QR Code reading module - Hikvision DS-KAB6-QR
QR Code Reader for Green Pass Reading, Connection Via USB Type C, in Plastic material, Compatible with DS-K1T671TM-3XF / DS-K1TA70MI-T
Internal application, Fixed with sheet metal screws or glued with 3M adhesive tapes
FIND INSTALLER
discover the available quantity
DS-KAB6-QR | QR READER FOR GREEN PASS - CONNECTION VIA USB - COMPATIBLE DS-K1T671TM-3XF / DS-K1TA70MI-T - HIKVISION
QR CODE reader, for reading qr code or green pass. DS-K1T671TM-3XF / DS-K1TA70MI-T compatible
Internal use, built in plastic material, Powered by USB, Installation by screws or adhesive tape.
Features:
- The device is small and handy, which can be installed with the face recognition terminal.
- The device adopts a high-precision image sensor with a resolution of 640 × 480, allowing QR code reading
- The device adopts USB2.0 communication transmission, which can directly supply 5VDC through the USB interface.
Data sheet
| DS-KAB6-QR | |
| Resolution | 640 x 480 |
| USB | Type-C |
| Power supply | 5 VDC |
| Power consumption | 500 mw |
| Working temperature | -20 ° C to 55 ° C |
| Dimensions | 35.1 mm × 24.1 mm × 17.5 mm |
| Installation | Fixed with sheet metal screws or glued with 3M adhensive tapes |
| Application environment | Indoor |
| Material | Plastic |
| Power supply method | USB |
