TTA111HDR HDMI Active Extender Receiver over UTP Cable for HDCVI/AHD/TVI/CVBS Video Signal Range 600M 1080P / 250m 4K. Dahua
BUSQUE INSTALADOR
https://www.setik.biz/es/accesorios-de-video/11056-dahua-tta111hdr-active-hdmi-extender-receiver-on-utp-cable-600m-range-dahua.html
78,17 €
181,78 € -57%
impuestos incluidos
LO HAI TROVATO A MENO?
Scrivici dove e ti sconteremo la differenza fino a fine mese!
HDMI ACTIVE EXTENDER RECEIVER FOR VIDEO SIGNAL EXTENSION - RANGE 600M - UTP CABLE
TTA111HDR Active HDMI Extender Receiver over UTP Cable for HDCVI/AHD/TVI/CVBS Video Signal Range 600M 1080P / 250m 4K
Product details
- HDMI Active Extender Receiver - Dahua
- Allows you to extend the transmission distance up to 600 meters on UTP cable
- HDCVI/AHD/TVI/CVBS video formats
Technical data sheet
| Model | TTA111HDR |
| Technical specifications | |
| Video input channel | 5-PIN removable terminal |
| Video output channel | BNC x 1 (75Ω 1Vp-p) |
| Video Formats | HD-TVI, HD-CVI |
| Switch | Slide switch (3 levels) x1 |
| Cable | UTP CAT5e/CAT6 |
| Transmission distance | AHD / HDCVI 400M @ 1080p HD-TVI 300M @ 1080p |
| Power supply | DC12V 500mA |
| Electricity consumption | 150mA(Typical), 220mA(Max) |
| Temperature | 1080P/1080I/720P/576P/576I/480P/480I |
| Output Voltage | Operation: 0 to 55°C Box: -20 to 85°C Humidity: Up to 95% |
| Dimensions mm |
57.8 x 49.2 x 41.7 |
| Weight g |
70 |
Further details
Download
Brochure not available
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification
fill out this form
