Dahua IPC-HFS7842-Z-5G-LED ONVIF 5G Bullet IP Camera - 8MP - With Artificial Intelligence , 8-56mm varifocal lens, 1 / 1.8 "8MP CMOS sensor, 5 stream , H.265 + compression - 5G Mobile Communication - Smart Lighting IR 80m (warm light module) - Day / Night (ICR), WDR 120dB, BLC, HLC, 3DNR, ROI - Video Analysis: Abandoned and lost objects, perimeter, intrusion, tripwire, metadata, face detection, ANPR, people counting, smart search - Audio, Alarm, Micro SD 256GB slot, RS485, Cloud P2P, IP67 protection - For outdoor.
FIND INSTALLER
€2,083.19
€4,844.62 -57%PRODUCT NOT AVAILABLE, DISCOUNT NOW 3%
LO HAI TROVATO A MENO?
Scrivici dove e ti sconteremo la differenza fino a fine mese!
CHRISTMAS WEEK 2024 ×
FREE SHIPPING
ON THE ENTIRE CATALOGUE!
1. Reach at least €249
2. Select FEDEX
3. Confirm code NATALE-FREE-E
4. Complete your order.
Shipping will be free of charge!
Until 10 a.m. on 27/12/2024
Code NOT combinable with other actives
OUTDOOR IP CAMERA ONVIF® BULLET 5G - 8 MEGAPIXEL - 8-56MM - SMART IR 80M - 5 STREAM - AI - VIDEO ANALYSIS - DAHUA - IPC-HFS7842-Z-5G-LED
Resolution 8 Megapixel - Optical 8-56mm - CMOS 1 / 1.8 " 8MP - Up to H.265 + - 80m Smart IR illuminator with warm light module - 5G connection module - Day / Night (ICR) - WDR 120dB - 3DNR - Artificial Intelligence - 256GB MicroSD Slot (not included) - Audio / Alarm - RS-485 - Artificial Intelligence : Perimeter Protection, Face Detection, People Counting, Metadata, Intelligent Search, ANPR - Video Analysis : Abandoned / Lost Objects, Movement of Objects
AI TECHNOLOGY | ARTIFICIAL INTELLIGENCE:
Artificial intelligence (AI) refers to the branch of science and engineering that produces intelligent machines, especially intelligent computer programs. In the security sector, on the other hand, the artificial intelligence used is the one that allows the creation of advanced devices for environmental analysis.
Product details
- Outdoor IP camera ONVIF® 5G AI Series Dahua
- Resolution 8 Megapixel 8MP
- 8-56mm motorized varifocal lens
- 1 / 1.8 ”8MP image sensor
- 5G connection module
- Video Compression up to H.265 +
- 5 Stream
- Artificial Intelligence: Perimeter Protection, Face Detection, People Counting, Metadata, Smart Search, ANPR
- General Video Analysis: Abandoned / lost objects, movement of objects, tripwire, intrusion
- Functions: Day / Night (ICR), WDR 120dB , BLC, HLC, 3D DNR, Motion Detection, ROI, EIS, Defog, Image rotation, Mirror Mode, Privacy Masks
- Smart IR 80m
- 2 audio in / 1 out
- 7 alarm inputs / 3 outputs
- IP67 protection (Dust / Immersion) ideal for outdoor use
- RS-584
- MicroSD Slot (Max 256GB - Not Included)
- 12V DC power supply (not included)
- Operating temperature: –30 ° C to + 60 ° C (–22 ° F to + 140 ° F) / Less than 95% RH
- Dimensions: 404.3mm × 163.8mm × 211.8mm
- Weight: 4.02Kg
- Plastic and metal housing
- 24 months warranty
Data sheet
| IPC-HFS7842-Z-5G-LED | |||||
|
Technical Specs |
|||||
|
Room |
|||||
|
Image Sensor |
1 / 1.8 ”8Megapixel progressive CMOS |
||||
|
Max. Resolution |
3840 (H) × 2160 (V) |
||||
|
ROM |
4 GB |
||||
|
RAM |
2 GB |
||||
|
Scanning System |
Progressive |
||||
|
Electronic Shutter Speed |
Auto / Manual 1/3 s – 1 / 100,000 s |
||||
|
Min. Illumination |
0.003 Lux@F1.2 (Color, 30IRE) 0.0003 Lux@F1.2 (B / W, 30IRE) 0 Lux (Illuminator on) |
||||
|
S / N Ratio |
> 56 dB |
||||
|
Illumination Distance |
80 m |
||||
|
Illuminator On / Off Control |
Auto / Manual |
||||
|
Illuminator Number |
6 (Warm light) |
||||
|
Lens |
|||||
|
Lens Type |
Motorized vari-focal |
||||
|
Mount Type |
Module |
||||
|
Focal Length |
8 mm – 56 mm |
||||
|
Max. Aperture |
F1.2 (Constant) |
||||
|
Field of View |
Horizontal: 40 ° (W) –9 ° (T) Vertical: 22 ° (W) –5 ° (T) Diagonal: 46 ° (W) –10 ° (T) |
||||
|
Iris Type |
Car |
||||
|
Close Focus Distance |
W: 2m (6.6ft) T: 3m (9.8ft) |
||||
|
Smart Event |
|
|
IVS |
Abandoned object; missing object |
|
Professional, intelligent |
|
|
IVS (Perimeter Protection) |
Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection |
|
Face Detection |
Face detection; track; optimization; snapshot; high quality picture report; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: Face, single inch photo; three snapshot methods: Real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting |
|
People Counting |
Support the people counting of tripwire, people counting in area, and displaying and outputting yearly / monthly / daily reports Support queue management, and displaying and outputting monthly / daily reports Support 4 rules configuration for people counting of tripwire, 4 rules configuration for people counting in area, 4 rules configuration for queue management |
|
ANPR |
ANPR, track, priority, snapshot Vehicle attributes: license plate, vehicle type, vehicle color, vehicle brand Other attributes: sun visor, seat belt, smoking, phoning, in-car accessories, annual vehicle inspection mark |
|
Video Metadata |
Support human body, human face, motor vehicle and non-motor vehicle image capture and attributes extraction. |
|
Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
|
Video |
|
|
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
|
Smart Codec |
Smart H.265 + / H.264 + |
|
Video Frame Rate |
2 channel (RCA port) |
|
Audio Output |
1 channel (RCA port) |
|
Alarm Input |
7 channels in: 5mA 3V – 5V DC |
|
Alarm Output |
3 channels out: 1,000mA 30V DC / 500mA 50V AC |
|
Power |
|
|
Power Supply |
12V DC |
|
Power Consumption |
Basic power consumption: 5.2W (12V DC) Max. Power consumption (ICR + warm light full intensity + 5G acquiring): 25.5W (12V DC) |
|
Environment |
|
|
Operating Conditions |
–30 ° C to + 60 ° C (–22 ° F to + 140 ° F) / Less than 95% RH |
|
Protection Grade |
IP67 |
|
Construction |
|
|
Casing |
Metal + Plastic |
|
Dimensions |
404.3 mm × 163.8 mm × 211.8 mm (15.9 × 6.4 "× 8.3") (L × W × H) |
|
Net Weight |
4.02 kg (8.9 lb) |
|
Gross Weight |
4.98 kg (11 lb) |
Further details
 |
All Onvif , the absolute standard for IP cameras, being Onvif guarantees compatibility with any modern recording system. NOT being Onvif means having a camera for its own sake that can never be used together with recording systems This camera complies with the ONVIF® standard |
|
 |
This camera integrates a high performance module for 5G connection. | |
 |
Dahua ANPR cameras offer a full range of license plate recognition functions. They integrate an algorithm that detects and captures license plates and stores their details in a database
How and where can it be used? A Dahua ANPR camera is suitable for various types of areas, including parking entrances, barrier controlled areas or lane monitoring. The camera can acquire license plates up to a speed of 25 miles per hour ( 40km / h )
 |
|
|
|
AI | Artificial intelligence - Perimeter protection : Line crossing, intrusion, fast movement (the 3 functions support classification and accurate detection of vehicles and humans), parking detection, loitering, wandering
|
|
 |
|
|
 |
New ULTRA HD 4K Technology! Even higher resolution than FULL-HD! More detail available, greater sense of depth and realism. |
|
 |
Video Stream - 5 Streams! This camera supports H.265 + video compression with 5 video streams! |
|
 |
This camera features 8-56mm varifocal lens! | |
 |
Illuminator with an approximate maximum range of 80m!
|
|
 |
Remote visibility on mobile using the Dahua DMSS application. |
|
 |
This camera provides VIDEO ANALYSIS (SMART DETECTION): |
|
 |
ULTRA WDR up to 120dB WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light / shadow contrast. Fundamental in the case of shots from the inside out, license plates, shaded spots or all situations where there is no homogeneity of light. The higher the db value, the greater the camera's ability to manage the strong difference in the backlight present. Common WDRs usually reach 80db, the human eye is able to recognize a difference of up to 100db. This model reaches up to 120db managing very strong contrast levels.  |
|
 |
This camera is equipped with the ROI function. The images deriving from IP cameras are “compressed”, consequently the quality is set during the recording phase. Especially on cameras with a very high resolution, it is often necessary to reduce the quality in order to guarantee a reduced bandwidth occupation and record a greater number of days or cameras. The ROI allows you to define areas where you can set a higher quality (for example a door, the area where the plate usually passes, an exit, etc.). In that area I can set a higher quality thus guaranteeing a greater definition of the image.  |
|
 |
This camera features the EIS function. The EIS (image stabilizer) especially useful when the camera is not positioned in a fixed place (ships, vehicles, etc.) or outdoors on poles where atmospheric conditions can make the image unstable  |
|
 |
DEFOG It allows you to clearly see images taken in particular climatic conditions: rain, smoke and fog   |
|
 |
It allows to adapt the lens to the night / day vision and the consequent management of the IR illuminator automatically. |
|
 |
The IR CUT FILTER is a mechanical filter that allows a correct display of images in daylight viewing conditions. It filters the typical infrared frequencies thus improving the image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies.  |
|
 |
AGC is an integrated signal amplifier that allows vision even in critical conditions. It is automatic and does not require specific settings. |
|
 |
BLC (Back Light Compensation): it is one of the 3 possible steps in the management of images with contrast, typical situations are: entrances or exits from parking lots, license plates, special lights, entrances with shots from inside to outside, etc. Light compensation is one of the most complex operations possible, the BLC function allows a discreet adaptation to these situations  |
|
 |
3D-NR is the most advanced version of NOIS REDUCTION management. Allows still images in low light and in motion. It is currently the most powerful solution for obtaining maximum results in low light conditions |
|
|
|
This camera has 2 audio input + 1 audio output |
|
 |
This camera has 7 inputs + 3 alarm outputs | |
 |
1x RS485 | |
 |
Possibility to record what happens on MicroSD. (Max 256GB - Not included) |
|
 |
Protection level IP67 (Dust / Diving) |
|
 |
A 12V DC power supply is required for the operation of this camera (not included)  |
|
 |
This product is covered by a 24 month warranty. |
