UR FOG fog generator pump technology FAST 1500 PUMP PRO PLUS Anti-theft

UR FOG fog generator pump technology FAST 1500 PUMP PRO PLUS Anti-theft
-25%

UR FOG FAST 1500 PUMP PRO PLUS Fog Alarm, ideal for protecting small/medium areas (shops, apartments, ATMs etc.). Shoots up to 1,500 m3 of thick fog in about 70 seconds with a single shot, 1000ml bag (not included) . Easy wall installation - equipped with a compartment for inserting cards and additional accessories. FPU1500PP



Artikel-Nr.: FPU1500PP

Marke: UR FOG

INSTALLATEUR FINDEN



Partnership Helvetia UR FOG Polizza HELVETIA-UR FOG PARTNERSHIP:

Do you have a business?
Discover the benefits you can get from this collaboration!

ANTI-THEFT FOG GENERATOR FAST 1500 PUMP PRO PLUS UR FOG

FPU1500PP

URFog FAST 1500 PUMP PRO PLUS
URFOG Fog System

Ideal fogging system for protecting small/medium areas (shops, apartments, ATMs, etc.).
It shoots in a single shot, up to 1500 m3 of dense fog in about 70 seconds, 1000ml bag (not included) of low pressure fogging liquid and can be installed on the wall.


Product details

FPU1500PP
  • Fog Generator - UR FOG
  • Emission up to 4500m3 of fog
  • Smoke liquid certified as not harmful to health
  • 1000ml bag (not included)
  • Battery powered 2 Ah 12V (not included)
  • Complies with standards: CE and EMC
  • Complies with European standards
  • Wall mountable (vertical or horizontal)
  • Lower compartment for installing additional cards and accessories
  • White color
  • Dimensions: 36.0X28.5Xh43.5
  • Weight: 29kg (without packaging)

Technical data sheet

Model FPU1500PP
WEIGHT OF THE FOG MACHINE About 29 Kg
WEIGHT WITH PACKAGING About 31 kg
UNITS ON ONE PALLET 100X120 24
DIMENSION OF THE MACHINE 36.0X28.5Xh43.5
PACKAGING DIMENSIONS 51.0X39.0XH52.5
Colors

White

WORKING TIME WITHOUT MAINS POWER About 2.5 hours
HEAT UP TIME FROM COLD about 2.5 hours
VERTICAL OR CORNER MOUNTING yes
HORIZONTAL OR CORNER MOUNTING Optional (35°)
SERIAL/USB PORT FOR MONITORING yes
NOZZLE TAMPER yes
RS232 serial interface with standard UR FOG protocol yes
Active Cloud Network Optional
Fog Generator
LAYER HEATING SYSTEM yes
MAX FOG SINGLE SHOT 1.5M VISIBILITY up to 4500 m3
MAX FOG SINGLE SHOT ZERO VISIBILITY up to 1500 m3
MAX SECONDS OF FOG 70 sec
MAX FOG EMISSION WITH FULL FOG TANK 1700 m3
NUMBER OF CYLINDERS 1
FOG TANK CAPACITY 1 x 1000 ml
SHOOTING SPECIFICATION programmable in seconds
CYLINDER INCLUDED 1
Electrical Specifications
POWER SUPPLY 230 OR 120V
AVERAGE POWER CONSUMPTION 60W
BATTERY 2AH 12V (not included) YES
PIR INPUT YES
OUTPUT CONFIRM SHOT YES
POWER SUPPLY YES

Further details

Prodotto escluso da garanzia

For operation:

To operate the fog generator, you need to:

- 230V power supply (for the exchanger heating system)

- 2Ah battery (for cylinder motors) - power supply not included

- 12V power supply for electronic board power supply

It is recommended to supply 12V via the alarm control unit.

For connections between alarm control unit - switches, etc., refer to the installation and use manual.

Emissione nebbia rapida

The fastest fog generators in the world

Up to 200 m3 in 15 seconds. It is impossible to steal what is impossible to see this sentence makes great sense when we mean UR Fog since in a few seconds you can not see anything.

Nebbia ad alta densità

The thickest fog

Thanks to the innovative formulation of the fluid with a high percentage of glycol it ensures a dense fog that is totally impenetrable to visibility.

Sostituzione cilindro semplice

Removable cylinders

Removable and no charging required.

Basso consumo di energia

Low energy consumption

The perfect insulation system offers very low energy consumption which saves costs compared to other misting systems.

Nozzle Tamper

Nozzle tamper

Another unique, patented and very useful advantage that allows to automatically detect if the nozzle is tampered with and sends a warning signal

Protocollo Standard Smart Bus

Smart bus standard protocol

A single serial bus to connect an additional card to the electronic board that allows you to easily interface the machine with alarms and control the misting system even remotely. A standard protocol for all machines.

Tecnologie UR FOG in continua evoluzione

Innovative technology and performance

UR FOG fogging systems are innovative in their technology and performance, in order to guarantee maximum protection against theft.

Prodotto certificato UR FOG

Safe and certified

UR FOG misting systems are certified according to European regulations. The fog liquid is tested and is absolutely safe. They are not dangerous for objects, animals, people and leave no residue.

Accessories

UR-FOG ACCESSORIES:

F01STH - Wall bracket for FAST 01
F23STHPRO - Wall bracket for FAST PRO 02/03
F23PRUG7 - Nozzle Extension 7CM
F1MO3UG3 - 3 Hole Nozzle
F23KITD - Demo Kit for FAST 01/02 and FAST/FAST PRO
URTR - Remote control with receiver
Telecomando aggiuntivo - URT URT - Additional remote control

F123KEY - Armament key
F23KITA - Anti-theft cable
F23PA - Anti-theft button
URRS232 - 5/12V rs232 transceiver
URRE - Relay Card
URCL - Cloud Lan Card
Alimentatore UR FOG F1SO4PS - Power supply
Batteria 2Ah UR FOG F1M04BATT - Battery 2Ah

Download

No brochure available


WHO IS UR FOG?

Nebbiogeni Antifurto UR FOG

UR Fog is one of the most solid Italian companies in the fog systems market.
The UR FOG team is made up of professionals and engineers with over 20 years of experience both in the development of new products and in the management of distribution all over the world. From 2012 to today they have obtained several patents, created new technologies such as the single and double cylinder born right at the beginning of the activity and introduced important innovations such as the adjustable nozzle.
One of the strong points of this company and thanks to which they are very often chosen, is the speed of fog ejection, a critical aspect for the products of many other competing brands.

All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
