Double beam infrared barrier with a range of up to 30 meters. Equipped with a single low-consumption channel, it offers installation flexibility thanks to the possibility of wiring the receiver. It ensures advanced protection thanks to the detection of interruptions of the double infrared beam coded with double modulation. IP65 protection. Powered by 2 SAFT LSH20 lithium batteries for transmitter and receiver, it supports a power range from 3.6 to 3.9 Vdc. - SL-100TNR
https://www.setik.biz/es/sensores-y-detectores/11148-optex-sl-200tnr-copy-of-low-consumption-infrared-barrier-for-outdoor-use-range-30m-wireless-optex.html
198,27 €
291,58 € -32%
impuestos incluidos
CHRISTMAS WEEK 2024 ×
FREE SHIPPING
ON THE ENTIRE CATALOGUE!
1. Reach at least €249
2. Select FEDEX
3. Confirm code NATALE-FREE-E
4. Complete your order.
Shipping will be free of charge!
Until 10 a.m. on 27/12/2024
Code NOT combinable with other actives
LOW CONSUMPTION OUTDOOR INFRARED BARRIER WI-FI 2 BATTERIES LSH20 - RANGE 30 M - OPTEX
Product details
- Low consumption outdoor infrared barrier for wireless or hybrid systems with PCU-5
- Wi-Fi
- Range 30 m outside
- Consumption: 500mA
- Power supply: 3.6V DC
- Working temperature: -20°C ~ +60°C
- Dimensions: 295 x 69 x 117 mm
Technical data sheet
| Model | SL-100TNR |
| Maximum detection range | 30 m/100 ft. |
| Maximum distance from arrival | 265 m/870 ft |
| Detection method | Twin infrared beam interruption detection |
| Interruption time | Variable between 50/100/250/500 ms (4 steps) |
| Power source | 3.6 to 3.9VDC D size lithium batteries Each Transmitter and Receiver: 2 units (Recommended SB-D02HP manufactured by VITZROCELL) 3.0 VDC CR123A lithium batteries Each Transmitter and Receiver: 8 units (with optional battery holder CRH-5: 2 units) |
| Current draw (stand by/at 25°C) | |
| 3.6 to 3.9 VDC size Lithium battery | Total: Approx. 500 μA Transmitter: Approx. 200 μA Receiver Approx. 300 μA |
| 3.0VDC CR123A | Total: Approx. 600 μA Transmitter: Approx. 200 μA Receiver Approx. 400 μA |
| Battery life | |
| D size Lithium battery | Transmitter: Approx. 6 years Receiver Approx. 5 years |
| CR123A | Transmitter: Approx. 1.5 years Receiver Approx. 1 year |
| Output | |
| Alarm output | Form C-Solid State Switch: 3.9 VDC, 0.01 A |
| Alarm period | 2 sec (±1) (Nominal) |
| DQ output | Form C-Solid State Switch: 3.6 VDC, 0.01 A (Receiver only) |
| Low battery output | NC (mechanical switch): 3.6 VDC, 0.01 A |
| Tamper output (cover, back box, main unit) | NC (Solid State Switch): 3.9 VDC, 0.01 A Opens when the battery cover removed. |
| LED indicator | |
| Alarm/Level indicator (Receiver) | ON: Beam not received Blinking: Beam not received sufficiently OFF: Beam received |
| Power/Low battery indicator (Transmitter and Receiver) |
ON: Power ON Blinking: Voltage reduction OFF: Power OFF |
| Operating temperature | -20°C - +60°C (-40°F - 140°F) |
| Operating humidity | 95% (max.) |
| Alignment angle | ±90° Horizontal, ±10° Vertical |
| Dimensions | 295 x 69 x 117 mm |
| Weight | 1200 g (42.4 oz.) (Total weight of Transmitter + Receiver, excluding accessories) |
| International protection | IP65 |
