ONVIF POE IP Camera - Panoramic and PTZ - Dahua - SDT5X425-4Z4-FA-2812 - Resolution up to 4MP 2688×1520 - Overview: 2.12mm varifocal lens, 1/1.8" 4MP CMOS sensor, IR 30m - Detail: 5.4-135mm lens, 1/1.8" 4MP CMOS sensor, IR100m - WDR 120dB - AWB - HLC - BLC - Defog - ROI, 3DNR - Artificial intelligence - Audio - Alarm - RJ45 - IP67 outdoor protection and TVS 8000 lightning protection - 512GB MicroSD slot (not included) - Supports Hi-PoE power supply.
FIND INSTALLER
€2,950.88
€6,862.50 -57%PRODUCT NOT AVAILABLE, DISCOUNT NOW 3%
LO HAI TROVATO A MENO?
Scrivici dove e ti sconteremo la differenza fino a fine mese!
ONVIF POE IP CAMERA - PANORAMIC AND PTZ - DUAL LENS AND DUAL CMOS SENSOR - ARTIFICIAL INTELLIGENCE - AUDIO - ALARM - DAHUA - SDT5X425-4Z4-FA-2812
Product details
- Hybrid PTZ and Panoramic Camera - Dahua - SDT5X425-4Z4-FA-2812
- Resolution 4MP 2688*1520
- 2.8-12mm motorized optics (panoramic)
- 5.4-135mm varifocal lens (detail)
- 1/ 1.8 ” STARVIS CMOS Sensor with Starlight Technology! (for panoramic and detail camera)
- Starlight: Thanks to the sensor, color shots even at night
- ULTRA WDR (120dB) - Day/Night (ICR), BLC, HLC, AGC, AWB, Defog
- Artificial Intelligence: Perimeter Protection and Smart Tracking, Face Detection
- PFA Technology
- 1 audio input and 1 audio output
- 2 alarm inputs and 1 alarm output
- RJ45 100M
- IP67 Protection (Dust / Immersion)
- TVS 8000V lightning protection
- Product net weight: 9Kg
- Operating temperature: –40 °C to +65 °C
- Dimensions: 385mm × Φ277mm
- Hi-PoE Power Supply
- Power supply 36 VDC, 2.23 A (included in the package)
- 5 year manufacturer's warranty
Technical data sheet
| SDT5X425-4Z4-FA-2812 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Room | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor | Panorama: 1/1.8"" CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pixel | Panorama: 4MP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Resolution | Panorama: 2688 (H) × 1520 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ROM | 8 GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM | 4GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed | Panorama: 1 s–1/30,000 s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System | Progressive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Min. Illumination | Panorama: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight | 9kg (19.84lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight | 13.8 kg (30.42 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Further details
 |
| |
 | Onvif, the absolute standard for IP cameras. Being Onvif guarantees compatibility with any modern recording system. NOT being Onvif, means having a camera that is an end in itself and can never be used together with recording systems. This camera is ONVIF® compatible | |
 | This camera features a resolution of 4MP 2688*1520 | |
| Dual 1/1.8" CMOS STARVIS™ sensor with STARLIGHT technology. Low brightness, color vision even in night mode With the Starlight CMOS sensor, you can shoot in color even in night mode. Normally, when entering night mode, the color vision changes to black/white. With the SENSOR present, night shots will be clear and in color
| |
| Double Optics: 2.8-12mm Varifocal with 25x Optical Zoom + 16x Digital Zoom (PTZ, detail) Varifocal 5.4-135mm (detail) | |
 | This camera uses ARTIFICIAL INTELLIGENCE Perimeter Protection: Smart Tracking Face detection | |
 | This camera features AUTO TRACKING function. | |
 | Lighting: Panoramic camera: up to 30m Detail camera: up to 100m | |
 | Supports Intelligent 3D Positioning with DH-SD protocol. This system allows not only movement on the camera axis but also positioning in terms of depth, and the same can be stored in the Presets
| |
 | This camera has 2 inputs and 1 alarm output | |
 | This camera has 1 audio input and 1 audio output. | |
 | Day/Night: allows you to adapt the lens to night/day vision, and the relative automatic management of the IR Illuminator, when present.  | |
 | ULTRA WDR up to 120dB WDR (Wide Dynamic Range): This is the professional solution when you need to work in high light/shadow contrast conditions. It is essential when shooting from inside to outside, license plates, shadowed areas or any situation where there is no homogeneity of light. The higher the value in db, the greater the camera's ability to handle the strong difference in backlighting present. Common WDRs usually reach 80db, the human eye is able to recognize a difference of up to 100db. This model reaches up to 120db, managing very strong levels of contrast.  | |
 | BLC (Back Light Compensation): is one of the 3 possible steps in the management of images with contrast, typical situations are: entrances or exits from parking lots, license plates, particular lights, entrances with shots from the inside towards the outside, etc. Light compensation is one of the most complex operations possible, the BLC function allows a fair adaptation to these situations.  | |
 | 3D-NR is the most advanced version of Noise Reduction management, it allows still images in low light and in motion, the most powerful solution currently available for obtaining maximum results in low light.  | |
 |
| |
 | Protection level IP67 (Dust / Immersion) |
