TP-Link Omada EAP655-Wall is a Wall-Plate WiFi 6 AX3000 access point designed to provide fast, stable and reliable wireless connections in dense user environments, such as offices, schools and retail stores. With combined speeds of up to 2976 Mbps and support for MU-MIMO and OFDMA technology, it ensures optimized performance even when using multiple devices simultaneously. This device integrates seamlessly with the Omada SDN ecosystem, enabling centralized cloud management for simple and flexible network control. With its ceiling-mount design and slim profile, it easily fits into any environment, maintaining a discreet aesthetic. It supports PoE power supply, simplifying installation and reducing costs. TP-Link Omada EAP655-Wall is the ideal choice for implementing modern, reliable and scalable business networks.
BUSQUE INSTALADOR
PRODOTTO NO DISPONIBLE, DE DESCUENTO AHORA 3%
AX3000 CEILING ACCESS POINT DUAL-BAND Wi-Fi 6 - TPLINK OMADA
AX5400 Ceiling Mount Dual-Band Wi-Fi 6 Access Point with 1 x Gigabit Ethernet Port. Offers speeds of 2976Mbps (574Mbps in 2.4GHz and 2,402Mbps in 5GHz). Supports 802.3at PoE power supply. Includes 4 internal antennas and advanced features such as MU-MIMO, seamless roaming, Band Steering, Beamforming, load balancing, Airtime Fairness. Centrally manageable via Omada SDN Controller or via Omada App for easy and intuitive setup.
Main features:
- Wi-Fi 6 AX3000: Offers wireless speeds of up to 2976Mbps (574Mbps in 2.4GHz and 2,402Mbps in 5GHz) .
- Perfect for crowded environments: Advanced MU-MIMO and OFDMA technologies, introduced with the Wi-Fi 6 standard, quadruple the network capacity, allowing more devices to connect simultaneously without interruption.
- Seamless Roaming: Ideal for streaming and other real-time applications, it allows you to move between access points without losing performance.
- PoE+ Support: Compatible with Power over Ethernet (802.3at standard).
- Guest Network: Includes a Captive Portal for quick and secure access, with multiple authentication modes available.
- Omada SDN Integration: Omada Software Defined Networking platform enables centralized network management, with remote access via the cloud.
- Omada App: Simple and intuitive network management via Android and iOS devices, accessible anywhere thanks to the cloud connection.
- Ultra-slim design: With a height of 143 mm, length of 86 mm and a thickness of 42.6 mm, the EAP655-Wall model integrates seamlessly into any environment, offering installation flexibility.
Technical data sheet
| Model | EAP655-Wall |
| HARDWARE FEATURES | |
| Interface | Uplink: 1× Gigabit Ethernet Port Downlink: 3× Gigabit Ethernet Ports (One port supports PoE out. The PoE out feature requires 802.3at PoE+ input. The maximum power output for POE pass-through is 10.5 W (EU version) or 10 W (US version), based on laboratory testing.) |
| Physical security lock | No |
| Key | LED Reset |
| Diet | 802.3at PoE |
| Energy consumption | EU: 12W (802.3at PoE, PoE Out off) US: 12.6W (802.3at PoE, PoE Out off) |
| Dimensions (L x W x H) | 143 × 86 × 42.6 mm (5.6 × 3.4 × 1.7 in) |
| Antenna type | 2 Dual Band Antennas 2.4GHz: 2×3dBi 5GHz: 2×5dBi |
| Mounting type | Wall Plate Mounting (Kits included) |
| WIRELESS FEATURES | |
| Coverage | 50㎡(600 ft²) |
| Wireless Client Capacity | 120+** |
| Wireless Standards | IEEE 802.11ax/ac/n/g/b/a |
| Frequency | 2.4GHz and 5GHz |
| Signal rate | 5GHz: Up to 2402Mbps 2.4GHz: Up to 574Mbps |
| Wireless functionality | 16 SSIDs (Up to 8 SSIDs on each band) Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power on dBm) QoS(WMM) Seamless Roaming(802.11k/v/r)§§ Beamforming Rate Limit Load Balance Airtime Fairness Band Steering Reboot Schedule Wireless Schedule RADIUS Accounting MAC Authentication Wireless Statistics Static IP/Dynamic IP |
| Wireless Security | Captive Portal Authentication§ Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients VLAN Rogue AP Detection 802.1X Support WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Transmission power | THERE IS: <20dBm(2.4GHz,EIRP) <23 dbm="" 5="" ghz="" band1="" band2="" eirp="" br=""> <26 dbm="" 5="" ghz="" band3="" eirp="" br=""> FCC: <21dbm 2="" 4ghz="" br=""> < 21 dBm (5 GHz, band 1 & band 2 & band 3 & band 4) |
| MANAGEMENT | |
| Omada App | Yes |
| Centralized Management | Omada Cloud-Based Controller Omada Hardware Controller (OC300) Omada Hardware Controller (OC200) Omada Software Controller |
| Cloud Access | Yes. Require the use of OC300, OC200, Omada Software Controller, or Omada Cloud-Based Controller. |
| Email Alerts | Yes |
| LED ON/OFF | Yes |
| MAC Access Control Management | Yes |
| SNMP | v1, v2c, v3 |
| Local and remote system logs | Local/Remote Syslog |
| SSH | Yes |
| Web-based management | HTTP/HTTPS |
| L3 Management | Yes |
| Multisite Management | Yes |
| VLAN Management | Yes |
| Zero Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller. |
| OTHER | |
| Certification | CE, FCC, RoHS |
| Package Contents | AX3000 Wall Plate WiFi 6 Access Point EAP655-Wall Installation Guide Mounting Kits |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Environment | Operating Temperature: 0°C–40°C (32°F–104°F); Storage Temperature: -40°C–70°C (-40°F–158°F); Operating Humidity: 10%–90% non-condensing; Storage Humidity: 5%–90% non-condensing |
|
A private Wi-Fi network in every room
|
|
|
Ultra-fast Wi-Fi 6 AX3000 Wi-Fi 6 technologies ensure high connection speeds and greater network capacity by reducing lag and interference. Enjoy stable and reliable connections with combined speed of the two Wi-Fi bands up to 2976Mbps.
|
|
|
Better user experience thanks to high-performance Wi-Fi 6 connectivity The latest Wi-Fi 6 features and advanced wireless techniques ensure greater network efficiency and lower latency.
|
|
|
Safety first Protect your network from brute-force attacks and snooping with WPA3 standard technologies, portal authentication, and separate guest networks.
|
|
|
Gigabit wired connectivity and PoE Passthrough switches The 4 Gigabit ports (1 uplink + 3 downlink) allow you to connect more wired devices to expand your network. One of the downlink ports offers PoE pass-through to power wired devices such as VoIP phones and IP cameras without the need for additional power cables.
|
|
|
Maximum flexibility thanks to PoE technology EAP655-Wall features 802.3af/802.3at PoE support which allows the device to be installed and powered via network cable.
|
|
|
Quick and easy installation EAP655-Wall can be mounted on the wall using a 503 bracket or any electrical flush box. The unique design simplifies placement and only requires an Ethernet cable connected to a PoE switch.
|
|
|
Optimize performance with Auto Channel Selection and Power Adjustment It provides powerful wireless performance by significantly reducing Wi-Fi interference and automatically adjusting the channel settings and transmission power levels of nearby APs in the same network.
|
|
|
Omada SDN - Software Defined Networking Omada SDN is TP-Link's Software Defined solution that offers wireless and wired solutions ideal for hotels, healthcare facilities, education, businesses, public spaces and more. Omada SDN integrates a full range of devices - Access Points, Switches, Gateways and Hardware Controllers - into a highly scalable network solution with Full-Cloud and Hybrid-Cloud management.
|
|
|
3 year warranty The following product is covered by a 3 year warranty |
|
