Ponte wireless - 2.4Ghz - 5Ghz - Antenna integrata -Supporta PoE - Range fino a 3km

Hardware

Interface

1 × PoE RJ–45 (1000 Mbps);

1 × LAN RJ–45 (100 Mbps)

Power Module Connector

1 × PoE RJ–45(IN: 30 W)

Wireless Standard

2.4GHz: 802.11b/g/n;

5GHz: 802.11a/n/ac

Power Supply

PoE IN: 802.3at;

PoE OUT: 802.3af

Included Power Adapter

Yes

Included Antenna

Yes

Ethernet Ports

2

Ethernet Port Speed

10/100/1000 Mbps

Reset Button

1

Power Consumption

< 30 W

External Port

2 × RJ–45; 1 × Reset

Indicator Light

1 × power indicator;
2 × LAN port indicators;
1 × PoE indicator;
3 × wireless signal strength indicators

Performance

Terminal Communication Protocol

IEEE802.11a/n/ac

Network Access

Ethernet

Operating Frequency

2.4 GHz(2412 MHz–2472 MHz);

5.150 - 5.850 GHz(5.15 GHz–5.25 GHz and 5.735 GHz–5.835 GHz)

Modulation Type

OFDM

Antenna

Built-in directional antenna

Antenna Interface

IPEX

Antenna Direction Angle

Horizontal 45°, vertical 20°

Polarization

Vertical/horizontal

Cross-polarization Isolation

> 12

Antenna Gain

12 dBi

Max. VSWR

< 2.5

Transmission Distance

3 km (9,842.52 ft)

Air Interface Rate

867 Mbps

Protection

IP65

Network Mode

Bridge

Operating Mode

Access point; client

Device Type

802.11a/b/g/n/ac

Channel Width

20/40/80 MHz

Standard TX Power

Adapt to the regulations of countries or regions.

Connected Wireless Terminals

8

Funtion

Encryption Mode

WPA-PSK/AES/TKIP

Management and Log

NTP; Syslog

Webpage Configuration Management

Web configuration

Firmware Update

Web update

Wireless Certification

CE/FCC

Security Mechanism

WPA/WPA2; hidden SSID

Network Protocol

HTTPS; IPv4; UDP; NTP; DHCP; TCP

TDMA Enhancement

Yes

TDMA

Yes

General

Operating Temperature

–30 °C to +65 °C (–22 °F to +149 °F)

Storage Temperature

–40 °C to +80 °C (–40 °F to +176 °F)

Operating Humidity

5%–95% (RH), non-condensing

Gross Weight

0.46 kg (1.01 lb)

Net Weight

0.37 kg (0.82 lb)

Packaging Dimensions

297 mm × 110 mm × 108 mm (11.7 " × 4.33" × 4.25")

Product Dimensions

268 mm × 82 mm × 35 mm (10.55" × 3.23" × 1.38")

Memory

1 Gb

Mounting

Pole mounting bracket included

Input

48 V

Statics Protection

Air discharge: 15 kV
Contact discharge: 8 kV

Lighting Protection

Common mode: 6 kV
Differential mode: 4 kV

Installation

Pole mount
