The VIGI PS30 is an advanced solar controller equipped with a 31.2Ah/10.8V automotive-grade lithium battery. It offers remote management and maintenance via the VIGI App or VIGI Cloud VMS, ensuring efficient monitoring. The intelligent auxiliary heating technology ensures optimal battery performance even in extremely cold weather conditions. The Maximum Power Point Tracking (MPPT) charge controller increases charging efficiency by 20% compared to traditional PWM controllers. With built-in protections against overcharge, over-discharge, overcurrent, overheating and short circuit, and an IP66 rating, the VIGI PS30 is ideal for powering outdoor devices such as surveillance cameras and network equipment.
3 Years Warranty
BUSQUE INSTALADOR
VIGI PS30 SOLAR SYSTEM CONTROLLER - 31.2Ah/10.8V - IP66
The TP-Link VIGI PS30 31.2Ah/10.8V Automotive-Grade Lithium Battery is designed to provide stable and long-lasting power to your devices, ensuring maximum performance even in extreme weather conditions. Thanks to the intelligent auxiliary heating technology, it maintains optimal efficiency even at low temperatures.
Equipped with a MPPT charge controller, it optimizes solar charging by increasing efficiency up to 20% compared to traditional PWM controllers. In addition, the integrated protection against overload, over-discharge, over-current, overheating and short circuit ensures safe and reliable operation over time.
With a residual capacity of over 70% after 500 cycles, this battery guarantees exceptional durability and resistance. The IP66 certification makes it resistant to the elements, protecting it from dust and water, perfect for outdoor installations.
With remote management and maintenance via VIGI app or VIGI Cloud VMS, you can monitor the battery status in real time and optimize its performance without manual intervention. In addition, the simple installation makes it suitable for any type of off-grid or solar power system.
PRODUCT DETAILS
|| Technical Specifications:
- 31.2Ah/10.8V Automotive-Grade Lithium Battery
- Remote management and maintenance via VIGI app or VIGI Cloud VMS
- Intelligent auxiliary heating technology ensures optimum battery performance in extremely cold weather conditions
- The charge controller with maximum power point tracking (MPPT) increases charging efficiency by 20%*
- Overload, over-discharge, over-current, over-heat and short circuit protection
- Residual capacity > 70%** after 500 cycles
- IP66 Weatherproof
- 3 year warranty
DATA SHEET
| Battery | |
|---|---|
| Type | Lithium |
| Intelligent Auxiliary Heat | Yes |
| Battery Capacity | 31.2 Ah |
| Voltage | 10.8 V |
| Max.Output Voltage | 12.6 V |
| Life | More than 500 cycles |
| Dimensions | 242×70×65 mm (9.5×2.8×2.6 in) |
| Charging Condition | 0°C~45°C -30°C~45°C (With intelligent auxiliary heating) |
| Discharging Condition | -20°C~60°C -30°C~60°C (With intelligent auxiliary heating) |
| HARDWARE | |
| Interface | 1× 10/100Mbps RJ45 1× Photovoltaic Panel Connector 3× 5.5mm DC Power Plugs (#1, #2: 9V-12.6 VDC/2A, #3: 12 VDC/2A) |
| LED indicator | Quantity: 4 (1× SYS Indicator, 1× LAN Indicator, 1× PV Indicator, 1× BAT Indicator) Color: Blue |
| SOFTWARE FEATURES | |
| Load Control | Yes |
| High and Low Temperature Protection | Yes |
| Overdischarge protection | Yes |
| Power Consumption Statistics | Yes |
| Displays Real-time Load Status | Yes |
| Battery Level Display | Yes |
| Time Zone Selection | Yes |
| Region Selection | Yes |
| Schedule Saving | Yes |
| Firmware Remote Update | Yes |
| Remote Reboot | Yes |
| Local LAN Management | Yes |
| Smart Charging Control | -30°C~5°C |
| Account Management | Yes |
| Remote Reset | Yes |
| Remote Message Push | Yes |
| OTHER | |
| Certification | CB, PSE (Battery) CE, FCC, VCCI, IC, IP66 Weatherproof |
| Package Contents | VIGI PS30 Quick Start Guide Waterproof Cable Attachments Mounting Accessories |
| Box dimensions (L x W x H) | 580×320×225 mm (22.83×12.60×8.86 in) |
| Weight | Package Weight: 9.9kg |
| Environment | Operating Temperature: -30°C-60°C (With intelligent auxiliary heating) Operating Humidity: 10%~90%RH, Non-condensing |
|
3 year warranty The following product is covered by a 3 year warranty |
