POE ONVIF IP camera - Panoramic and PTZ - Dahua - SDT5X425-4Z4-QA-0832 - Resolution up to 4MP 2688×1520 - Panoramic: 6mm fixed lens, 1/1.8" 4MP CMOS sensor, IR 30m - Detail: 4.8-120mm lens , CMOS sensor 1/1.8" 4MP, IR100m - WDR 120dB - AWB - HLC - BLC - Defog - ROI, 3DNR - Artificial intelligence - Audio - Alarm - RJ45 - IP67 protection for outdoors and TVS 8000 lightning protection - MicroSD slot 512GB ( not included) - Supports Hi-PoE power supply.



Reference: SDT5X425-4Z4-FA-0832

Brand: Dahua

EAN: 6923169750866

FIND INSTALLER

€2,950.88

€6,862.50 -57%
taxes included
Tax included
 Available in 5 days
 starting

PRODUCT NOT AVAILABLE, DISCOUNT NOW 3%

LO HAI TROVATO A MENO?

Scrivici dove e ti sconteremo la differenza fino a fine mese!

meno


POE ONVIF IP CAMERA - PANORAMIC AND PTZ - DOUBLE LENS AND DOUBLE CMOS SENSOR - ARTIFICIAL INTELLIGENCE - AUDIO - ALARM - DAHUA - SDT5X425-4Z4-QA-0832

Made by Setik
POE ONVIF IP camera - Overview and PTZ - Dahua - SDT5X425-4Z4-QA-0832
Resolution 4MP 2688*1520 - Overview : Varifocal lens 8-32mm, CMOS 1/.1.8" 4MP, IR 30m white light - Detail (PTZ) : Varifocal lens 5.4-135mm, CMOS 1/1.8" 4MP, IR100m - H. 265+ with Triple Stream - WDR 120dB - AWB - HLC - BLC - Defog - ROI, 3DNR, - PFA Technology - Artificial Intelligence - Audio 1in/1out - Alarm 2in/1out - RJ45 100Mbps - IP67 protection, ideal for outdoor use / TVS 8000V from lightning - 512GB MicroSD slot (not included) - Supports HI-POE - Power supply: 36 VDC, 2.23 A (power adapter included).
Artificial Intelligence: Perimeter Protection / Smart Tracking / Face Detection

Product details

Telecamera Videosorveglianza Speed Dome PTZ Dahua
  • Hybrid PTZ and Panoramic Camera - Dahua - SDT5X425-4Z4-QA-0832
  • 4MP 2688*1520 resolution
  • Motorized lens 8-32mm (panoramic)
  • 5.4-135mm varifocal lens (detail)
  • 1/ 1.8 STARVIS CMOS sensor with Starlight Technology! (for overview and detail camera)
  • Starlight: Thanks to the sensor, color shots even at night
  • ULTRA WDR (120dB) - Day/Night (ICR), BLC, HLC, AGC, AWB, Defog
  • Artificial Intelligence: Edge Protection and Smart Tracking, face detection
  • PFA Technology
  • 1 audio input and 1 audio output
  • 2 inputs and 1 alarm outputs
  • RJ45 100M
  • IP67 Protection (Dust / Immersion)
  • TVS 8000V lightning protection
  • Product net weight: 9Kg
  • Operating temperature: –40°C to +65°C
  • Dimensions: 385mm × Φ277mm
  • Hi-PoE power supply
  • Power supply 36 VDC, 2.23 A (included in the package)
  • 5 year manufacturer's warranty

Data sheet

SDT5X425-4Z4-QA-0832

Room

Image Sensor

Panorama: 1/1.8"" CMOS
Detail: 1/1.8"" CMOS

Pixels

Landscape: 4MP
Detail: 4MP

Max.Resolution

Panorama: 2688(H)×1520(V)
Detail: 2688(H)×1520(V)

ROM

8GB

RAM

4GB

Electronic Shutter Speed

Panorama: 1s–1/30,000s
Detail: 1s–1/30,000s

Scanning System

Progressives

Min Illumination

Landscape:
Color: 0.001lux@F1.6
B/W: 0.0001lux@F1.6
Details:
Color: 0.001lux@F1.6
B/W: 0.0001lux@F1.6
0 lux (IR light on)

Illumination Distance

Gross Weight

13.8kg (30.42lbs)

Further details

PoE power supply

The advantage of a PoE camera is evident, it allows it to be powered with the same cable with which it communicates without carrying additional power cables and without having to install a separate power supply system, a PoE camera guarantees constant voltages and simple installation

Standard ONVIF® support

Onvif, the absolute standard for IP cameras. Being Onvif guarantees compatibility with any modern recording system. NOT being Onvif means having a camera for its own sake that can never be used together with recording systems.

This camera is ONVIF® compatible

4MP resolution

This camera features a resolution of 4MP 2688*1520

Double Sensor 1/1.8" CMOS STARVIS™ with STARLIGHT technology.

Low brightness, color vision even in night mode

With the Starlight CMOS sensor it is possible to have color shots even in night mode.

Normally, when entering night mode, the color vision becomes black/white.

With the SENSOR present, night shots will be clear and in colour

Esempio di visione notturna in presenza di sensore con tecnologia starlight

Ottica varifocaleOptical Zoom

Double Optics:
Varifocal 8-32mm with 25x Optical Zoom + 16x Digital Zoom (PTZ, detail)
Varifocal 5.4-135mm (detail)
Artificial Intelligence Technology

This camera involves the use of ARTIFICIAL INTELLIGENCE

Perimeter Protection:

smart tracking

Face detection


This camera features the AUTO TRACKING function.
The system will identify the objects moving in a given video surveillance area and will automatically enlarge it for a better view of the tracked object.

IR illuminator 60MT Lighting:
Panoramic camera : up to 30m
Detail camera : up to 100m
Infrared Illuminator

It supports 3D Intelligent Positioning with DH-SD protocol. In addition to the movement on the camera axis, this system also allows positioning in terms of depth, and the same can be stored in the Presets

Generic PTZ Functions:


Pan/Tilt Range:
Panorama: Pan: 0° to 360° endless Tilt: 0° to 30°
Detail: Pan: 0° to 305° Tilt: –10° to 90°

Manual Control Speed:
Panorama: Pan: 0.1°/s–100°/s; Tilt: 0.1°/s–25°/s
Detail: Pan: 0.1°/s–400°/s; Tilt: 0.1°/s–200°/s

Speed presets:
Panorama: Pan: 100°/s; Tilt: 50°/s
Detail: Pan: 360°/s; Tilt: 200°/s


Presets: 300
PTZ Mode: 5 Patterns, 8 Tours, 5 Scans
Power-Off Memory : Yes

Idle Motion: Presets; Scan; Tours
Protocol: DH-SD, Pelco-P/D (Auto recognition)

Full HD This camera has 2 inputs and 1 alarm output
Ingresso Audio This camera has 1 audio input and 1 audio output
Icon Day/Night function Day/Night: allows you to adapt the lens to night/day vision, and the relative automatic management of the IR Illuminator, when present.
Example Day/Night function
ULTRA WDR up to 120dB
WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light/shadow contrast. Fundamental in case of shooting from inside to outside, plates, shadowed points or all situations where there is no homogeneity of light.
The greater the value in dB, the greater the camera's ability to manage the strong difference in the backlight present. Common WDRs usually reach 80db, the human eye is able to recognize a difference of up to 100db. This model reaches up to 120db managing very high levels of contrast.
Immagine esempio funzione WDR 120db

BLC (Back Light Compensation): it is one of the 3 possible steps in the management of images with contrast, typical situations are: entrances or exits from car parks, license plates, special lights, entrances with shots from inside to outside, etc. The light compensation is one of the most complex possible operations, the BLC function allows a discreet adaptation to these situations

3D-DNR function

3D-NR is the most advanced version of Noise Reduction management, it allows still images in low light and moving images, currently the most powerful solution for obtaining maximum results in low light.

Esempio funzione 3D-DNR
MicroSD card slot

Possibility to insert Micro SD up to 512GB (not included)

Protezione IP67 contro polveri e immersioni Protection level IP67 ( Dust / Immersion )

Downloads

Download the English brochure
SD50225-HC-LA dimensioni
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
