Electromagnetic latch - Ideal for glass doors - DAHUA - ASF808 - Push resistance up to 1000Kg - User adjustable door lock delay - Photoelectric technology to prevent mechanical failures - Resistance to very low temperatures: -30°C~+60°C - Control circuit with micro-processor chip.
FIND INSTALLER
https://www.setik.biz/en/bracket-and-cases/8851-dahua-asf808-electromagnetic-lock-for-glass-doors.html
€106.49
€247.66 -57%
taxes included
LO HAI TROVATO A MENO?
Scrivici dove e ti sconteremo la differenza fino a fine mese!
ELECTROMAGNETIC LOCK - FOR GLASS DOORS - DAHUA - ASF808
Electromagnetic lock - DAHUA - ASF808
Ideal for glass doors - Push resistance up to 1.000Kg - Resistant to low temperatures: -30°C~+60°C - 12VDC power supply - Photoelectric technology for the prevention of mechanical malfunctions - Dimensions: 148*43*39mm / 148 *43*25mm.
Ideal for glass doors - Push resistance up to 1.000Kg - Resistant to low temperatures: -30°C~+60°C - 12VDC power supply - Photoelectric technology for the prevention of mechanical malfunctions - Dimensions: 148*43*39mm / 148 *43*25mm.
Product details
- Electromagnetic lock - DAHUA - ASF808
- Ideal for use with glass doors
- Resistant to thrusts up to 1.000Kg
- User adjustable door lock delay: 0/3/6/9s
- Photoelectric technology to prevent mechanical malfunctions
- Power supply: 12VDC
- Dimensions: 148*43*39mm & 148*43*25mm
- Product net weight:
- Durability: 1,000,000 uses
- Wide operating temperature supported and ultra-low temperature resistance: -30°C~+60°C
- Microprocessor for circuit control
- Low consumption
Data sheet
| ASF808 | |
|
Technical Specs |
|
|
Electronic |
|
|
Working voltage |
DC12V |
|
Working current |
80mA |
|
Lock hold interval |
0/3/6/9s |
|
General |
|
|
Applications |
Glass door |
|
life |
>1000,000 times |
|
Anti-pull |
1000kg |
|
Dimensions |
148*43*39mm & 148*43*25mm |
|
Working Environment |
|
|
Working temperatures |
-30°C~+60°C |
|
Working humidity |
≤95% |
Further details
Downloads
Download the English brochure
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification
fill out this form
