/Rotation Range

Pan: 0°–355°
Tilt: 0°–75°
Rotation: 0°–355°

Lens

Lens Type

Motorized vari-focal

Lens Mount

φ14

Focal Length

2.7mm–13.5mm

Max. Openings

F1.5

Field of View

H: 113°–31°; V: 58°–18°; D: 138°–36°

Iris Control

Fixed

Close Focus Distance

0.8 m (2.62 ft)

Intelligence

IVS (Perimeter Protection)

Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)

Smart Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)

Smart Codec

Smart H.265+; Smart H.264+

Video Frame Rate

Main stream: 2960 × 1668 @(1–20 fps )/2688 × 1520@(1–25/30 fps)
sub stream: 704 × 576 @ (1–25 fps)/704 × 480 @(1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Stream Capability

2 streams

Resolution

2960 × 1668 (2960 × 1668); 2880 × 1620 (2880 × 1620); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280×960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Bitrate Control

CBR/VBR

Video Bitrate

H.264: 32kbps–8192kbps
H.265: 12kbps–8192kbps

Day/Night

Auto(ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

120dB

White Balance

Car; natural; street lamp; outdoor; manual; regional custom

Gain Control

Auto; Manual

Noise Reduction

3D NR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

Yes (4 areas)

Smart Lighting

Yes

Image Rotation

0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)

Mirror

Yes

Privacy Masking

4 areas

Audio

Built-in MIC

Yes

Audio Compression

G.711a; G.711Mu; PCM; G.726

Alarm

Alarm Event

No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; defocus detection; external alarm (Only - ZAS supports); SMD; security exception

Network

Network Port

RJ-45 (10/100Base-T)

SDK and API

Yes

Network Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Boujour

Interoperability

ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestones

User/Host

20 (Total bandwidth: 48M)

Storage

FTP; SFTP; Micro SD card (support max. 256GB); NAS

Browser

IE; Chrome; Firefox

Management Software

Smart PSS; DSS; DMSS

Mobile Client

iOS; Android

Cyber Security

Configuration encryption; trusted execution; Digests; security logs; WSSE; account lockout; syslog; video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certification

Certification

Certifications

CE-LVD: EN62368-1;

CE-EMC: Electromagnetic Compatibility Directive

2014/30/EU;

FCC: 47 CFR FCC Part 15, Subpart B;

UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14

Port

Audio Input

1 channel (RCA port) (Only - ZAS supports)

Audio Output

1 channel (RCA port) (Only - ZAS supports)

Alarm Input

1 channel in: 5mA 3V–5V DC (Only - ZAS supports)

AlarmOutput

1 channel out: 300mA 12V DC (Only - ZAS supports)

Power

Power Supply

12VDC/PoE (802.3af)

Power Consumption

-ZS:
Basic: 2.4W (12VDC); 3W (PoE)
Max. (H.265+ max. resolution + max. stream+ WDR + IR intensity + IVS): 6.1 W (12 VDC); 7.3W (PoE)
-ZAS:
Basic: 2.4W (12VDC); 3W (PoE)
Max. (H.265+ max. resolution + max. stream+ WDR + IR intensity + IVS): 6.2 W (12 VDC); 7.4W (PoE)

Environment

Operating Temperature

–30 °C to +60 °C (–22 °F to +140 °F)

Operating Humidity

≤95%

Storage Temperature

–40 °C to +60 °C (–40 °F to +140 °F)

Storage Humidity

≤95%

Protection

IP67; IK10

Structure

Casing Material

Metal

Product Dimensions

93.4 mm × Φ122 mm (3.68" × Φ4.80")

Net Weight

-ZS: 0.50 kg (1.10 lb)
-ZAS: 0.51 kg (1.12 lb)

Gross Weight

-ZS: 0.66 kg (1.46 lb)
-ZAS: 0.67 kg (1.48 lb)

Further details

	All Onvif , the absolute standard for IP cameras, being Onvif guarantees compatibility with any modern recording system. NOT being Onvif, means having a camera that is an end in itself that can never be used together with recording systems This camera supports Onvif version
	The advantage of a PoE camera is clear, it can be powered with the same cable with which it communicates without carrying additional power cables and without having to install a separate power system, a PoE camera guarantees constant voltages and simple installation.
	Smart H.265+ Smart H.265+ is the optimized implementation of H.265 codec that uses scene-adaptive coding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ greatly reduces bit rate and storage requirements compared to standard H.265 compression.
	5MP resolution, means 12 times the resolution of a common D1 camera : It ensures adequate resolutions for any need.
	This camera features a 2.7-13.5mm varifocal lens with motorized zoom. Motorized zoom example:
	1/2.7" CMOS sensor With the SENSOR present, night shots will be in color
	This camera features VIDEO ANALYSIS / SMART DETECTION: - Line crossing recognition - Intrusion recognition
	Infrared illuminator with range up to 40 meters! This camera also features SMART IR technology. Through this technology, the light emitted by the LEDs is adapted depending on the object being framed.
	Remote visibility on mobile using Dahua DMSS application.
	ULTRA WDR up to 120dB WDR (Wide Dynamic Range): This is the professional solution when you need to work in high light/shadow contrast conditions. It is essential when shooting from inside to outside, license plates, shadowed areas or any situation where there is no homogeneity of light.
	This camera has ROI function. Images from IP cameras are “compressed”, so the quality is set during recording. Especially on cameras with very high resolution, it is often necessary to reduce the quality in order to ensure a reduced bandwidth occupation and record a greater number of days or cameras. The ROI allows you to define areas where you can set a higher quality (for example a door, the area where the license plate usually passes, an exit, etc.). In that area I can set a higher quality , thus ensuring a higher definition of the image.
	It allows you to adapt the lens to Night/Day vision and the consequent automatic management of the IR illuminator.
	The IR CUT FILTER is a mechanical filter that allows correct viewing of images in daytime viewing conditions. It filters the typical infrared frequencies, thus improving image quality. In nighttime conditions, the filter is removed as it is necessary to capture the typical IR frequencies.
	BLC (BACK LIGHT COMPENSATION) is one of the 3 solutions for managing images with contrast. The BLC function allows a discrete adaptation to all those situations where shooting is difficult (Entrance or exit of parking lots, shooting of license plates, presence of particular lights etc...).
	3D-NR is the most advanced version of Noise Reduction management, it allows still images in low light and in motion, the most powerful solution currently available for obtaining maximum results in low light.
	Possibility to insert Micro SD up to a maximum of 256GB (not included)
	Protection level IP67 (Dust / Immersion)
	IK 10 is the highest level of protection from direct damage. This allows the camera to be used even if there is a risk of vandalism
	12V DC power supply NOT included!
	This product is covered by a 24 month warranty.
