Outdoor dual infrared detector with anti-masking function ensures a detection coverage of 30 x 20 meters , offering 74 detection zones. 3-axis accelerometer for tampering and anti-rotation alarm with double shielding of the pyroelement. The alarm range is adjustable and the installation is compatible with heights between 2.3 and 4 meters , making it a versatile solution for outdoor security. - SIP-3020/5
BUSQUE INSTALADOR
LIQUIDACION TOTAL ×
CLEARANCE SALE!
Take advantage of our must-see outing offers.
Discover the promo >>
OUTDOOR DUAL PIR DETECTOR WITH ANTI-CRAWLING AND ANTI-MASKING ZONE - 30x20 M - OPTEX
Product details
- Outdoor Dual PIR Detector
- Anti-creep
- Anti-masking
- To branch
- Detection coverage 30x20 m
- Mounting for height 2.3 - 4 m
- Dimensions 248x102x266 mm
- Weight: 1.4 Kg
Technical data sheet
|
Model |
SIP-3020/5 |
| Detection method | Passive Infrared |
| Coverage (main area) | 30x20 m (100 x 65 ft.) |
| Coverage (creep zone) | 3x5m (10x16ft.) installed at 2.3m (7.6ft) height, 6x9m (20x30 ft.) installed at 4m (13ft.) height, Detection angle adjustable horizontally |
| Power input | 11-16 VDC 22-26 VAC, 22-26 VAC with optional heating unit |
| Current draw | 40mA max. (12VDC) 75mA (24VDC), 415mA max. (24VAC) with optional heating unit |
| Mounting height | 2.3 to 4m (7.6 to 13ft) |
| Sensitivity selector | Far: SH/H/M/L Near: SH/H/M/L |
| Range selector | to: On/Off |
| Detection logic selector | And/Or |
| Alarm input (main area) | NO, NC, 28 VDC 0.01A max. |
| Alarm input (creep zone) | NO, NC, 28 VDC 0.01A max. |
| Alarm interval period | Off/15, 30, 60 sec. |
| Troubleshooting | NC, 28 VDC 0.2 A max. |
| Tamper-proof | NC, 28 VDC 0.1 A max. |
| Alarm period | approx. 2 sec. |
| Warm-up period | approx. 60 sec. |
| Operating temperature | -25 to 60°C, -40 to +60°C with optional heating unit (-13 to + 140°F, -40 to 140°F with optional heating unit) |
| IP rating | Main unit: IP66 Frame: IP55 |
| Dimensions | 248x102x266 mm (9.08x4.0x10.5 in.) |
| Weight | 1.4 Kg (48 oz) |
Download
Brochure not available
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification
