HYU-1038 - Equivalent SF-T943CA-3KP - Dome camera 5MP 4in1 (HDCVI / HDTVI / AHD / ANALOG) - Resolution 5MP 2960x1665) - 5MP CMOS sensor - 2.8mm fixed lens - ColorView (24/7 color vision) - Smart IR 20m white light - BLC, HLC, Global, HLS, Digital WDR, 2D-DNR - White balance - AGC - Onboard microphone - White light alarm - Metal housing - IP67 protection, ideal for outdoor use - 12V DC adapter (not included).
4 IN 1 DOME CAMERA HYUNDAI 5 MEGAPIXEL 2.8MM FIXED LENS - 4 in 1: HDCVI, HDTVI, AHD, ANALOG - SMART IR 20 MT - IP67 - WHITE LIGHT ALARM - MICROPHONE - HYU-1038
![Hyundai Hyundai Security](https://www.setik.biz/storage/images/Articoli/Hyundai_logo_blu.jpg)
HYU-1038 equivalent SF-T943CA-3KP - Hyundai 4 in 1 outdoor dome camera
![](https://cdn.setik.biz/storage/images/Articoli/9162_2936_55_002.jpeg)
Product details
![Hyundai products Gamma di prodotti Hyundai](https://www.setik.biz/storage/images/Articoli/hyundai_banner_2.jpg)
HYUNDAI CATALOG: Are you looking for a HYUNDAI product but couldn't find it on our website? Don't worry, we can supply you with ALL Hyundai products: consult the CATALOG or contact us by email. |
![]() |
This camera is a FOUR HYBRID (4 Integrated Technologies) Switch Technologies: The camera can switch from HDCVI to HDTVI, AHD or Analog via dip switch on coaxial cable |
![]() |
CMOS sensor with ColorView Technology ! COLOR VIEW: With the adoption of high performance sensor and large aperture lens, this camera can provide more colorful image even in low light environment. Full-color starlight cameras are perfect for low-light applications that exceed 1 lux, such as parking lots, city streets, schools, museums, etc. 24H IN COLOR: This camera does not have an IR CUT filter. The camera does not switch to B/W but the vision will always be in colour. |
![]() |
This camera features a resolution of 5Megapixel 5 MP! |
![]() |
This camera is equipped with a 2.8mm fixed lens |
|
Smart IR illuminator, with a maximum range of 20 meters, with white light This camera is also equipped with SMART IR technology. |
|
The camera has an OSD menu , through which it is possible to manage and adjust some functions such as: AWB, AGC, ATW, 2D-DNR, etc. |
![]() |
The AGC is an integrated signal amplifier that allows vision even in critical conditions. It is automatic and does not require specific settings. |
![]() |
ULTRA WDR up to 120dB WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light/shadow contrast. Fundamental in case of shooting from inside to outside, plates, shadowed points or all situations where there is no homogeneity of light. ![]() |
![]() |
Protection level IP67 ( Dust / Immersion ) |
![]() |
A 12VDC power supply is required for the operation of this camera (not included) ![]() |
![]() |
This product is covered by the manufacturer's 3-year warranty! |
Data sheet
HYU-1038 |
5 megapixel CMOS sensor |
Digital resolution: 5MP (2960x1665), 4MP (2560x1440), 1080P (1920x1080) |
Frames per second: 20fps @5MP (TVI/AHD), 25/30fps @4MP (TVI/CVI/AHD), 25/30fps @1080P (TVI) |
Switchable 4-in-1 video output |
24h color mode |
0.001 lux F1.0 (colour) / 0 lux with white light activated |
White light: 20 metres |
2.8mm fixed optics |
Angle of view: 102°(H), 56°(V), 122°(D) |
OSD via coaxial (TVI) |
Picture modes: BLC, HLC, Global, HLS, Digital WDR, 2D-DNR |
Adjustment of brightness, contrast, sharpness, mirror mode, defective pixel correction, |
Anti-Banding, Smart Light |
White balance with 4 modes |
Automatic gain control |
Built-in microphone |
Solid light visual alarm (white light) |
Power supply: 12V DC (±25%) |
Power consumption: 2.5W (max.) |
Operating temperature range: -40°C ~ +60°C |
Relative humidity: <90% (non-condensing) |
Degree of protection IP67 |
Metal housing |
Dimensions: Ø85.1 x 77.62 mm |
Weight: 328g |
