RILEVATORE PIR A DOPPIO FASCIO - PORTATA 12X12 METRI - SETIK

Rivelatore PIR a doppio fascio

DESCRIZIONE:
Il rivelatore GRD VXI-ST, è uno dei migliori rilevatori PIR a doppio fascio sul mercato.

Questo dispositivo è munito di 2 fasci di rivelazione regolabili e SMDA (Super Multi Dimension Analysis), logica avanzata di compensazione della temperatura e dell'immunità al rumore ambientale.

Prodotto estremamente affidabile.

Dettagli prodotto

  • Rivelatore PIR Infrarosso Passivo - Setik
  • Tipologia: rilevatore PIR  a doppio fascio
  • Copertura di rilevazione regolabile sino a 12 metri e 90°, programmabile in 5 livelli
  • Alimentazione da 9,5 a 18 Vc.c.
  • Assorbimento di corrente: Max 20 mA a 12 Vc.c.
  • Temperatura di funzionamento Da -30 a 60°C (da -22 a 140°F)
  • Protezione IP54

Rilevatore PIR infrarosso passivo doppio fascio

Scheda tecnica

Model GRD VXI-ST
System
Detection method Passive infrared
PIR Coverage 12.0 m (40 ft) 90° wide / 16 zones
PIR Distance Limit 12 – 2.5 m (5 levels)
Detectable Speed 0.3 – 1.5 m/s (0.98 – 4.92 ft/s)
Sensitivity 2.0°C (3.6°F) at 0.6 m/s
Power Input 9.5 – 18 V DC
Current Draw 20 mA (max.) at 12 V DC
Alarm Period 2.0 ±1 sec.
Warm-up Period Approx. 60 sec. (LED blinks
Alarm Output N.C. / N.O. Selectable 28 V DC 0.1 A (max)
Tamper Output N.C. 28 V DC 0.1 A (max) open when cover removed.
LED indicator Red: Warm-up, alarm, masking detection (VXI-AM only)
RF interference No alarm 10 V/m
Operating temperature -30 – +60°C (-22 – +140°F)
Environment humidity 95% max
International Protection IP54
Mounting Wall, Pole (Outdoor, Indoor
Mounting Height 0.8 – 1.2 m (2.64 – 3.94 ft)
Weight 500 g (17.7 oz.)
Accessories Screw (4×20 mm) ×2 , Wiring sponge ×3 , Masking seal ×3
