IP CAMERA FOR PARKING WITH 2.8MM FIXED LENS AND ARTIFICIAL INTELLIGENCE - DAHUA - ITC414-PH5B-TF2

Made by Dahua
4MP IP Parking Camera with Artificial Intelligence - Dahua - ITC414-PH5B-TF2
2.8mm fixed lens - 4MP resolution - WDR100dB - Artificial intelligence: Vehicle recognition, parking space detection, unauthorized parking detection - WDR 100dB, 3D NR, HLC, BLC - For cable tray mounting - IP54 protection - Indicator lights with 7 different colors -


AI TECHNOLOGY | ARTIFICIAL INTELLIGENCE:

Artificial intelligence (AI) refers to the branch of science and engineering that produces intelligent machines, especially intelligent computer programs. In the security sector, however, the AI used is that which allows the creation of advanced devices, for environmental analysis.

This camera allows:
vehicle detection and recognition,
free space detection
the detection of unauthorized parking.

Product details


- 4MP AI IP Parking Camera - Dahua - ITC414-PH5B-F2
- Resolution: 4MP
- Image sensor 1/1.3” progressive scan CMOS
- 2.8mm fixed optics
- Video Compression up to H.265 for storage space optimization
- WDR 100dB
- ARTIFICIAL INTELLIGENCE:
Vehicle recognition
Detect available space
Illegal parking detection
- 7 LED indicators with differentiated colors
- 3D NR, HLC, BLC
- RS485
- IP54 protection
- Size: 120mm × 136mm × 105mm
- Net weight: 0.5Kg
- Can be installed on cable tray
- Operating temperature: –20 °C to +50 °C
- 24 month warranty

Technical data sheet

ITC414-PH5B-F2

Basic

Image Sensor

1/3" CMOS

Max.Detection Space

6

Parking Space Indicator

1, 7 customizable colors (red, yellow, blue, green, cyan, white, and pink)

Image Resolution

2688 (H) × 1520 (V) (OSD black background is not calculated in the pixels)

2 × RJ-45 Ethernet port, 100M network transmission

Power Output

12 VDC ± 10% voltage output, ≤1 A current output


Further details

AI | Artificial Intelligence
This camera features Artificial Intelligence on board

Allows:
Vehicle detection and recognition
available space detection
illegal parking detection

AI Camera - Cattura del volto

This camera has a resolution of 4Mpx 2560x1440

This camera has a resolution of 4Megapixel.

Fixed optics

This camera features a 2.8mm fixed lens

WDR at 100dB
WDR (Wide Dynamic Range): It is the professional solution in cases where you have to operate in conditions of high light/shadow contrast. Fundamental in case of shooting from inside to outside, license plates, shadowed points or all situations where there is no homogeneity of light.


RS485 interface present, for connecting external devices such as radar.

Questo prodotto è coperto da garanzia 24 mesi italiana

This product is covered by a 24 month warranty.

Download

Download the English Brochure
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
