copy of Outdoor Dome Camera - 4in1 - ColorView Series - 5MP - 2.8mm - Smart IR 20m - IP67

copy of Outdoor Dome Camera - 4in1 - ColorView Series - 5MP - 2.8mm - Smart IR 20m - IP67

HYU-1038 - Equivalent SF-T943CA-3KP - Dome camera 5MP 4in1 (HDCVI / HDTVI / AHD / ANALOG) - Resolution 5MP 2960x1665) - 5MP CMOS sensor - 2.8mm fixed lens - ColorView (24/7 color vision) - Smart IR 20m white light - BLC, HLC, Global, HLS, Digital WDR, 2D-DNR - White balance - AGC - Onboard microphone - White light alarm - Metal housing - IP67 protection, ideal for outdoor use - 12V DC adapter (not included).



Reference: HYU-1091

Brand: Hyundai Security

FIND INSTALLER

€54.35

taxes included
Tax included
 Available in 5 days
 starting


Videosorveglianza Hyundai Security

4 IN 1 DOME CAMERA HYUNDAI 5 MEGAPIXEL 2.8MM FIXED LENS - 4 in 1: HDCVI, HDTVI, AHD, ANALOG - SMART IR 20 MT - IP67 - WHITE LIGHT ALARM - MICROPHONE - HYU-1038

Hyundai Security

HYU-1038 equivalent SF-T943CA-3KP - Hyundai 4 in 1 outdoor dome camera
"HDTVI / HDCVI / AHD / ANALOG resolution 960H" - 5 MP resolution - 2.8mm fixed lens - Series with ColorView technology, for 24/7 color viewing - Smart IR20 MT white light illuminator - OSD functions via coaxial, AGC, BLC, HLC, WDR 120dB, 2D-DNR, image adjustments, mirror mode - Microphone - Steady light visual alarm (white) - Hyundai 3 year extended warranty! - Ideal IP67 protection. for outdoor use - Power supply 12 V DC (±25%) - Metal body

Product details

Gamma di prodotti Hyundai

HYUNDAI CATALOG:

Are you looking for a HYUNDAI product but couldn't find it on our website?

Don't worry, we can supply you with ALL Hyundai products: consult the CATALOG or contact us by email.

Tecnologia Quadribrida

This camera is a FOUR HYBRID (4 Integrated Technologies)
These cameras are at the same time Analog , Ahd , Hdcvi and Hdtvi .

Tecnologia AHDTecnologia HDCVITecnologia HDTVI

Switch Technologies:

The camera can switch from HDCVI to HDTVI, AHD or Analog via dip switch on coaxial cable

24 hours in color

CMOS sensor with ColorView Technology !

COLOR VIEW:

With the adoption of high performance sensor and large aperture lens, this camera can provide more colorful image even in low light environment. Full-color starlight cameras are perfect for low-light applications that exceed 1 lux, such as parking lots, city streets, schools, museums, etc.
* If the lighting conditions are total darkness, the video cannot be used for monitoring.

24H IN COLOR:

This camera does not have an IR CUT filter.

The camera does not switch to B/W but the vision will always be in colour.

Day/Night Standard VS Day/Night Color

Risoluzione 5MP

This camera features a resolution of 5Megapixel 5 MP!

Ottica fissa This camera is equipped with a 2.8mm fixed lens

Illuminatore IR 20 MT

Smart IR illuminator, with a maximum range of 20 meters, with white light

This camera is also equipped with SMART IR technology.
Through this technology, the light emitted by the LEDs is adapted according to the object framed.
Tecnologia Smart IR

Menu OSD

The camera has an OSD menu , through which it is possible to manage and adjust some functions such as: AWB, AGC, ATW, 2D-DNR, etc.
OSD menu control via coaxial cable (UTC)

Funzione AGC Automatic Gain Control The AGC is an integrated signal amplifier that allows vision even in critical conditions. It is automatic and does not require specific settings.
ULTRA_WDR_TLC.jpg ULTRA WDR up to 120dB
WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light/shadow contrast. Fundamental in case of shooting from inside to outside, plates, shadowed points or all situations where there is no homogeneity of light.
Protezione IP67 contro polveri e immersioni Protection level IP67 ( Dust / Immersion )

12V 3A power supply A 12VDC power supply is required for the operation of this camera (not included)
12V DC power supply
Garanzia 3 anni This product is covered by the manufacturer's 3-year warranty!

Data sheet

HYU-1038

5 megapixel CMOS sensor

Digital resolution: 5MP (2960x1665), 4MP (2560x1440), 1080P (1920x1080)

Frames per second: 20fps @5MP (TVI/AHD), 25/30fps @4MP (TVI/CVI/AHD), 25/30fps @1080P (TVI)

Switchable 4-in-1 video output

24h color mode

0.001 lux F1.0 (colour) / 0 lux with white light activated

White light: 20 metres

2.8mm fixed optics

Angle of view: 102°(H), 56°(V), 122°(D)

OSD via coaxial (TVI)

Picture modes: BLC, HLC, Global, HLS, Digital WDR, 2D-DNR

Adjustment of brightness, contrast, sharpness, mirror mode, defective pixel correction,

Anti-Banding, Smart Light

White balance with 4 modes

Automatic gain control

Built-in microphone

Solid light visual alarm (white light)

Power supply: 12V DC (±25%)

Power consumption: 2.5W (max.)

Operating temperature range: -40°C ~ +60°C

Relative humidity: <90% (non-condensing)

Degree of protection IP67

Metal housing

Dimensions: Ø85.1 x 77.62 mm

Weight: 328g

Further details

Famiglia di prodotti hyundai

Downloads

Leaflet: not available
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
