Outdoor Twin Infrared Barrier Range 60m - Wired - IP65 - Optex

-32% Neu

Outdoor coded double beam infrared barrier with a range of 60m. Alarm memory held for 55 minutes. The selectable beam encoding is designed to prevent unwanted interference, ensuring reliable operation even in situations involving the use of multiple beams over long distances or in the presence of barriers installed in a column. - IP65 protection. - AX-200TF

Artikel-Nr.: AX-200TF

Marke: Optex

INSTALLATEUR FINDEN

https://www.setik.biz/de/sensoren/11119-optex-ax-200tf-outdoor-twin-infrared-barrier-range-60m-wired-ip65-optex.html

166,75 €

245,22 € -32%

Steuern inbegriffen

SIND SIE PROFESSIONELL IN DER BRANCHE?
REGISTRIEREN SIE SICH, UM AUF IHRE LISTE ZUGREIFEN

Quantität

Erhältlich in 5 tage

CHRISTMAS WEEK 2024 ×

FREE SHIPPING
ON THE ENTIRE CATALOGUE!

1. Reach at least €249
2. Select FEDEX
3. Confirm code NATALE-FREE-E
4. Complete your order.
Shipping will be free of charge!

Until 10 a.m. on 27/12/2024
Code NOT combinable with other actives

Description Product Details Data Sheet Download

OUTDOOR TWIN INFRARED BARRIER - RANGE 60M - IP65 - OPTEX

Product details

Medium Range Outdoor Twin Infrared Barrier
To branch
Range 60 m outside
Alarm memory 55 minutes
Consumption: 48mA
Power supply: 10.5 - 28V DC
Working temperature: -35°C ~ +60°C
IP65 protection
Dimensions: 170 x 65 x 70 mm

Technical data sheet

Model	AX-200TF
Detection method	Infrared beam interruption detection
Maximum detection range	60m (200ft.)
Maximum arrival range	600m (2000ft.)
Interruption period	Selectable between 50, 100, 250, and 500m sec.
Selectable beam frequency	4 channels
Power Supply	10.5 - 28V DC
Current consumption (transmitter + receiver)	48mA (max.)
Alarm period	2sec. (±1) nominal
Alarm output	NC/NO 28V DC, 0.2A (max.)
DQ output	NC 28V DC, 0.2A (max.)
Tamper switch	Opens when cover is removed at 28V DC, 0.2A max
Operation Temperature	-35°C to +60°C (-31°F to +140°F) Use the optional heating unit (HU-3) in conditions of -25°C (-13°F) or below.
Operating Humidity	95% (Max)
Alignment Angle	± 90° Horizontal, ± 5° Vertical
Mounting	Wall and pole mounting
Weight	700g (24.7oz.)
IP rating	IP65
